- Page 1 AIR CHAMP PRODUCTS User Manual Tension Control Brake Model TCB-7 FORM NO. L-20169-D-0501...
- Page 2 In accordance with Nexen’s established policy of constant product improvement, the specifications contained in this manual are subject to change without notice. Technical data listed in this manual are based on the latest information available at the time of printing and are also subject to change without notice.
-
Page 3: Table Of Contents
TABLE OF CONTENTS Introduction ---------------------------------------------------------------------------------------------------------------------------------------- 1 Installation ---------------------------------------------------------------------------------------------------------------------------------------- 2 Air Connections --------------------------------------------------------------------------------------------------------------------------------- 3 Operation ------------------------------------------------------------------------------------------------------------------------------------------ 3 Maintenance -------------------------------------------------------------------------------------------------------------------------------------- 3 Troubleshooting---------------------------------------------------------------------------------------------------------------------------------- 4 Parts Replacement ----------------------------------------------------------------------------------------------------------------------------- 4 Replacement Parts ----------------------------------------------------------------------------------------------------------------------------- 6 Parts List ------------------------------------------------------------------------------------------------------------------------------------------- 7 Accessories --------------------------------------------------------------------------------------------------------------------------------------- 7 Warranties ----------------------------------------------------------------------------------------------------------------------------------------- 8 (iii) -
Page 4: Introduction
Accordingly, anyone who uses a procedure that is not recommended by Nexen must first satisfy themselves that neither their safety or the safety of the product will be jeopardized by the service method selected. -
Page 5: Installation
Do not flange mount the TCB-7. Flange mounting will result in damage to the TCB-7 Housing. 1. Insert the Nexen supplied Key (Item 6) into the machine shaft (See Figure 1). 2. Slide the TCB-7 onto the machine shaft (See Figure 1). -
Page 6: Air Connections
(See Figure 4). OPERATION For optimum brake operation, connect the controls as close to the TCB-7 as possible. Nexen Manufacturing recommends the installation of a filter in the Air Line ahead of the control. Never exceed the maximum operating speed of 4000 RPM. -
Page 7: Troubleshooting
TROUBLESHOOTING u l i n i t . 7 - f l a i t c r i a . e r u l i . r i u f l o i t i r F i t c r i a . - Page 8 DIAPHRAGM 1. Proceed with Steps 1 - 4 of PARTS REPLACE- MENT—FRICTION FACINGS. Cylinder (Item 11) 2. Remove the six Socket Head Cap Screws (Item 20) and Cover (Item 13) from the Cylinder (Item 11) (See Figure 8). Diaphragm (Item 14) 3.
-
Page 9: Replacement Parts
Bearing (Item 4) FIGURE 9 REPLACEMENT PARTS The item or balloon number for all Nexen products is used When ordering replacement parts, specify model for part identification on all product parts lists, product designation, item number, part description, and quantity. -
Page 10: Parts List
Per OSHA regulations, Nexen recommends using a guard that will not restrict the flow of cooling air around the unit if the unit has rotating parts. Contact your local Nexen Distributor for information about guards designed for the Nexen TCB-7. -
Page 11: Warranties
Exclusive Remedy The exclusive remedy of the Buyer for any breach of the warranties set out above will be, at the sole discretion of Nexen, a repair or replacement with new, serviceably used or reconditioned Product, or issuance of credit in the amount of the purchase price paid to Nexen by the Buyer for the Products.
