- Page 1 Fixturlaser Laser Kit Quick tips...
- Page 3 Fixturlaser Laser Kit Rough Alignment S T E P Correct Obvious Soft Foot shim Follow Tightening Sequence Follow the same sequence throughout the alignment pro-...
- Page 4 Fixturlaser Laser Kit Bolt Tightening Sequence Make a Final Soft Foot Correction...
- Page 5 Mount the ‘M’ sensor on the movable shaft or coupling hub and hand tighten the nut use the titning Tighten the nut Press the power button Start the Laser Kit App Click on the Fixturlaser Laser kit app on your device...
- Page 6 Fixturlaser Laser Kit Aim the Lasers adjustment wheel adjustment knob...
- Page 7 Fixturlaser Laser Kit Enter Dimensions Press the yellow tape measure icon to open the Measure the indicated dimension to the nearest Continue Tape measure icon Measure Misalignment the mea- 12:00 Position the sensors within ± 3° 9:00 3:00 9:00 position...
- Page 8 Fixturlaser Laser Kit measurement icon again to take the second 12:00 position...
- Page 9 Fixturlaser Laser Kit Evaluating the Results Green coupling icons indicate values which are within Using the VertiZontal Process ™ First Correct the Vertical Misalignment Shim icon...
- Page 10 Fixturlaser Laser Kit Next Correct the Horizontal Misalignment “ Live reading” icon Some machines move laterally when tightening the...
- Page 11 Fixturlaser Laser Kit Re-Measure Results/Save Auto save box...
- Page 12 Fixturlaser Laser Kit Fixturlaser Laser Kit Complete system: Case: Sensors M5 1-0976/S5 1-0977 Class I Bluetooth transceiver with IP 20...
-
Page 13: Declaration Of Conformity
1-0976 FIXTURLASER M5 1-0977 FIXTURLASER S5 Manufacturer’s name, address, telephone & fax no ACOEM AB - Box 7 - SE-431 21 Mölndal - Sweden comply with good engineering practice in safety matters in force within the EEA, have been applied:... - Page 14 Fixturlaser Laser Kit The Fixturlaser Laser Kit was designed to be used with the Fixturlaser Laser Kit App. View our following resources for more information. Welcome to our world...
