6
standard - press and hold one of the buttons below for about 2 sec. until you hear a
double beep to start downloading data at a speed of 115200.
If you select a higher baud rate in the tachograph which does not support it, the device will not proceed to
download at all or reading will be corrupted.
- downloads all the data stored in the tachograph;
- downloads the data from the tachograph according to pre-defined
configuration - see the description under:
or
- downloads data for a range of days set by pressing:
- downloads data for the last 28 days;
or
- allows to set the range of downloaded days without having to connect the
device to a PC - in the configuration window of the device, select: Custom
configuration option. In this case, the data download starts when you press
the:
in the device

4. Operating modes

Depending on the status (driver card inside / device plugged to tachograph or to PC) the
TachoReader Combo Plus runs in one of the following modes:
Device plugged to tachograph with the cable Tacho-Combo
Power supply comes from the tachograph, download from tachograph possible.
Device plugged to tachograph with the cable Tacho-Combo and driver card inserted
Power supply comes from the tachograph, download only from the card possible.
Device plugged to PC with the MINI-USB cable
Power supply comes from PC, USB mode; the device memory can be read out or written; the
data stored in the device can be transmitted into the PC software 4Trans or TachoScan.
Device plugged to PC with the MINI-USB cable and driver card inserted
Power supply comes from PC, download only from the card possible.
ul. Karpacka 24/U2b, 43-300 Bielsko-Biała • REGON 356687662 • NIP:551-23-33-463
tel. + 48 33 496 58 71, fax. +48 33 496 58 71 (111) • e-mail: biuro@inelo.pl • www.inelo.pl
button. For a description refer to the section:
".
9
INELO Stocerz Sp. J.
"Configuration ";
7
;
"Configuration directly
Operating elements
