Moffat BLUE SEAL EVOLUTION G518A-B Technical Data Sheet

Technical data sheet for
GAS COOKTOPS 1200mm
G518D-B, G518D-CB, G518D-LS, G518D-RB,
G518C-B, G518C-CB, G518C-LS, G518C-RB,
G518B-B, G518B-CB, G518B-LS, G518B-RB,
G518A-B, G518A-CB, G518A-LS, G518A-RB
Heavy-duty construction
28 MJ/hr open burners
Flame failure standard
Pilot burners optional
300mm, 600mm, and 900mm griddle
plate options
Optional simmer plates
3 models of base unit
1 model of ventilated refrigeration base
with drawer/door options
Rear rollers
Stainless steel exterior
Easy clean
Easy service
Fully modular

Overall Construction

Cooktop

• Welded hob with 1.5mm 304 stainless steel bull nose
• Side panels 1.2mm 304 stainless steel
• Splashback 1.2mm 304 stainless steel
• Vitreous enamelled control panel
• Aluminised steel internal construction
• Cast iron 28MJ/hr open burners with forged brass cap
• Vitreous enamelled cast iron potstands
• Vitreous enamelled open burner spill covers
• Cast iron simmer plates (optional extra)
• 12mm thick mild steel griddle plate
• 2.5mm 304 stainless steel griddle splash guards
• Stainless steel spill trays
Griddle sections are standard on RH side. Available on LH side and
centres to order or by conversion.
Bench mount (supplied as –B model)
• Four 63mm dia. heavy-duty 1.2mm 304 stainless steel bench legs
with adjustable feet
• Adjustable height 80mm – 105mm
Cabinet base (supplied as –CB model)
• Fully modular for match suite finish
• Double skin 0.9mm 304 stainless steel interior and exterior
• Optional GN 1/1 4 position racking kit (1 or 2 cabinet bays)
• Up to eight 65mm GN 1/1 capacity
• 63mm dia. heavy-duty 1.2mm 304 stainless steel legs with two
adjustable feet at front and two rollers at rear
Leg stand (supplied as –LS model)
• Fully modular for matched suite finish
• Framed top for connection to Cooktop
• 63mm dia. heavy-duty 1.2mm 304 stainless steel legs with two
adjustable feet at front and two rollers at rear
• Fully modular framed stand shelf with 0.9mm 304 stainless
steel finish
• Shelf to top stainless steel backstop panel for convenience
and rigidity
• Suitable for rear or through shelf gas connection to Cooktop
• Quick assembly design
G518D-LS
Refrigerated Base (supplied as –RB model)
• Self contained suite matched modular base
• Ventilated system with R134a refrigerant
• -2° to + 8°C temperature (Tropical Climate rated)
• Two GN 1/1 drawers and one door standard
• 100mm deep pan drawer capacity
• Heavy-duty European telescopic drawer guides
• Magnetic drawer gaskets (replaceable without tools)
• 50mm fully foamed CFC free insulation
• 304 stainless steel exterior and interior
• Anti-corrosion treated evaporator
• No condensate drain required
• 63mm dia. heavy-duty 1.2mm 304 stainless steel legs with
adjustable feet
• Condensing unit removable through front of unit for service
• Easy clean interior

Controls

Cooktop
• Variable high to low controls to open burners
• Open burners flame failure standard with pilot burners optional
• Variable high to low controls to griddles
• Griddles standard with pilot, flame failure and piezo ignition
• Large easy use control knob - heat resistant reinforced
• Easy view control settings on knob
Refrigerated base
• Digital control electronic thermostat
• Automatic defrost
• Automatic evaporation of defrost water
• -2° to +8°C temperature range

Cleaning and Servicing

• All models with easy clean stainless steel external finish
• Lift off burner heads and vitreous enamelled burner spill covers
• Stainless steel spill trays under open burner and griddle sections
• Access to all parts from front of unit
• Refrigerated Base condenser removable through front of unit
