  • Page 1 IMB-1216 User Manual Version 1.0 Published August 2019 Copyright©2019 ASRockind INC. All rights reserved.
  • Page 2 Version 1.0 Published August 2019 Copyright©2019 ASRockind INC. All rights reserved. Copyright Notice: No part of this documentation may be reproduced, transcribed, transmitted, or translated in any language, in any form or by any means, except duplication of documentation by the purchaser for backup purpose, without written consent of ASRockind Inc.
  • Page 3 ® The terms HDMI and HDMI High-Definition Multimedia Interface, and the HDMI logo are trademarks or registered trademarks of HDMI Licensing LLC in the United States and other countries. CAUTION: RISK OF EXPLOSION IF BATTERY IS REPLACED BY AN INCORRECT TYPE. DISPOSE OF USED BATTERIES ACCORDING TO THE INSTRUCTIONS.

  • Page 4: Table Of Contents

    Contents 1 Introduction ............5 1.1 Package Contents ............5 1.2 Specifications ..............6 1.3 Motherboard Layout ............8 1.4 I/O Panel ................ 10 2 Installation ............11 2.1 Screw Holes ..............11 2.2 Pre-installation Precautions ........... 11 2.3 Installation of Memory Modules (SO-DIMM) ....12 2.4 Expansion Slots ............

  • Page 5: Introduction

    Chapter 1: Introduction Thank you for purchasing ASRockind IMB-1216 motherboard, a reliable mother- board produced under ASRockind’s consistently stringent quality control. It delivers excellent performance with robust design conforming to ASRockind’s commitment to quality and endurance. In this manual, chapter 1 and 2 contain introduction of the motherboard and step- by-step guide to the hardware installation.

  • Page 6: Specifications

    1.2 Specifications Form Dimensions Mini-ITX (6.7-in x 6.7-in) Factor ® Intel 8th Gen (Whiskey lake-U) Core™ MCP Processors Processor IMB-1216V (i3-8145UE, DC, 2.2GHz, 15 W) System IMB-1216M (i5-8365UE, QC, 1.6GHz, 15 W) IMB-1216P (i7-8665UE, QC, 1.7GHz, 15 W) Chipset PCIe Mini PCIe 1 x M.2 (Key E, 2230) with PCIe x1, CNVI and USB2.0 for Wireless...
  • Page 7 HDMI DisplayPort 1 x DP1.2++ Rear I/O Ethernet 4 x USB3.1 Audio 2 (Mic-in, Line-out) Serial PS/2 3 x USB2.0, 1 x USB3.1 TypeA LVDS/ inverter 1 (shared with LVDS) 1 x Header (shared with DP) 2 x COM (RS232/422/485), 4 x COM (RS- Serial 232) Internal...

  • Page 8: Motherboard Layout

    LAN1 M2_SEL2 BIOS M2M_1 LAN2 M2E_1 DDR4_A1 M2_B1 USB 3.0 T: USB0 DDR4_B1 B: USB1 USB3_PWR0_1 SIM1 USB3_PWR2_3 USB 3.0 IMB-1216 Industrial T: USB2 B: USB3 PANEL1 Line Out BUZZ2 BAT1 AUDIO CODEC CLRMOS1 Mic In COM2 COM4 COM6 BUZZ1...
  • Page 9 1 : 4-Pin ATX Power Connector (Input +12V~28V) 2 : 2-pin UPS Module Power Input Connector 3 : USB Power Setting Jumpers (USB2_PWR5_6_7 (For USB2_5_6 and USB2_7)) (USB3_PWR4 (For USB3_4)) 4 : USB2.0 Headers (USB2_5_6, USB2_7) 5 : Vertical Type A USB3.0 (USB3_4) 6 : SATA3 Connectors (SATA3_1, SATA3_2) 7 : SATA Power Output Connector 8 : 4-Pin CPU FAN Connector (+12V)

  • Page 10: I/O Panel

    1.4 I/O Panel DC Jack (DC_JACK1) USB 3.1 Ports (USB3_0_1) HDMI Port (HDMI1) USB 3.1 Ports (USB3_2_3) DisplayPort (DISPLAY1) Line out (Lime) LAN RJ-45 Port* Microphone (Pink) LAN RJ-45 Port* * There are two LED next to the LAN port. Please refer to the table below for the LAN port LED indications.

