• Mobile Phone: 080-8884-0111.
• Fax: 045-263-9296.
• Email: kharukawa@intrepidcs.com
Korea Office
In Korea, use the following contact information:
• Phone: +82 31 782 1805.
• Fax: +82 31 782 1808.
• Email: jchung@intrepidcs.com
China Office
Intrepid's Shanghai office can also be reached by phone, fax or email:
• Phone: 021-51330254.
• Fax: 021-51330271.
• Email: icschina@intrepidcs.com
India Office
In India, please use this contact information:
• Phone: +91 +97 66 44 55 33.
• Email: sbhagwat@intrepidcs.com
Australia Office
Our Australian office can be reached as follows:
• Phone: 03 9466 4948 (international callers: +61 3 9466 4948).
• Email: icsaustralia@intrepidcs.com
11

Reference: Frame Wrapping and Wrapper Format

In the overview (Section 3) we mentioned that the RAD-Star encloses each message received
on its BroadR-Reach ports in a special wrapper frame before it is retransmitted to the
conventional Ethernet network. The wrapper allows additional timestamp information to be sent
with the message, enables the FCS field of the original frame to be captured, and ensures that
error frames are not discarded.
