National Instruments SCXI-1332 Installation Instructions Manual

INSTALLATION INSTRUCTIONS
NI SCXI -1332
Terminal Block for the NI SCXI-1127/1128
Conventions
»
bold
™
This guide describes how to install and connect signals to the
National Instruments SCXI-1332 terminal block to configure the
SCXI-1127/1128 switch module as a 4 × 8, 2-wire matrix.
Screw terminals on the SCXI-1332 allow you to access the 4 × 8 matrix.
The SCXI-1332 also contains terminals for connecting rows and columns
between modules using expansion cables.
Refer to the NI Switches Getting Started Guide to determine when to install
the terminal block. Visit
switching solutions.
The following conventions are used in this guide:
The » symbol leads you through nested menu items and dialog box options
to a final action. The sequence File»Page Setup»Options directs you to
pull down the File menu, select the Page Setup item, and select Options
from the last dialog box.
This icon denotes a note, which alerts you to important information.
This icon denotes a caution, which advises you of precautions to take to
avoid injury, data loss, or a system crash. When this symbol is marked on a
product, refer to the Read Me First: Safety and Radio-Frequency
Interference document for information about precautions to take.
Bold text denotes items that you must select or click in the software, such
as menu items and dialog box options. Bold text also denotes parameter
names.
for information on other
ni.com/switches
