INSTALLATION GUIDE
SCXI -1381K T
™
Introduction
What You Need to Get Started
™
National Instruments , and ni.com
are trademarks or trade names of their respective companies.
321927B-01 © Copyright 1998, 2001 National Instruments Corp. All rights reserved.
ERMINAL
This guide explains how to assemble your SCXI-1381K terminal block
housing kit and includes dimensions for designing your circuit boards.
The SCXI-1381K is intended for developers of custom SCXI terminal
blocks who design and lay out custom circuit boards for terminal blocks.
The SCXI-1381K terminal block housing kit includes the unassembled
components you need to build a custom SCXI terminal block. Your kit
contains all the following mechanical components of an SCXI terminal
block:
• The metal enclosure
• Front and back panels
• Connectors, not including the circuit board
• A 96-position, right-angle DIN connector for attaching to your custom
circuit board, if needed
To use your SCXI-1381K to build a custom SCXI terminal block, you need
the following:
❑
SCXI-1381K terminal block housing kit, containing the following:
– SCXI-1381K Terminal Block Housing Kit Installation Guide
– Terminal block base
– Terminal block cover
– Strain-relief bar
– Two self-adhesive rubber foam strips
– Two 6–32 by 5/8 in. screws
– One number 4 eyelet solder-lock terminal
– One 4–40 by 1/4 in. panhead screw
™ ™
, and SCXI are trademarks of National Instruments Corporation. Product and company names mentioned herein
B H
LOCK OUSING
K
IT
February 2001
