CAPACITANCE MANOMETER
CONTROLLER
MODEL GM-2001/2002
Instruction Manual
This manual is for units of the following serial
numbers:
S/N:00001 and higher.
Read this manual before operation and keep it at
hand for immediate reference.
I
No. SK00-7107-EI-003-03
Components Division,
ULVAC, Inc.
http://www.ulvac.co.jp/

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the GM-2001 and is the answer not in the manual?

Questions and answers

Related Manuals for Ulvac GM-2001

Summary of Contents for Ulvac GM-2001

  • Page 1 No. SK00-7107-EI-003-03 CAPACITANCE MANOMETER CONTROLLER MODEL GM-2001/2002 Instruction Manual This manual is for units of the following serial numbers: S/N:00001 and higher. Read this manual before operation and keep it at hand for immediate reference. Components Division, ULVAC, Inc. http://www.ulvac.co.jp/...

  • Page 2: Safety Symbols

    The copyright of this instruction manual is held by ULVAC, Inc. You are prohibited from copying any portion of this instruction manual without the consent of ULVAC Inc.

  • Page 3: Safety Precautions

    If the vacuum gauge is accidentally damaged, immediately turn off the power supply. There is a risk of fire and electric shock from use in this state. Request repairs for safety from the dealer where purchased, from ULVAC Inc., or from the URL listed in this instruction manual.
  • Page 4 If the wrong power supply is mistakenly connected, there is a risk of damage to the vacuum gauge and a risk of fire. GM-2001 supply voltage: 85 to 264 VAC. GM-2002 supply voltage: 24 VDC. CCMT-D Series scale-over display On the CCMT-D Series, a pressure value of approx.

  • Page 5: Revision History

    Revision History DATE Reason Aug 3, 2011 First edition May 7, 2012 Added display range Calculation formula added to recorder output Nov 1, 2013 Quick manual added Optional power cable added Warranty changes Added pollution certificate Dec. 6, 2019 Added product phot to cover Added Revision History Section 1.2.

  • Page 6: Table Of Contents

    Contents Prior to Use........................I Safety Symbols ......................II Safety Precautions .....................III Revision History ....................... V Contents........................VI 6.4. ISPLAY AND HANGE OF ETPOINT SPECIFICATIONS ....1 ALUE ....1 1.1. PECIFICATIONS ....15 6.4.1. Setpoint Output ..... 2 1.2. OMPONENTS 6.5.

  • Page 7: Specifications

    : 24V DC Maximum load current : 50mA (saturation voltage : 1 V) Zero correction input No-voltage contact input Input current: 10mA Power requirements GM-2001: AC85 ~ 264V 50/60Hz GM-2002: DC24V±10% Power consumption 15VA or less Operating 10 ~ 40℃ temperature range Weight 0.4 kg...

  • Page 8: Components

    CCMT-1D : 133.32 Pa F.S. (2) Sensor head cable 4, 10, 15, 20, 30, 50, 100 m 3m （only GM-2001） (3) Power cable The plug specification of supply cable is AC125V / 7A (4) Inspection certificate (5) JCSS calibration certificate...

  • Page 9: Dimensional Drawing

    1.4. Dimensional drawing Panel Cut (Control unit)

  • Page 10: Part Names And Functions

    Part Names and Functions CCMT-D Series scale-over display On the CCMT-D Series, a pressure value of approx. 1.333x10 or higher is displayed, even when scale-over. The display does not show "----". 2.1. Front Panel ②Setpoint output action display ⑤Unit of pressure display ①Operation Switch ③PV indicator ④SV indicator...

  • Page 11: Rear Panel

    Power supply terminal voltage GM-2001:85 to 264 VAC and GM-2002:24 VDC Because these terminals are applied with the above voltage, you will receive an electric shock if you touch them when the power is on.
  • Page 12 Fig. 2-2 Rear panel...

  • Page 13: Check

    Power supply terminal voltage GM-2001:85 to 264 VAC and GM-2002:24 VDC Because these terminals are applied with the above voltage, you will receive an electric shock if you touch them when the power is on.

  • Page 14: Installation

    Power supply terminal voltage GM-2001: 85 to 264 VAC GM-2002: 24 VDC Because these terminals are applied with the above voltage, you will receive an electric shock if you touch them when the power is on.

  • Page 15: Onnecting The Sensor Head Cable

    4.2. C onnecting the sensor head cable 1 8 B (1) When connecting and fastening the sensor head cable, use care not to exert undue force to the connections between the sensor head and sensor head cable and between the GM-200□ and sensor head cable.

