Harmony GENESYS Instruction Manual page 11

P R E PA R I N G C H I L D R E S T R A I N T F O R U S E
INCORRECT USE OF THE HARNESS SYSTEM IS THE MOST COMMON
MISTAKE PEOPLE MAKE. IT IS VERY IMPORTANT TO READ, UNDERSTAND
AND FOLLOW ALL INSTRUCTIONS AND WARNINGS. DO NOT MISTAKE
COMFORT FOR SAFETY. THE HARNESS SYSTEM MUST BE SNUGLY
ADJUSTED AT ALL TIMES.
A D J U S T I N G H A R N E S S S H O U L D E R S T R A P S
! ENSURE the harness height is correct for your child's size. VERIFY OFTEN
1. Loosen harness system by pushing the up-front metal harness adjuster at the front of
the seat JUST ABOVE the adjustment strap (under the fabric) and by simultaneously
pulling the chest harness straps towards you
TIP: PULL ON THE HARNESS STRAPS. DO NOT PULL ON THE SHOULDER
PADS AS THEY ARE LOCKED IN PLACE.
2. To determine what harness height is appropriate for your child, have your child sit
in the child restraint with their back flat against the backrest.
3. Reach into the opening on the top of the headrest fabric cover and find the RED
one-hand headrest height adjustment button.
4. Squeeze button and lift the headrest until the shoulder straps are at or just
above your child's shoulders
adjustments.
5. Release the button and listen for a 'click' to make sure harness is locked in place.
! WARNING: To ensure headrest is locked in position, gently push
down on headrest.
! ENSURE BOTH HARNESS STRAPS ARE PROPERLY SECURED
ON THE SPLITTER PLATE.
! WARNING: The shoulder harness must be EVEN OR SLIGHTLY
ABOVE the child's shoulders
position is below the child's shoulders, DO NOT use this child
restraint with harness.
! WARNING: DO NOT use this child restraint if the midpoint
of your child's head is above the top of the child restraint's
headrest at its maximum height
REMEMBER to check the shoulder straps position frequently
and move them to the next position when necessary. The
harness straps MUST be in the height position EVEN WITH or
just ABOVE the shoulders. The harness pads and crotch pads
are optional and are not a safety feature.
WARNING!
!
(3)
(A)
(B)
(2)
.
. The child restraint has NINE headrest height
. If the upper most harness
.
(1)
.
A
B
