Installation; Configuration - inelo TachoReader Combo Plus Manual

Operating modes
Driver card inserted, device connected neither to PC nor to tachograph
Power supply from the batteries, driver card can be downloaded.

5. Installation

The device is not supported by Windows
Required elements for PC installation
1. The device TachoReader Combo Plus;
2. The cable MINI-USB.
Installation procedure
1. Connect the device TachoReader Combo Plus to USB port via Mini USB cable and wait
®
till Windows
2. In device manager you can find the installed TachoReader Combo Plus as USB Mass
Storage Device.

6. Configuration

Files downloaded from the driver card are stored in the CARD directory, and files downloaded from the
digital tachograph are stored in the TACHO directory.
Under no circumstances should you move, delete, or rename these directories!
Before you launch the download, configure TachoReader in the following way:
1. Plug TachoReader into a USB port.
2. Start the program TachoScan/4Trans.
Menu in the 4Trans is different than shown here - refer to the 4Trans Help.
click on the appropriate icon;
select the menu option Device configuration.
The Device configuration window may be opened directly from TachoReader, by executing the file
Konfigurator.
then select the following settings:
®
2000 and earlier operating systems.
has performed the installation automatically.
