United states stove company solid fuel warm air furnace owners manual model 1537q
Hide thumbs
Table of Contents

Advertisement

Quick Links

Model 1537Q
SOLID FUEL WARM AIR FURNACE
Owners Manual
TM
*FOR PARALLEL INSTALLATION WITH AN
EXISTING FORCED AIR, GAS OR OIL
FIRED FURNACE (U.S. ONLY)
*FOR INSTALLATION AS A CENTRAL FURNACE
Improper Installation May
CAUTION:
Void Your Warranty
Read All Instructions Carefully Before
Starting the Installation or Operating the
Save This Manual For
Furnace.
Future Reference
DO NOT USE THIS FURNACE IN A MOBILE HOME OR TRAILER
UNITED STATES STOVE COMPANY
WARNOCK HERSEY
S
C
U
S
227 Industrial Park Road
P.O.Box 151
South Pittsburg, TN 37380
R
(423) 837-2100
851239B
10/98
