- Page 1 Please read this manual Owner’s Manual before use Electric Tiller KS 1000T E KS 1500T E...
-
Page 2: Table Of Contents
CONTENTS 1. Introduction 4. Electric Tiller Overview 2. Main Specification 3. Packing List 5. Main overview 6. Safety Information 7. Symbols description 8. Installation 9. Operation 10. Maintenance 11. Warranty service terms EXPLANATION OF SYMBOLS: Könner & Söhnen production tiller electric 1500 model name... -
Page 3: Introduction
INTRODUCTION We are grateful to you for your purchase of ТМ Könner & Söhnen series electric triller. This manual contains safe working recommendations, operation and adjustment description of these trillers and maintenance instructions. All data, specified in this operation manual is the most up to date for the moment of its publishing. -
Page 4: Main Specification
MAIN SPECIFICATION Model KS 1000T E KS 1500T E Engine’s type electric electric Input Power 1000W 1200 W 50 Hz 50 Hz Frequency Voltage 230 V 230 V Tilling blade diameter 22 cm 22 cm Tilling Depth ≤ 22 cm ≤... -
Page 5: Main Overview
MAIN OVERVIEW KS 1000Т Е, KS 1500Т Е 1. Wheel (for model KS 1500Т Е) 6. Button of blocking 2. Engine 7. Lever of inclusion 3. Frame 8. Screws 4. Power cable 9. Blade cover 5. Handle 10. Tilling blade... -
Page 6: Safety Information
SAFETY INFORMATION Please carefully read this manual before you start working with the tiller. Do not allow strangers and children to work with the device. Do not use the device in close presence of adults, children and animals. Tiller operator is responsible for all possible injuries, threat of property and life. - Page 7 HUMAN SECURITY - Stay alert, watch what you are doing, think a step forward when working with a tiller. - Turn the device just before the operation, making sure the switch is in working condition. - Do not allow strangers to stay in the working area within a radius of 10 meters. The area must be freed from foreign objects.
-
Page 8: Symbols Description
RISK OF INJURY - Tiller can be carried out only during the day or at very good artificial light. - Never touch rotating parts, do not place arms and legs on or under moving parts. - Be careful - do not treat the soil if there is the chance of electricity wiring in it, gas or plumbing. -
Page 9: Installation
INSTALLATION 1. Using the screws that are in attachment, gather the bottom of the handle. Fastening 2. Install the attachment for the power cord, as shown in the illustration. 3. Fix the handle with the screws. Install the mounting wire on the handle as shown in the illustration. -
Page 10: Operation
OPERATION STARTING THE ENGINE To start the engine turn the device into the socket, press with a finger of one hand the lock button to lock, another should press the lever of inclusion. Release the lock button when the engine starts. IMPORTANT! The engine stops when you release the lever of inclusion. -
Page 11: Maintenance
MAINTENANCE Please perform only those work which are listed in this manual. In order to perform any other work, please, visit the authorized service center. Full list of addresses can be found on our official website ks-power.de. For the correct operation of the device it is important to replace damaged and worn parts. -
Page 12: Warranty Service Terms
WARRANTY SERVICE TERMS TERMS AND CONDITIONS: The international manufacturer warranty is 1 year. The warranty period starts from the date of purchase. In cases when warranty period is longer than 1 year according to local legislation please contact your local dealer. The Seller which sells the product is responsible for granting the warranty. - Page 13 - If there are faults caused by contamination or fouling such as contamination of the fuel, oil or cooling system. - If electrical cables or plugs show signs of mechanical or thermal damage. - In the event of foreign liquids and objects, metal chips, etc. inside the product. - If the malfunction is caused by the use of non-original spare parts and materials, oils, etc.
- Page 15 CONTACTS Germany ks-power.de info@dimaxgroup.de Poland ks-power.pl info.pl@dimaxgroup.de Ukraine ks-power.com.ua sales@ks-power.com.ua...
