Related Manuals for Braun No touch + forehead
Summary of Contents for Braun No touch + forehead
- Page 1 No touch + forehead thermometer NTF 3000...
- Page 3 O visite nuestro sitio web: www.braunthermometers.com Por favor asegúrese de especificar el número de modelo. Este producto es fabricado bajo licencia de la marca registrada ‘Braun’. ‘Braun’ es una marca registrada de Braun GmbH, Kronberg, Alemania. © 2016 Todos los derechos reservados.
-
Page 4: Warnings And Precautions
Thank you for purchasing the Braun No touch + forehead thermometer (NTF 3000). This thermometer is a high quality product incorporating the latest technology and tested in accordance with international standards. With its unique technology, the product can provide a stable, accurate reading with each measurement. - Page 5 This thermometer is intended for household use only. Use of this thermometer is not intended as a substitute for consultation with your physician. Temperature elevation may signal a serious illness, especially in newborns and infants, or in adults who are old, frail, or have a weakened immune system .
-
Page 6: Product Description
Product description Power button Silent mode switch Temperature button Battery door LCD display Guidance light Scanner Protective cap... - Page 7 The Braun No touch + forehead thermometer is non-invasive. A measurement can be taken even while a child is sleeping. The Braun No touch + forehead thermometer is less threatening to a child than a rectal thermometer and easier to use than other methods.
- Page 8 How does Braun No touch + forehead work? The Braun No touch + forehead thermometer measures infrared energy radiated from the skin at the center of the forehead area. This captured energy (which is twice as much thermal energy compared to a traditional...
- Page 9 How to use your Braun No touch + forehead Remove cap Power on Press and release the power button once. Backlight will come on and the start up sequence starts. Ready When the device is ready and correctly positioned, a horizontal line of dashes (“---”) will appear on the screen.
- Page 10 Take temperature Press the temperature button (you can press and hold the button or press and release it). When the device is placed correctly, the screen 0 - 2” displays a dashed line animation while it takes a (0-6 cm) reading.
-
Page 11: Temperature Taking Hints
Temperature taking hints It is important to know each individual’s normal temperature when they are well. This is the only way to accurately diagnose a fever. To determine normal temperature, take multiple readings when healthy. Re-measure with a standard digital thermometer for confirmation. This thermometer displays an oral equivalent temperature reading. -
Page 12: Changing The Temperature Scale
Fahrenheit Celsius Changing the sound mode The Braun No touch + forehead thermometer allows you to silence the beeps on the thermometer to avoid waking a sleeping child. To use this feature, slide the switch to the silent mode position and take a temperature reading. -
Page 13: Care And Cleaning
Clean sensor mirror before each use or as needed. Replacing the batteries The Braun No touch + forehead thermometer comes with 2 AA batteries. Replace with 2 new AA batteries when the flashing battery symbol appears on the LCD display. To change the batteries, slide open the battery cover and remove batteries. -
Page 14: Errors And Troubleshooting
Errors and troubleshooting Error Message Situation Solution When 20% of battery Replace battery. life is left, the display flashes the low battery warning symbol. The device can still work until the battery life has 0% left. If the steady battery Replace battery. -
Page 15: Limited Three Year Warranty
MOTOR HOUSING YOURSELF, DOING SO MAY VOID YOUR WARRANTY AND CAUSE DAMAGE TO THE PRODUCT OR PERSONAL INJURY. Product specification Type: No touch + forehead thermometer (NTF 3000) Measuring range: 93.9 °F (34.4 °C) – 108 °F (42.2 °C) Resolution: 0.1 °F (0.1°C) - Page 16 Long term storage ranges Storage/transport temperature: –13 °F to 140 °F (–25 °C to 60 °C) Humidity: 15–95% non condensing Battery: (2) AA Batteries - at least 1000 measurements Pressure: 700-1060hPA (0.7-1.06 atm) This infrared thermometer meets requirements established in ASTM Standard E 1965-98 for the thermometer system.
- Page 17 P/N: 31IMNTF3190R1 07JUN16...
Need help?
Do you have a question about the No touch + forehead and is the answer not in the manual?
Questions and answers
how to make braun no touch SET for adult reading (not pediatric)
To set up the Braun No Touch thermometer for adult readings:
1. Remove the cap.
2. Press and release the power button once to turn it on. The backlight will activate, and the startup sequence will begin.
3. Wait for the screen to display a horizontal line of dashes (“---”), indicating the device is ready.
4. Position the device on or up to 2 inches (5 cm) away from the center of the forehead, just between the eyebrows.
5. For no-touch readings, use the yellow guidance light to aim correctly.
The thermometer does not require a specific setting for adults; it is safe and accurate for all age groups.
This answer is automatically generated
My thermometer was working during the day but at night when room is cooler I'm getting the ERR red light error message?
The Braun No Touch + Forehead thermometer may show an ERR red light error message at night when the room is cooler because the backlight remains off when the measured temperature is below 34.4°C (93.9°F). If the room is too cool, the thermometer may register a low temperature reading, triggering an error.
This answer is automatically generated