  • Page 11: Installation

    Chapter 2: Installation This is a Mini-ITX form factor (6.7” x 6.7”, 17.0 x 17.0 cm) motherboard. Before you install the motherboard, study the configuration of your chassis to ensure that the motherboard fits into it. Make sure to unplug the power cord before installing or removing the motherboard.

  • Page 12: Installation Of Memory Modules (So-Dimm)

    2.3 Installation of Memory Modules (SO-DIMM) IMB-1216 provides two 260-pin DDR4 (Double Data Rate 4) SO-DIMM slots. Step 1. Align a SO-DIMM on the slot such that the notch on the SO-DIMM matches the break on the slot. 1. The SO-DIMM only fits in one correct orientation. It will cause permanent damage to the motherboard and the SO-DIMM if you force the SO-DIMM into the slot at incorrect orientation.

  • Page 13: Expansion Slots

    2.4 Expansion Slots (SIM and M.2 Sockets) There is 1 SIM socket and 3 M.2 sockets on this motherboard. SIM socket: 1 x SIM Socket connected to M.2 Key B. M.2 sockets: 1 x M.2 (Key E, 2230) with PCIe x1, CNVI and USB2.0 for Wireless. 1 x M.2 (Key M, 2242/2260/2280) with PCIe x4 or SATA3 for SSD.

  • Page 14: Jumpers Setup

    2.5 Jumpers Setup The illustration shows how jumpers are setup. When the jumper cap is placed on pins, the jumper is “Short”. If no jumper cap is placed on pins, the jumper is “Open”. The illustration shows a 3-pin jumper whose pin1 and pin2 are “Short”...
  • Page 15 Backlight Control Level (CON_LBKLT_CTL) 1-2 : eDP Control 2-3 : CH7511B Control (3-pin BLT_PWM1) (see p.8, No. 16) Backlight Power Select (LCD_BLT_VCC) 1-2 : LCD_BLT_VCC : +5V 2-3 : LCD_BLT_VCC : +12V (5-pin BKT_PWR1) 4-5 : LCD_BLT_VCC : DC_IN (see p.8, No. 15) Panel Power Select (LCD_VCC) Use this to set up the VDD power of the LVDS connector.
  • Page 16 M.2 Select (For Key-M) Open : M.2 PCIe Short : M.2 SATA (2-pin M2_SEL2) (see p.8, No. 38) BL1, BL2 Open : Protect LCD_BLT_VCC (2-pin BL1) Short : No Protect LCD_BLT_VCC (see p.8 No. 12) Open : Protect R_LVDD (2-pin BL2) Short : No Protect R_LVDD (see p.8 No.

