AP508/ 512
1. Parts List
2. Power Supply Board
• M507 Schematic
• M507 PCB layout
3. Power Amp Board
• M508 Schematic
• M508 PCB layout
4. Input Channel Board
• M1054 Schematic
• M1054 PCB layout
5. Master Board
• M1055 / m1055eq Schematic
• M1055 PCB layout
6. Master i/o Board
• M1056 Schematic
• M1056 PCB layout
7. Contact Information
SERVICE MANUAL
sm-ap5xx.pdf v.2.0 11/98
Advertisement
Related Manuals for YORKVILLE AP508
Summary of Contents for YORKVILLE AP508
- Page 1 AP508/ 512 1. Parts List 2. Power Supply Board • M507 Schematic • M507 PCB layout 3. Power Amp Board • M508 Schematic • M508 PCB layout WORLD HEADQUARTERS 4. Input Channel Board • M1054 Schematic CANADA U.S.A. • M1054 PCB layout Yorkville Sound Yorkville Sound Inc.
- Page 2 AP5xxParts List 11/4/98 IMPORTANT SAFETY INSTRUCTIONS YS # Description Qty. YS # Description Qty. YS # Description Qty. 5990 GREEN 3MM LED 1V7 20MA RAD W/STOPER 5318 220N 50V 10%CAP T&R BEAD 3468 8? 3/16 SJT AC LINE CORD STRIP 17" 5991 RED 3MM LED 1V9 20MA RAD W/STOPER 5233 330N 63V 5%CAP T&R RADIAL.2"FILM 3821 HEYCO #1200 STRAIN RELIEF...
- Page 3 SHEAR PCB MECH M1056-3.20 ASSEMBLY M1056-3.20 TJH1 CHASSIS AP5xx Parts List 11/4/98 100N YS No. Description Qty. YS No. Description Qty. 4955 1/4W 8K2 5% .2"U T&R RES 3437 DPDT PUSH SW PCMT V MINI UGT 3522 249R R210 4762 1/4W 9K760 0.1% *** T&R RES 3439 SP SERIES VERTICAL MOM PCB SWITCH 4800 1/4W 10K0 1%...
- Page 4 ACTUAL PARTS MAY HAVE HIGHER VOLTAGE RATINGS. ALL UNMARKED DIODES ARE 1N4148. SERVICE WARNING: POTENTIALS CLOSE TO 130 VDC, USE CAUTION. AUDIO-PRO DATE: APR/22/97 MODELS: SCH ISSUE: 1.60 AP-5XX_SERIES_MIXER/AMPS YORKVILLE NAME: M507.SCH PCB#: M507 TITLE: SUPPLY/FAN/PCB #3892 BLK DBL/INS DO NOT STUFF...
- Page 5 R43A RIGHT V+BUSS CHANN -3/+3 V-BUSS 33078 FOR MODEL(S): 1200_SERIES_MIXERS PCB #: M1054 CHAN B/D CONFIGURATION YORKVILLE SOUND LTD DESIGN BY: PFI_&_GA DRAWN BY: DWG #: BUSS PIN NUMBER CAD FILE NAME: PCB VER: M1054-3.10 SCH ISSUE: DATE: TITLE: C:\PCAD\EXE\ M1054.SCH...
- Page 6 FOR MODEL(S): AP1212_AP1216_AP508_AP512_AP516 PCB #: M1055 YORKVILLE SOUND LTD BD238 BC560C MPSA13 LD22 LD23 DESIGN BY: PFI_&_GA DRAWN BY: DWG #: VERSION_2.0 LD21 LD20 BC550C MPSA63 MPSA17 BC264D LD18 LD19 CAD FILE NAME: PCB VER: SCH ISSUE: DATE: TITLE: DISPLAY_SELECT...
- Page 7 " ASSEMBLY M508-3.10 " PCB MECH M508-3.00 " LINEWIDTH GAUGE " " _WC1 _WC4 OUTPUT_A OUTPUT_A OUTPUT_B OUTPUT_B AMP_SIGNALS FROM_M1055 _WC2 THIS JUMPER FOR _WC3 PPW ONLY 5600U RCLIP RREF FROM_M1055 R50R RSIG #3638 D19L PART# C32R C31R D21L Q24L Q25L C31L Q25R...
- Page 8 ASSEMBLY M1054-3.10 SHEAR SHEAR PCB MECH M1054-3.10 3" BLK 22AWG NO WIRE #3638 _MW1 C14D PART# R28D R26D R44D PART# R27D #3638 R46D C19D R20D R13D 470R WC5D 14K0 R15D #4574 14K0 C18D 150R 470R C17C LD1D P10D R25D R37D 1/8W TLO72 R43D...
- Page 9 SHEAR SHEAR " 0 " LEDS " GUIDE " BLANK SIZE=14.000"X7.750" HAND MACHINE ETCH " INSERT INSERT " R109 R105 BC550 R108 R104 R172 R107 470K 10K0 R106 R175 MC14017BP LM3916 LM3916 270R TLO72 10K0 R169 R167 270R R179 BC550 BC550 R110 R182...
