Summary of Contents for Ultrawave Q Series
-
Page 2: Table Of Contents
Warranty ......................30 Temperatures of touchable hot surfaces ............31 Compliance with the Control of Noise at Work Regulations ......32 Service record ....................33 Notes ........................36 Ultrawave baths are manufactured in the United Kingdom and conform to exacting international standards. -
Page 3: Safety Instructions & General Use
The user should familiarise themselves with this Operator Instruction manual before operating the equipment and should apply to Ultrawave or its agent for advice on cleaning techniques or detergents. Ultrawave will not be responsible for damage or injury caused by incorrect use of the equipment. -
Page 4: Installation
Installation The following parts and accessories are included with the Q-Series ultrasonic bath: 1 x Q-Series ultrasonic bath 1 x basket 1 x lid 1 x memory card 1 x memory card to USB card reader 1 x 2m length of drain hose 1 x hose tail 1 x Ultraclean detergent sample How to install? -
Page 5: Quick Guide
Quick guide Pour cold water into the bath so that it submerses the level sensor (Do not overfill). Add the required dose of detergent (see page 21). In order to save the cycle data to the memory card, ensure that the memory card is installed in the port prior to Fluid level sensor turning the machine on (see page 19). -
Page 6: Controls
Controls Ensure your Q-Series ultrasonic bath is plugged into a 220-240 VAC fully earthed supply. Once plugged in, switch on your Q-Series bath via the power on/off switch at the rear of the unit. The switch will then illuminate. The Q-Series is operated through a menu driven control system: KEY 3 KEY 4 KEY 2... -
Page 7: Operating Instructions
Operating instructions When the Q-Series power is turned on and the bath is full of liquid, the following screens will display alternately. When the water temperature is at or above the temperature set, the message “Temp OK” will display. The actual temperature in the bath will vary and will be different to the value shown in the screen above. - Page 8 When the Q-Series power is turned on and the liquid level is too low, the following screen will display. When the bath is filled with liquid to the correct level, you will be given the option to degas. (The need for degassing is explained on page 24). You will need to degas the liquid to ensure good cleaning efficacy.
-
Page 9: Operator Menu
Operator menu A number of the Q-Series cleaning parameters can be altered. To access the options menu and scroll through the various changeable parameters, press the MENU key, when the following screen is displayed. To scroll through the menu, press the MENU key. To exit the MENU at any time, press the ... - Page 10 Screen 1: Setting the temperature Your Q-Series is fitted with a thermostat and heaters to ensure the temperature of the cleaning fluid is maintained at the set temperature. Use the UP and DOWN keys to accurately set the desired temperature of the cleaning fluid between 1°C and 70°C.
- Page 11 Screen 2: Setting the cycle time Your Q-Series ultrasonic bath is factory preset with a cycle time of 15 minutes. Use this screen to amend the cycle time. Use the UP and DOWN keys to scroll through the numbers in order to increase or decrease the time.
- Page 12 Screen 4: Degas As well as the automatic degas function that you are offered when the machine is first turned on, this menu function allows you to run a degas cycle whenever a cleaning cycle is initiated. Use the ON and OFF keys to select the required option. (See page 26 for the importance of degassing.) If you turn the degas function ON, your Q-Series ultrasonic bath will run a degas cycle every time the cycle start key is depressed.
- Page 13 Screen 5: Frequency Leap Your Q-Series ultrasonic bath is equipped with Frequency LEAP technology to provide more homogeneous ultrasonic cleaning activity throughout the whole tank. Using advanced software and generators, the Q-Series uses Frequency LEAP to create a pseudo-random leaping action between a wider frequency range, reducing standing waves and improving the cleaning action.
-
Page 14: Starting The Cycle
Starting the cycle Once all the Operator Menu options have been selected, the following screen will display. Q-Series is now ready for use. Press the key to begin the cleaning cycle. When the Q-Series is in operation, the following screen will display. (This screen is only an example. -
Page 15: Advanced Menu
Advanced menu The Advanced Menu allows different settings to be specified which may not require regular changes and also allows the usage history of the individual Q-Series ultrasonic bath to be seen. To access the advanced menu, press and hold Keys 3 and 4 together. The following screen will then appear: KEY 3 KEY 4... - Page 16 Screen 2: Time used This screen shows the total time your Q-Series ultrasonic bath has been in use in days, hours and minutes; i.e. the sum of all the cleaning cycle times since new. For example, the screen above shows that the bath has been in use for a total of 2 days, 5 hours and 27 minutes.
- Page 17 Screen 4: Cycle Count The second screen shows the number of cycles which the Q-Series ultrasonic bath has run since new. The cycle count shows all cycles which the bath has begun and includes those cycles which are not completed; i.e. those cycles aborted by the operator or because the fluid level was low.
- Page 18 Screen 6: Fluid level sensor Q-Series ultrasonic bath is fitted with a fluid level sensor to ensure it is not under-filled prior to or during the cycle. This ensures that the optimum cleaning process can occur and potential damage to the tank is minimised. The level sensor is a resistive device, so will not detect fluids with very low conductivity such as pure deionised (DI) water.
- Page 19 Screen 7: Portable appliance testing Q-Series ultrasonic bath is provided with this screen to make portable appliance testing easier. When the ON button is pressed, both the heater and the ultrasonic generator will turn on, irrespective of any other programmed settings. You will then be sure that the Q-Series ultrasonic bath is operating in the mode required for accurate portable appliance testing.