  • Page 17: Onboard Headers And Connectors

    2.6 Onboard Headers and Connectors Onboard headers and connectors are NOT jumpers. Do NOT place jumper caps over these headers and connectors. Placing jumper caps over the headers and connectors will cause permanent damage of the motherboard! CPU Fan Connector Please connect the CPU fan cable to the connector and (4-pin CPU_FAN1)
  • Page 18 System Panel Header This header accommodates several system front panel (9-pin PANEL1) RESET# functions. PWRBTN# (see p.8, No. 20) PLED- HDLED- PLED+ HDLED+ Connect the power switch, reset switch and system status indicator on the chassis to this header according to the pin assignments below. Note the positive and negative pins before connecting the cables.
  • Page 19 USB 2.0 Headers There are two headers on this USB_PWR motherboard. (9-pin USB2_5_6, USB2_7: DUMMY (see p.8, No. 4) USB_PWR LPC Header This connector supports a Trusted Platform Module (TPM) (19-pin LPC1) system, which can see p.8, No. 25) securely store keys, digital certificates, passwords, and data.
  • Page 20 ATX Power Connector Please connect a DC +12V~28V power supply to this (4-pin FROM_UPS1) connector. (see p.8 No. 1) 1-2: GND 3-4: DC Input (+12V~28V) UPS Module Power Input Connector Pin1 : GND Pin2 : DC Input (2-pin TO_UPS1) (see p.8 No. 2) Vettical Type A USB3.0 (USB3_4) (see p.8 No.
  • Page 21 LVDS Connector Signal Name Signal Name LCD_VCC LCD_VCC (40-pin LVDS1) LDDC_CLK +3.3V LVDS_A_DATA0# LDDC_DATA (see p.8 No. 11) LVDS_A_DATA0 LVDS_A_DATA1 LVDS_A_DATA1# LVDS_A_DATA2# LVDS_A_DATA2 LVDS_A_DATA3 LVDS_A_DATA3# LVDS_A_CLK# LVDS_A_CLK LVDS_B_DATA0 LVDS_B_DATA0# LVDS_B_DATA1# LVDS_B_DATA1 LVDS_B_DATA2 LVDS_B_DATA2# LVDS_B_DATA3# DPLVDD_EN LVDS_B_DATA3 LVDS_B_CLK LVDS_B_CLK# CON_LBKLT_EN LCD_BLT_VCC CON_LBKLT_CTL LCD_BLT_VCC LCD_BLT_VCC...
  • Page 22 Backlight Power Connector Signal Name LCD_BLT_VCC (6-pin BLT_PWR1) LCD_BLT_VCC (see p.8, No. 13) CON_LBKLT_EN CON_LBKLT_CTL Backlight Volume Control Signal Name (7-pin BLT_VOL1) (see p.8, No. 14) BLT_DW BLT_UP PWRDN GPIO_VOL_DW GPIO_VOL_UP 3W Audio AMP Output Wafer (4-pin SPEAKER1) (see p.8 No. 29) Signal Signal Signal...

  • Page 23: Uefi Setup Utility

    Chapter 3: UEFI SETUP UTILITY 3.1 Introduction This section explains how to use the UEFI SETUP UTILITY to configure your system. The UEFI chip on the motherboard stores the UEFI SETUP UTILITY. You may run the UEFI SETUP UTILITY when you start up the computer. Please press <F2>...

  • Page 24: Navigation Keys

    3.1.2 Navigation Keys Please check the following table for the function description of each navigation key. Navigation Key(s) Function Description Moves cursor left or right to select Screens Moves cursor up or down to select items + / - To change option for the selected items <Enter>...

  • Page 25: Advanced Screen

    3.3 Advanced Screen In this section, you may set the configurations for the following items: CPU Configu- ration, Chipset Configuration, Storage Configuration, Super IO Configuration, AMT Configuration, ACPI Configuration, USB Configuration and Trusted Computing. Setting wrong values in this section may cause the system to malfunction.

  • Page 26: Cpu Configuration

    3.3.1 CPU Configuration Intel Hyper Threading Technology To enable this feature, a computer system with an Intel processor that sup- ports Hyper-Threading technology and an operating system that includes ® ® optimization for this technology, such as Microsoft Windows 7 / 8 / 8.1 / ®...
  • Page 27 Intel Turbo Boost Technology Use this item to enable or disable Intel Turbo Boost Mode Technology. Turbo Boost Mode allows processor cores to run faster than marked fre- quency in specific conditions. The default value is [Enabled]. CPU Thermal Throttling You may select [Enabled] to enable CPU internal thermal control mechanism to keep the CPU from overheating.

  • Page 28: Chipset Configuration

    3.3.2 Chipset Configuration VT-d ® ® Use this to enable or disable Intel VT-d technology (Intel Virtualization Technology for Directed I/O). The default value of this feature is [Disabled]. Share Memory Configure the size of memory that is allocated to the integrated graphics processor when the system boots up.
  • Page 29 Onboard VGA/DP Select onboard VGA/DP. The default value is [DP]. Onboard LAN1 This allows you to enable or disable the Onboard LAN1 feature. Onboard LAN2 This allows you to enable or disable the Onboard LAN2 feature. Onboard HD Audio Select [Auto], [Enabled] or [Disabled] for the onboard HD Audio feature. If you select [Auto], the onboard HD Audio will be disabled when PCI Sound Card is plugged.

