Page 5
LED Name LED Status Indication Power Router is switched on and correctly (PWR) powered. WAN port is connected. WAN port is not connected. WAN activity (transferring or receiving Blinking data). LAN port is connected. LAN port is not connected. LAN(1-4) LAN activity (transferring or receiving Blinking data).
Page 6
Interfaces Description Antenna This antenna is a 5dBi dipole antenna. LAN (1 - 4) Local Area Network (LAN) ports 1 to 4. Wide Area Network (WAN / Internet) port.
Page 7
Interfaces Description The Power socket is where you will connect the power adapter. Power Please use the power adapter provided with this Wireless Router. Connector Press this button to power ON/OFF the router. Power on/off button Reset the router to factory default settings (clear all settings). Reset Press this button and hold for 5 seconds to restore all settings to factory defaults.