-
Page 20: Using The Memory Card
The information is saved as a CSV file. This is automatically saved as Ultrawave.xls on the memory card and will open in Microsoft Excel. information saved... -
Page 21: Recording The Data
There is a file on the memory card which is already set up to provide a template for recording the data – Ultrawave.xls. Open this file and the data will display in spreadsheet format. -
Page 22: Ultrasonic Cleaning Detergents
Each of these detergents is available from Ultrawave. The required detergent dose may vary depending on the component being cleaned and the level of contamination. Ultrawave recommend a dosage of between 2 and 5% for all detergents other than Sonozyme. -
Page 23: Specifications
Specifications Tank Basket Working Unit external Tank internal capacity internal capacity dimensions dimensions max. dimensions (litres) (mm) (mm) (litres) (mm) 2.75 285x185x265 240x140x100 220x125x40 3.75 285x185x265 240x140x150 215x120x90 345x200x265 300x150x150 273x125x90 QS10 10.5 550x180x265 500x140x150 460x110x90 QS12 12.5 345x285x365 295x245x200 265x215x140 QS18 17.5... - Page 24 Operating Heater Total Power Ultrasonic Heating Mains Freq. Range consumption power power voltage (KHz) (°C) (Vac) 220- 32 to 38 0-80 220- 32 to 38 0-80 220- 32 to 38 0-80 220- QS10 32 to 38 0-80 220- QS12 32 to 38 0-80 220- QS18...
-
Page 25: Technical Information
The time needed to degas the liquid varies depending on the amount of gas present in the liquid and the quantity of water in the tank. Ultrawave recommends a degas period of at least 10 minutes. -
Page 26: Troubleshooting
Troubleshooting Ultrawave have a dedicated service team who are able to resolve any problems that occur with your Q-Series . However, on many occasions it is possible that the problem can be rectified by the operator. The unit fails to turn on... -
Page 27: Cycle Abort Modes
Cycle abort modes If the cycle is aborted, the reason for the failure will be displayed. If the operator aborts the cycle, the following screen will be displayed. If the Level sensor is set to ON (see page 19), and the fluid drops below the required level during operation, the cleaning cycle will stop and the following screen will be displayed. -
Page 28: Maintenance
Portable Appliance Testing should be conducted with water in the bath. Service Ultrawave recommend that your Q-Series ultrasonic bath is serviced and tested by an Ultrawave approved engineer on an annual basis. More regular periodic testing can be done by the operator to ensure that your ultrasonic bath is operating at optimum efficiency. -
Page 29: Returning Equipment To Ultrawave
However, on rare occasions, it is possible that products may not meet the expectations of our customers. Should this occur, we aim to address and rectify any problems you may have with Ultrawave products quickly and effectively. Troubleshooting and Problem Solving Sometimes it is possible to rectify any issues over the telephone. -
Page 30: Warranty
12 months of the date of sale, or 2000 hours usage (whichever comes first) because of faulty material or manufacture. Genuine defective items returned to Ultrawave or its agent’s premises will be replaced or repaired free of charge at their discretion. -
Page 31: Temperatures Of Touchable Hot Surfaces
(see below). Your Ultrawave ultrasonic bath can be set so that the cleaning fluid is up to 70°C. This means that parts of ultrasonic bath will be above the recommended maximum temperature. -
Page 32: Compliance With The Control Of Noise At Work Regulations
To help you calculate your workers’ exposure, Ultrawave publish the noise generated by your ultrasonic cleaner on the Certificate of Test. The figure is that experienced by a worker standing in the operating position. -
Page 33: Service Record
Q-Series ultrasonic bath is serviced at least once every 12 months. This record must be maintained by the engineer conducting the service. There are no user serviceable parts inside. All service and repair should be referred to qualified Ultrawave engineers only. Date Cycle count Engineer... - Page 34 Date Cycle count Engineer Details Next service due Date Cycle count Engineer Details Next service due Date Cycle count Engineer Details Next service due Date Cycle count Engineer Details Next service due Date Cycle count Engineer Details Next service due...
- Page 35 Date Cycle count Engineer Details Next service due Date Cycle count Engineer Details Next service due Date Cycle count Engineer Details Next service due Date Cycle count Engineer Details Next service due Date Cycle count Engineer Details Next service due Date Cycle count Engineer...
-
Page 36: Notes
Notes _______________________________________________ _______________________________________________ _______________________________________________ _______________________________________________ _______________________________________________ _______________________________________________ _______________________________________________ _______________________________________________ _______________________________________________ _______________________________________________ _______________________________________________ _______________________________________________ _______________________________________________ _______________________________________________ _______________________________________________ _______________________________________________ _______________________________________________ _______________________________________________ _______________________________________________ _______________________________________________ _______________________________________________ _______________________________________________ _______________________________________________ _______________________________________________ _______________________________________________ _______________________________________________ _______________________________________________ _______________________________________________ _______________________________________________ _______________________________________________ _______________________________________________ _______________________________________________ _______________________________________________... - Page 37 Notes _______________________________________________ _______________________________________________ _______________________________________________ _______________________________________________ _______________________________________________ _______________________________________________ _______________________________________________ _______________________________________________ _______________________________________________ _______________________________________________ _______________________________________________ _______________________________________________ _______________________________________________ _______________________________________________ _______________________________________________ _______________________________________________ _______________________________________________ _______________________________________________ _______________________________________________ _______________________________________________ _______________________________________________ _______________________________________________ _______________________________________________ _______________________________________________ _______________________________________________ _______________________________________________ _______________________________________________ _______________________________________________ _______________________________________________ _______________________________________________ _______________________________________________ _______________________________________________ _______________________________________________...
