Moffat Blue Seal Evolution G512C-B Technical Data Sheet
Moffat Blue Seal Evolution G512C-B Technical Data Sheet

Moffat Blue Seal Evolution G512C-B Technical Data Sheet

Blue seal evolution series gas cooktops 300mm

Advertisement

Quick Links

Technical data sheet for
GAS COOKTOPS 300mm
G512D-B, G512C-B
Heavy-duty construction
28 MJ/hr open burners
Flame failure standard
Pilot burners optional
300mm griddle plate option
Optional simmer plates
Stainless steel exterior
Easy clean
Easy service
Fully modular
G512D-B
Overall Construction
Cooktop
• Welded hob with 1.5mm 304 stainless steel bull nose
• Side panels 1.2mm 304 stainless steel
• Splashback 1.2mm 304 stainless steel
• Vitreous enamelled control panel
• Aluminised steel internal construction
• Cast iron 28MJ/hr open burners with forged brass cap
• Vitreous enamelled cast iron potstands
• Vitreous enamelled open burner spill cover
• Cast iron simmer plates (optional extra)
• 12mm thick mild steel griddle plate
• 2.5mm 304 stainless steel griddle splash guards
• Stainless steel spill trays
Bench mount (supplied as –B model)
• Four 63mm dia. heavy-duty 1.2mm 304 stainless steel bench legs
with adjustable feet
• Adjustable height 80mm – 105mm
Controls
• Variable high to low controls to open burners
• Open burners flame failure standard with pilot burners optional
• Variable high to low controls to griddles
• Griddles standard with pilot, flame failure and piezo ignition
• Large easy use control knob - heat resistant reinforced
• Easy view control settings on knob
Cleaning and Servicing
• All models with easy clean stainless steel external finish
• Lift off burner heads and vitreous enamelled burner spill covers
• Stainless steel spill trays under open burner and
griddle section
• Access to all parts from front of unit

Advertisement

loading
Need help?

Need help?

Do you have a question about the Blue Seal Evolution G512C-B and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Moffat Blue Seal Evolution G512C-B

  • Page 1 Easy clean Easy service Fully modular G512D-B Overall Construction Cooktop • Welded hob with 1.5mm 304 stainless steel bull nose • Side panels 1.2mm 304 stainless steel • Splashback 1.2mm 304 stainless steel • Vitreous enamelled control panel • Aluminised steel internal construction •...
  • Page 2 Technical data sheet for GAS COOKTOPS 300mm Specifications Burners Open Burners 28MJ/hr dual flame ring with simmer rate Griddle Burners 20MJ/hr Gas power G512D 56 MJ/hr, 15.5kW G512C 20 MJ/hr, 5.5kW Griddle Plate 300mm Griddle cooking surface 292mm x 475mm, 1387cm2 Gas connection (BSP) male All units supplied with Natural and LP gas...