  • Page 16: Precautions Related To Usage

    Power supply terminal voltage GM-2001:85 to 264 VAC and GM-2002: 24 VDC Because these terminals are applied with the above voltage, you will receive an electric shock if you touch them when the power is on.

  • Page 17: Operating Procedure

    O PERATING PROCEDURE 5.1. C autions in Operation 2 2 B (1) When power is applied to this instrument, measurement starts about three seconds later. However, start measurement more than 30 minutes after turning power ON until the indicated value is stabilized because there can be temperature drift or other problem for some time after power is turned ON.

  • Page 18: Setting Of Contoller

    S ETTING OF CONTOLLER 6.1. G eneal flowchart 2 3 B Pressure DATA ＋ ＋ SET ＋ SET ▲ ＋ SET push push push push Select Select Change Adjust Recorder output Pressure unit Setpoint value Recorder output This datas are stored in memory even if the power of this unit is turned off. 6.2.
  • Page 19 Sensor Head 1000 CCMT-1000A CCMT-1000D CCMT-100A CCMT-100D CCMT-10A CCMT-10D CCMT-1D 1) Lin1 output graph (Example CCMT-10A) 1000 1100 1200 1300 1400 Pressure (Pa) 　指示値（Ｐａ）　　 2) Lin2 output graph (Example CCMT-10A) Pressure (Pa) 　指示値（Ｐａ）　　...

  • Page 20: Position Of Decimal Pointput

    6.3. S etting the Unit of Pressure and position of Decimal Pointput 2 5 B The decimal point is automatically shifted The decimal point position may differ from the table above when the ✔ Note measurement mode is restored. The reason is that when the measured pressure is below 1/10 of the full scale value of the sensor head, the position of the decimal point is automatically shifted by one digit to enhance the resolution of the measurement value.

  • Page 21: Value

    (1) Pressing the [DATA] [ ►] and [SET] switches from left to right in order sets up the unit and decimal point switching mode. (“Pt” is displayed on the SV indicator.) (2) Press the [ ►] and [ ▲ ] switches to select a unit and decimal point compatible with the sensor head to be used.
  • Page 22 smaller than the setpoint value, and the condition is maintained continuously for more than 0.5 second. When the setpoint output is turned ON, the green LED displaying the setpoint output action on the front panel lights up. Use the setpoint output load within the following range. Rated voltage 24 V DC Maximum rated current...
  • Page 23 6.6. Z ero Resetting Function 2 8 B This is a function of resetting the indicated value and the recorder (analog) output to zero when resetting is made with the zero input signal or with the switch on the front panel of this instrument. It is used when making zero adjustment by lowering the pressure at the measuring point to a sufficiently low level before starting measurement.

  • Page 24: Troubleshooting

    The fuse used in this instrument does not blow out under normal conditions. If the cause is unknown (for example, the power line was struck by lightening), do not replace it by yourself, but contact your local ULVAC representative for replacement. 7.2. T he display “------” blinks.
  • Page 25 7.5. P ressure Indication is not Constant. 3 4 B Possible cause Corrective action 1) Pressure is changing 1) Normal 2) The sensor head is contaminated or 2) Replace the sensor head deteriorated. 3) Leak in the sensor head ➝ Replace it. 3) There is a leak in the neighborhood of the sensor head or area where the sensor head Leak in other area ➝...

  • Page 26: Warranty

    1) In case, special agreement or memorandum for specifications is made individually, the descriptions are prior to this article “13 Product Warranty”. 2) Buyer shall inform ULVAC when this product is exported out of Japan. In the meantime, Buyer shall take necessary procedures according to Foreign Exchange and Foreign Trade Law.

  • Page 27: China Rohs Declaration

    C hina RoHS Declaration This mark is applied to the electronic information product sold in the People's Republic of China. The figure at the center of the mark is the validity date of environmental protection. This product does not influence the environment, the human body and the property during the period reckoning the manufacturing date as long as the caution for safe use regarding the products are observed.
  • Page 28 C ertificate of Contamination...

  • Page 29: Dimensions

    Dimensions 1 0 B 11.1. U nit cable wiring diagram 3 5 B Ａ Ｂ Side A Side B PIN No. Color Purpose PIN No. Color Purpose Black Black Green -15V Green -15V Brown +15V White White Brown +15V shield Shield...
