Quick Start Guide
Move/3500 BT/WiFi
GETTING STARTED
Set up your base unit in a convenient location close to a power
source and an Ethernet socket.
To connect the Ethernet cable, connect one side to your
Ethernet socket or router and the other side to the socket
located on the rear of your base unit.
To connect the power lead to your base, remove the back panel
as shown in the diagram. Connect the right-angle adaptor and
push it firmly into the socket.
Connectivity
The Move/3500 is a Multi-Comms terminal meaning you can
connect via WiFi or Bluetooth to Ethernet base
The terminal will attempt to use all the available options.
It will start with WiFi as first preference. If that is unavailable
or fails it will move to the Bluetooth/Ethernet connection
All of this operates seamlessly in the background and will not
need any intervention beyond the initial set up.
Function Keys
Virtual Function Keys: These appear on the Touchscreen
interface when they may be used as to select options in
terminal menus.
Menu key: To enter the application menus press the Menu
key from the idle screen. Pressing the key again moves
to the next menu (if available).
Correction keys: When entering numbers or letters, the
yellow key deletes one character at a time; while the red
key deletes the entire line (this key also cancels
transactions).
Confirmation key: The green key
anything that has been typed into the terminal.
Paper feed key: To test the feeding of the paper through the
printer press and hold the paper feed key .
is used to confirm
Connecting the base unit
Serial connection ports
Power socket
USB connection ports
Ethernet socket Cable compartment
SIM 2 or SAM 3
connector
SAM 1 connector
Paper feed key
Menu key
Cancel key
Clear key
Enter key
