  • Page 1 PTZA6 Series Pan-Tilt-Zoom Domes Installation Manual Aigis Mechtronics, Inc. 1124 Louise Road, Winston-Salem, NC 27282 Ph (336)785-7740 Fax (336)785-7744 www.aigismech.com Page 1...
  • Page 2: Table Of Contents

    Table of Contents Important Safeguards........... 3 1.1. Warnings............. 3 1.2. Environmental Specifications....... 3 1.3. Lightning-Proof Requirements ......3 1.4. Lightning and Surge Proofing ....... 4 1.5. Water Proofing............ 4 Installation ..............4 2.1. Before You Start..........4 2.2. Materials Required..........4 Bracket Installation............
  • Page 3: Important Safeguards

    Ensure any lift equipment used employs proper safety • features. Important Safeguards Cut off power to the unit before servicing. • 1.1. Warnings Do not exceed 30VAC on 24 volt models. Operation • above 30VAC violates low voltage operation (Class 2) Read this manual fully before attempting installation.
  • Page 4: Lightning And Surge Proofing

    1.4. Lightning and Surge Proofing 1.5. Water Proofing This product uses TVS Lightning Proof technology which can Outdoor domes are IP66 rated which indicates they are prevent damage to the equipment caused by lightning strickes dustproof, waterproof, and moisture proof. Do not install an below 1500W and impulse signals such as surge;...
  • Page 5: Bracket Installation

    Run the power, video, and data (alarm optional) cables 3.2. Bracket Installation through the back of the wall mount and down through the Select an appropriate mounting location such that a safety threaded hole in the arm (see Figure 4). Leave enough length factor of 4 can be achieved.
  • Page 6: Corner Bracket Installation

    01 Power/video/data cables 02 Ceiling Flange 03 Customer supplied 1.5” NPT pipe shown attached to Ceiling Flange and Adapter Figure 5 – Pendant Mount 04 Wall anchors Hole Pattern 05 Set screws Figure 6 – Apply RTV Sealant Figure 7 – Pendant Mount Corner Bracket Installation 3.2.3.
  • Page 7: Pole Bracket Installation

    01 Cables 02 Wall Mount 03 Corner Bracket 04 M8 x 30mm screw 05 M8 Wall Anchor 06 RTV Sealant Figure 10 – Corner Bracket and Wall Mount Figure 9 – Rear of Corner Bracket Pole Bracket Installation 3.2.4. Apply RTV sealant around the edge of the wall mount as shown in Figure 11.
  • Page 8: Wiring And Installing The Dome Cover

    3.3. Wiring and Installing the Dome Video Cable Connection Cover P rotective Cover The 4-position and 12-position terminal blocks are supplied in the packaging of the PTZ dome. The BNC connector is not supplied. Make the required connections based on the diagram in Figure 13.
  • Page 9: Pan/Tilt Module Installation

    Hold the dome bubble up to the mounted PTZ unit. If installing an outdoor unit, connect the heater ring in the dome bubble to the main unit be connecting the heater connectors (see Figure 21). Metal Button Figure 18 – Apply power and check LED 3.4.
  • Page 10: Recess Mount Installation

    Recess Mount Installation Tightening Cap Indoor recess-mount domes can be mounted in drop ceilings (a.k.a. ceiling tiles, acoustic ceiling tiles, etc.) or sheetrock ceilings. A typical installation is shown in Figure 23. The ceiling must be able to support 4 times the weight of the PTZ. Figure 23 –...
  • Page 11 Before closing the access panel, set the dip switches (see Figure 16) to select the desired Camera ID, Protocol, and Baud rate. Refer to the appendix of the Operation Manual for dip When the housing flange is flush with the ceiling, twist the switch information.
  • Page 12: Ptz Module Installation

    G u id e n o tc h e s 4.2. PTZ Module Installation AMP Socket Remove the pan/tilt module from the packaging and inspect it for damage. If the unit needs to be returned to the factory, replace it properly in its packaging as shown in Figure 33. Lo c kin g flan ge s L o ckin g clip s Figure 34 –...
