Moffat WALDORF RN8600G-B Technical Data Sheet

Technical data shee t for
GAS COOKTOPS 900mm
RN8600G-B, RN8600G-CB, RN8600G-LS, RN8600G-RB, RN8603G-B, RN8603G-CB, RN8603G-LS, RN8603G-RB,
RN8606G-B, RN8606G-CB, RN8606G-LS, RN8606G-RB, RN8609G-B, RN8609G-CB, RN8609G-LS, RN8609G-RB
RN8600G-LS
O verall Cons tru c tion

Cooktop

• Welded hob with 1.5mm 304 stainless steel bull nose
• Splashback and side panels 1.2mm 304 stainless steel
• Front panels 0.9mm 304 stainless steel
• Aluminised steel internal construction
• Cast iron 28MJ/hr open burners with forged brass cap
• Vitreous enamelled cast iron potstands
• Vitreous enamelled open burner spill covers
• Cast iron simmer plates (optional extra)
• 12mm thick mild steel griddle plate
• 2.5mm 304 stainless steel griddle splash guards
• Vitreous enamelled spill trays
Griddle sections are standard on RH side. Available on LH side to order
or by conversion.
Bench mount (supplied as –B model)
• Four 63mm dia. heavy-duty 1.2mm 304 stainless steel bench legs
with adjustable feet.
• Adjustable height 80mm – 105mm
Cabinet base (supplied as – CB model)
• Fully modular for match suite finish
• Double skin 0.9mm 304 stainless steel interior and exterior
• Optional GN 1/1 4 position racking kit
• 63mm dia. heavy-duty 1.2mm 304 stainless steel legs with
adjustable feet
Leg stand (supplied as –LS model)
• Fully modular for matched suite finish
• Framed top for connection to Cooktop
• 63mm dia. heavy-duty 1.2mm 304 stainless steel legs with
adjustable feet
• Fully modular framed stand shelf with 0.9mm 304 stainless steel finish
• Suitable for rear or through shelf gas connection to Cooktop
• Quick assembly design (no tools required)
Heavy-duty construction
28 MJ/hr open burners
Flame failure standard
Pilot burners optional
300mm, 600mm, and 900mm griddle
plate options
Optional simmer plates
3 models of base unit
1 model of ventilated 2 drawer refrigeration base
Stainless steel exterior
Easy clean
Easy service
Fully modular
Low back models (RNL) available
Refrigerated Base (supplied as –RB model)
• Self contained suite matched modular base
• Ventilated system with R134a refrigerant
• -2˚ to + 8˚C temperature (Tropical Climate rated)
• Two GN 1/1 drawers
• 100mm deep pan capacity
• Heavy-duty European telescopic drawer guides
• Magnetic drawer gaskets (replaceable without tools)
• 50mm fully foamed CFC free insulation
• 304 stainless steel exterior and interior
• Anti-corrosion treated evaporator
• No condensate drain required
• 63mm dia. heavy-duty 1.2mm 304 stainless steel legs with
adjustable feet
• Condensing unit removable through front of unit for service
• Easy clean interior
Con tro ls
Cooktop
• Variable high to low controls to open burners
• Open burners flame failure standard with pilot burners optional
• Variable high to low controls to griddles
• Griddles standard with pilot, flame failure and piezo ignition
• Large easy use control knob - heat resistant reinforced
• Easy view control settings on knob
Refrigerated base
• Digital control electronic thermostat
• Automatic defrost
• Automatic evaporation of defrost water
• -2˚ to +8˚C temperature range
Cl eaning and S er v icing
• All models with easy clean stainless steel external finish
• Lift off burners heads and vitreous enamelled burner spill covers
• Vitreous enamelled spill trays under open burner and griddle sections
• Access to all parts from front of unit
• Refrigerated Base condenser removable through front of unit
