YASKAWA CM057 Instruction

SMART DISTRIBUTED SYSTEM SATELLITE
This option may have been installed by the factory. However, certain steps can
only be completed at the installation site. Therefore, review and then perform
those steps which will complete the installation process.
Before installing this option, a TECHNICALLY QUALIFIED INDIVIDUAL who is
familiar with this type of equipment and the hazards involved, should READ THIS
ENTIRE INSTRUCTION SHEET.
The Smart Distributed System Satellite board is an electrostatic sensitive device.
Personnel must use approved methods for handling this type of equipment.
HAZARDOUS VOLTAGE CAN CAUSE SEVERE INJURY OR
DEATH. ENSURE ALL POWER SOURCES FEEDING DRIVE
ARE LOCKED IN THE "OFF" POSITION BEFORE INSTALLING
THIS OPTION.
INTRODUCTION
The Smart Distributed System network is a low-cost communications network used to connect industrial devices
(such as limit switches, photoelectric switches, valve manifolds, motor starters, smart motor controllers, operator
interfaces, and variable frequency drives) as well as control devices (such as programmable controllers and
computers).
The Smart Distributed System network can accommodate up to 64 nodes per network. A GPD 333 appears as
one node on the network. A Smart Distributed System Satellite board (MagneTek part no. CM057) must be
installed into each GPD 333 drive that will be communicating on the Smart Distributed System network. The
GPD 333 Smart Distributed System Satellite resides on the front of the drive in the location normally used by the
status plate or the Digital Operator. The Satellite board is powered from both the 24VDC Smart Distributed
System network power and the GPD 333 drive that it is connected to.
CHANGE RECORD
MODEL CM057
NOTE
CAUTION
CAUTION
WARNING
For GPD 333
Adjustable Frequency Drives
DWG. NO. 02Y00025-0389
SHEET NO. 1 OF 3
REL. 2/21/97 ( m - df )
