Getting started
Please connect the Power Supply unit to mains
power close to the desired location of the terminal.
Connect the Power supply cable to the port shown
and if Using Ethernet or PSTN, please connect the
cables to the Ports shown.
Once the Base and any additional cabling is connected, allow the device to power up.
This will take approximately 4 minutes.
If using an Ethernet connection, the terminal should obtain a valid IP address and
connection automatically once connected to an Active Ethernet Port.
The Ethernet symbol on the top of the Terminal Display should turn Green to indicate a
Valid IP connection
If the Ethernet Symbol remains white, please check the connection to the Terminal and
your Router to ensure the cables are connected correctly.
To confirm your terminal is connected and ready to accept Payments, perform a
connection test using the following steps
1. Press the Menu Button
2. Select option "Connection Test"
3. Terminal Will Print a receipt with "Connection OK" printed near the top.
4. Your terminal is now ready to use
Please consult your Quick reference guide provided for instructions on performing
transactions.
