- Page 1 7” ANGLE POLISHER MODEL NO: CAT54 PART NO: 3110650 OPERATING & MAINTENANCE INSTRUCTIONS GC0814...
- Page 2 Your tool kit has been designed to give long and trouble free service. If, however, having followed the instructions in this booklet carefully, you encounter problems, take the unit to your local CLARKE dealer. GUARANTEE This product is guaranteed against faulty manufacture for a period of 12 months from the date of purchase.
-
Page 3: General Safety Rules
GENERAL SAFETY RULES CAUTION: FAILURE TO FOLLOW THESE PRECAUTIONS COULD RESULT IN PERSONAL INJURY, AND/OR DAMAGE TO PROPERTY. WORK ENVIRONMENT 1. Keep the work area clean and tidy. 2. Dress appropriately - Do not wear loose clothing or jewellery. Tie long hair out of the way. - Page 4 8. Do not carry out any alterations or modifications to the tool. 9. Always disconnect from the air supply when: • Performing any maintenance. • The tool is not in use. • The tool will be left unattended. • Moving to another work area. •...
-
Page 5: Transportation And Storage
2.7 m/s Please note that the details and specifications contained herein are correct at the time of going to print. However CLARKE International reserve the right to change specifications at any time without prior notice. Always consult the machine’s data plate. - Page 6 OVERVIEW NO DESCRIPTION NO DESCRIPTION Polishing disc Trigger Lubrication point 2 x Wrenches Regulator Side Handle Air Inlet Parts & Service: 020 8988 7400 / E-mail: Parts@clarkeinternational.com or Service@clarkeinternational.com...
-
Page 7: Compressed Air Requirements
COMPRESSED AIR REQUIREMENTS WARNING: COMPRESSED AIR CAN BE DANGEROUS. ENSURE THAT YOU ARE FAMILIAR WITH ALL PRECAUTIONS RELATING TO THE USE OF AIR COMPRESSORS AND COMPRESSED AIR SUPPLIES. • Use only clean, dry, regulated compressed air as a power source. •... -
Page 8: Before Use
Your air tool is now ready for use. You can fit a whip hose with a quick fit coupling if required (available from your Clarke dealer). FITTING THE POLISHING DISC Thread the polishing disc onto the drive spindle, followed by the arbor as shown. -
Page 9: Operating The Tool
3. Tie the string and tuck the excess back under the edge of the bonnet to avoid it becoming entangled. FITTING THE SIDE HANDLE 1. Screw the side handle into either left or right side of the tool body as required. -
Page 10: Maintenance
1. Before use, drain water from the air tank, air line and compressor. 2. Pour a few drops of CLARKE airline oil, into the air inlet. This should be carried out regardless of whether or not an in-line mini oiler is used. If an in- line mini oiler is not used, this procedure should be repeated after every two to three hours of use. -
Page 11: Service And Repair
If the tool is to be stored, or is idle for longer than 24 hours, run a few drops of Clarke air line oil into the air inlet, and run the tool for 5 seconds in order to lubricate the internal parts. -
Page 12: Troubleshooting
2. Motor parts worn. 2. Return to Clarke dealer for repair. 3. Worn or sticking 3. Drip air tool lubricating mechanism due to oil into air inlet. Allow oil lack of lubricant. -
Page 13: Parts List
PARTS LIST Part No Description No Part No Description AP-70001 Main Shaft Casing HD-12001 Motor Housing AP-70002 Main Shaft AP-70030 Bushing BB-62011 Ball Bearing VP-70035 Valve Stem AP-70004 Bevel Pinion DG-40058 O-Ring AP-70005 Bearing Support VP-70037 Valve Spring AP-70006 Arbor AP-70034 Air Regulator BB-62032... -
Page 14: Parts Diagram
PARTS DIAGRAM Parts & Service: 020 8988 7400 / E-mail: Parts@clarkeinternational.com or Service@clarkeinternational.com... -
Page 15: Declaration Of Conformity
DECLARATION OF CONFORMITY Parts & Service: 020 8988 7400 / E-mail: Parts@clarkeinternational.com or Service@clarkeinternational.com...