  • Page 30: Storage Configuration

    3.3.3 Storage Configuration SATA Controller(s) Use this item to enable or disable the SATA Controller feature. SATA Mode Selection Use this to select SATA mode. The default value is [AHCI Mode]. AHCI (Advanced Host Controller Interface) supports NCQ and other new features that will improve SATA disk perfor- mance but IDE mode does not have these advantages.

  • Page 31: Super Io Configuration

    3.3.5 Super IO Configuration COM1 Use this to set parameters of COM1. Type Select Use this to select COM1 port type: [RS232], [RS422] or [RS485]. COM2 Use this to set parameters of COM2. Type Select Use this to select COM2 port type: [RS232], [RS422] or [RS485]. COM3 Use this to set parameters of COM3.

  • Page 32: Amt Configuration

    3.3.6 AMT Configuration (For IMB-1216M/P Only) AMT BIOS Features Use this to enable or disable Intel(R) Active Management Technology BIOS Extension. The default is [Enabled]. ASF support Use this to enable or disable Alert Specification Format. The default is [En- abled].
  • Page 33 WatchDog Use this to enable or disable AMT WatchDog Timer. The default is [Dis- abled]. Activate Remote Assistance Process Trigger CIRA boot. The default is [Disabled]. PET Progress User can enable or disable PET Events progress to receive PET events or not.

  • Page 34: Acpi Configuration

    3.3.7 ACPI Configuration Suspend to RAM Use this item to select whether to auto-detect or disable the Suspend-to- RAM feature. Select [Auto] will enable this feature if the OS supports it. Onboard LAN Power On Use this item to enable or disable onboard LAN to turn on the system from the power-soft-off mode.

  • Page 35: Usb Configuration

    3.3.8 USB Configuration Legacy USB Support Use this option to select legacy support for USB devices. There are two configuration options: [Enabled] and [UEFI Setup Only]. The default value is [Enabled]. Please refer to below descriptions for the details of these two options: [Enabled] - Enables support for legacy USB.

  • Page 36: Trusted Computing

    3.3.9 Trusted Computing Security Device Support Enable or disable BIOS support for security device. Onboard TPM (For IMB-1216M/P Only) Use this to enable or disable onboard TPM. The default value is [Enabled].

  • Page 37: Hardware Health Event Monitoring Screen

    3.4 Hardware Health Event Monitoring Screen In this section, it allows you to monitor the status of the hardware on your system, including the parameters of the CPU temperature, motherboard temperature, CPU fan speed, chassis fan speed, and the critical voltage. CHA_FAN1 Setting This allows you to set Chassis fan 1’s speed.

  • Page 38: Security Screen

    3.5 Security Screen In this section, you may set, change or clear the supervisor/user password for the system. Supervisor Password Set or change the password for the administrator account. Only the ad- ministrator has authority to change the settings in the UEFI Setup Utility. Leave it blank and press enter to remove the password.

  • Page 39: Boot Screen

    3.6 Boot Screen In this section, it will display the available devices on your system for you to config- ure the boot settings and the boot priority. Boot From Onboard LAN Use this item to enable or disable the Boot From Onboard LAN feature. Setup Prompt Timeout This shows the number of seconds to wait for setup activation key.
  • Page 40 CSM (Compatibility Support Module) Enable to launch the Compatibility Support Module. Please do not disable unless you’re running a WHCK test. If you are using Windows 8.1 64-bit and all of your devices support UEFI, you may also disable CSM for faster boot speed.

  • Page 41: Exit Screen

    3.7 Exit Screen Save Changes and Exit When you select this option, it will pop-out the following message, “Save configuration changes and exit setup?” Select [OK] to save the changes and exit the UEFI SETUP UTILITY. Discard Changes and Exit When you select this option, it will pop-out the following message, “Discard changes and exit setup?”...

  • Page 42: Software Support

    Chapter 4: Software Support 4.1 Install Operating System ® ® This motherboard supports various Microsoft Windows operating systems: 10 / 10 64-bit / 8.1 / 8.1 64-bit / 8 / 8 64-bit / 7 / 7 64-bit. Because motherboard settings and hardware options vary, use the setup procedures in this chapter for general refer- ence only.
