IAC INDUSTRIES LT Series Assembly Instructions Manual

Frame

Advertisement

Quick Links

INDUSTRIES
LTXX FRAME ASSEMBLY
IAC INDUSTRIES
3831 S BULLARD AVE., GOODYEAR, AZ 85338
Phone (714) 990-8997 Fax (714) 990-0557
www.iacindustries.com
Assembly Instructions
REV. (042318P65)

Advertisement

loading

Summary of Contents for IAC INDUSTRIES LT Series

  • Page 1 INDUSTRIES LTXX FRAME ASSEMBLY IAC INDUSTRIES 3831 S BULLARD AVE., GOODYEAR, AZ 85338 Phone (714) 990-8997 Fax (714) 990-0557 www.iacindustries.com Assembly Instructions REV. (042318P65)
  • Page 2: Attention Notes

    If you believe there are parts missing from your order please contact IAC Industries customer service HOTLINE at 800-989-1422. WARNING: ALL PARTICLE BOARD USED IN IAC INDUSTRIES PRODUCTS ARE SOURCED ONLY FROM VENDORS THAT ARE CARB ATCM PHASE 2 AND TSCA TITLE VI COMPLIANT WITH VALID CERTIFICATES Drilling, Sawing, Sanding or Machining Wood products can expose you to wood dust, a substance known to the state of California to cause cancer.
  • Page 3: Pre-Assembly Check List

    Your bench has been carefully packed at the factory to prevent damage during shipment. Unpack all parts and examine them for damage. Contact your freight carrier for freight claims information if your order was shipped "freight collect" or "pre-pay and add". Contact IAC Industries at 800 989-1422 if parts are missing. HARDWARE KIT HWR7006: HARDWARE KIT COMPONENTS: 900044 BOLT, 5/16-18 X .750 HHW BLACK (8)
  • Page 4: Tools Needed

    TOOLS NEEDED: Power or hand held Phillips head screwdriver with #2 tip, 7/16" and 1/2" combination wrench or thin wall sockets. LAB TABLE FRAME ASSEMBLY FOR LAMINATE OR HARDWOOD WORKSURFACES Step 1: Attach beam connector plates to the ends of the bench support beams using the 5/16-18 x .75 hex head bolts and 1/4 flat washers supplied as shown.
  • Page 5 Step 3: Align the workbench pedestals over the ends of the support beams and lower them down over the beam connector plates so that the plates are on the inside of the pedestal tubing. Align the slots in the pedestal support beam over the inserts in the worksurface and thread the 1/4-20 x .75 hex head bolts with the 1/4 flat washers into the inserts.
  • Page 6 LAB TABLE FRAME ASSEMBLY FOR EPOXY OR TRESPA WORKSURFACES Step 1: Attach beam connector plates to the ends of the bench support beams using the 5/16-18 x .75 hex head bolts and 1/4 flat washers supplied as shown. NOTE: DO NOT TIGHTEN THE HARDWARE. Place the support beams with the attached connector plates, open side toward the center, on a smooth flat surface being sure to protect them from damage by foreign objects.
  • Page 7 Step 3: LEG EXTENDER/FIXED HEIGHT PEDESTALS Slide the lab table frame leg extender into the pedestal leg tube making sure the black plastic insert at the end of the leg extender is exposed. Align the threads of the leg extender with the holes in the pedestal leg tube and select the desired height of the bench frame.
  • Page 8 CAUTION: Epoxy and Trespa table tops are heavy and can be very heavy depending on the overall size. Be sure there are enough people lifting the table tops during the installation process to avoid injury. IAC Lab frames a table tops are designed to have the following overhangs: For 24”...
