PCB ASSY - CONTROL (44115-0970) continued/...
Part Number Description
23685-0007 CAP 100NK 160V P/P MKP4 P10
25021-0901 DIO 1N4148 B/R
25061-0200 LED - T1 ROUND (3mm) - RED
25061-0519 DISPLAY 3 DIG .56 LED 9MM LEG
25061-0520 DISPLAY 4 DIG .56 LED 9MM LEG
25115-0907 DIO 1N4002 B/R
25117-0020 DIO 1N5401
25336-5590 TRAN PNP BC559C
25377-5490 TRAN NPN BC549C
27106-0506 IC LM324N 14 PIN
27106-0646 IC LF347 BI-FET OP AMP
27161-0120 IC V/REF ZRA245(ZR404) 2.45V
27164-0507 IC ULN-2003A
27226-0520 IC 4052B
27226-0530 IC 4053B
27231-5740 IC 74HC574
27250-2001 IC MCU8 PIC16C55A-04/P ROM
28502-0010 RESONATOR CER 4MHZ
35555-2910 PCB - CONTROL
MECHANICAL ITEMS
Part Number Description
10232-0425 SLEEVING H/SHR 19MM BR RED
20030-0263 WASHER M3 ZPST
20030-0264 WASHER M2.5 ZPST
20030-0266 WASHER M4 ZPST
20037-0247 WASHER 4BA SHK/PROOF I/T ZPST
20037-0301 WASHER M3 SHK/PROOF I/T ZPST
20037-0305 WASHER 5/16in.SHK/PRF I/T ZPST
20037-0401 SOLDER TAG SHAKEPROOF - 4BA
20038-9502 WASHER M4 SPRING
20062-9501 SCREW No.6x3/4in RAISED CKHDPZ
20063-0010 SCREW NO6 X 3/8 NIB HDPZ ST/AB
20065-0020 SCREW 2-28 X 5/16PLAS PNHDPZ
Position
C2,102
D1,2,3,4,5,7,8,9,11,12,13,101,102,103,104,
105,107,108,109,113
LED1,2,101,102
DIS1,2,102
DIS101
D114,115
D10,110
Q1,101
Q2,102
IC7,107
IC5,105
D6,106
IC1,101
IC4,104
IC2,8,102,108
IC6,106
IC3,103
XTAL1,101
Position
FERRITE SLEEVES
CONTROL PCB TO GROUND, STANDOFFS,
BRACKET TO MOULDING
CONTROL PCB
EARTH
EARTH TERMINAL
CHASSIS TO MAIN PCB SPACERS, GROUND
STANDOFFS
GREY TERMINAL
EARTH
EARTH
HANDLE TO COVER ,
HANDLE TO L BRACKET
COVER TO CHASSIS,
FRONT PANEL TO CHASSIS
CONTROL PCB & L BRACKET TO MOULDING
