- Page 1 IMB-1211-D R2 IMB-1211-L R2 IMB-1210-D R2 IMB-1210-L R2 User Manual Version 1.0 Published May 2018 Copyright©2018 ASRockInd INC. All rights reserved.
- Page 2 Version 1.0 Published May 2018 Copyright©2018 ASRockInd INC. All rights reserved. Copyright Notice: No part of this documentation may be reproduced, transcribed, transmitted, or translated in any language, in any form or by any means, except duplication of documentation by the purchaser for backup purpose, without written consent of ASRockInd Inc.
- Page 3 CAUTION: RISK OF EXPLOSION IF BATTERY IS REPLACED BY AN INCORRECT TYPE. DISPOSE OF USED BATTERIES ACCORDING TO THE INSTRUCTIONS.
-
Page 4: Table Of Contents
Contents 1 Introduction ............5 1.1 Package Contents ............5 1.2 Specifications ..............6 1.3 Motherboard Layout ............14 1.4 I/O Panel ................ 16 2 Installation ............20 2.1 Screw Holes ..............20 2.2 Pre-installation Precautions ........... 20 2.3 Installation of Memory Modules (SO-DIMM) ....21 2.4 Expansion Slots ............ -
Page 5: Introduction
Chapter 1: Introduction Thank you for purchasing ASRockInd IMB-1211-D R2 / IMB-1211-L R2 / IMB- 1210-D R2 / IMB-1210-L R2 motherboard, a reliable motherboard produced under ASRockInd’s consistently stringent quality control. It delivers excellent performance with robust design conforming to ASRockInd’s commitment to quality and endur- ance. -
Page 6: Specifications
1.2 Specifications IMB-1211-D R2: Form Dimensions Mini-ITX (6.7-in x 6.7-in) Factor ® Socket LGA 1151 for 8th Intel Core i7/i5/i3/ Celeron (Supports up to 65W) Processor * The Performance of CPUs over 65W will be System limited due to power design. - Page 7 HDMI DisplayPort 3 Ethernet Rear I/O 4 x USB support USB3.1 Audio 2 (Mic-in, Line-out) Serial 2 x COM(RS-232/422/485) 4 x USB 2.0 LVDS/ inverter Serial 3 x COM(RS-232) Internal SATA 4 x SATA3 (6.0Gb/s) Connector GPIO 4 x GPI, 4 x GPO SATA PWR Output Speaker...
- Page 8 IMB-1211-L R2: Form Dimensions Mini-ITX (6.7-in x 6.7-in) Factor ® Socket LGA 1151 for 8th Intel Core i7/i5/i3/ Celeron (Supports up to 65W) Processor * The Performance of CPUs over 65W will be System limited due to power design. ® Chipset Intel Q370...
- Page 9 HDMI DisplayPort 2 Ethernet Rear I/O 4 x USB support USB3.1 Audio 2 (Mic-in, Line-out) Serial 2 x COM(RS-232/422/485) 4 x USB 2.0 LVDS/ inverter Serial 3 x COM(RS-232) Internal SATA 4 x SATA3 (6.0Gb/s) Connector GPIO 4 x GPI, 4 x GPO SATA PWR Output Speaker...
- Page 10 IMB-1210-D R2: Form Dimensions Mini-ITX (6.7-in x 6.7-in) Factor ® Socket LGA 1151 for 8th Intel Core i7/i5/i3/ Celeron (Supports up to 65W) Processor * The Performance of CPUs over 65W will be System limited due to power design. ® Chipset Intel H310...
- Page 11 HDMI DisplayPort 3 Ethernet Rear I/O 4 x USB support USB3.1 Audio 2 (Mic-in, Line-out) 1 x COM(RS-232/422/485), 1 x COM (RS- Serial 232) 4 x USB 2.0 LVDS/ inverter Serial 2 x COM(RS-232) Internal 4 x SATA3 (6.0Gb/s), one is shared with M.2 SATA Connector Key M...
- Page 12 IMB-1210-L R2: Form Dimensions Mini-ITX (6.7-in x 6.7-in) Factor ® Socket LGA 1151 for 8th Intel Core i7/i5/i3/ Celeron (Supports up to 65W) Processor * The Performance of CPUs over 65W will be System limited due to power design. ® Chipset Intel H310...
- Page 13 HDMI DisplayPort 2 Ethernet Rear I/O 4 x USB support USB3.1 Audio 2 (Mic-in, Line-out) 1 x COM(RS-232/422/485), 1 x COM (RS- Serial 232) 4 x USB 2.0 LVDS/ inverter Serial 2 x COM(RS-232) Internal 4 x SATA3 (6.0Gb/s), one is shared with M.2 SATA Connector Key M...
-
Page 14: Motherboard Layout
1.3 Motherboard Layout... - Page 15 4 : Inverter Power Control Wafer (BLT_PWR1) 5* : LVDS Panel Connector (For IMB-1210-L R2 / IMB-1211-L R2 only) * eDP Connector (For IMB-1210-D R2 / IMB-1211-D R2 only) (on the Backside of PCB) 6 : BL2 7 : Buzzer...
-
Page 16: I/O Panel
1.4 I/O Panel IMB-1211-D R2: COM Port (COM3) (RS232/422/485)* USB 3.0 Ports (USB3_3_4) (Only +5VSB) DisplayPort (DP1) USB 3.0 Ports (USB3_1_2) LAN RJ-45 Port** DisplayPort (DP3) LAN RJ-45 Port** DisplayPort (DP2) Line out (Lime) COM Port (COM4) (RS232/422/485)* Microphone (Pink) * This motherboard supports RS232/422/485 on COM3, 4 ports. - Page 17 IMB-1211-L R2: COM Port (COM3) (RS232/422/485)* USB 3.0 Ports (USB3_3_4) (Only +5VSB) DisplayPort (DP1) USB 3.0 Ports (USB3_1_2) LAN RJ-45 Port** D-Sub Port (VGA1) LAN RJ-45 Port** DisplayPort (DP2) Line out (Lime) COM Port (COM4) (RS232/422/485)* Microphone (Pink) * This motherboard supports RS232/422/485 on COM3, 4 ports. Please refer to below table for the pin definition.
- Page 18 IMB-1210-D R2: COM Port (COM3) (RS232/422/485)* USB 3.0 Ports (USB3_3_4) (Only +5VSB) DisplayPort (DP1) USB 3.0 Ports (USB3_1_2) LAN RJ-45 Port** DisplayPort (DP3) LAN RJ-45 Port** DisplayPort (DP2) Line out (Lime) COM Port (COM4) (RS232)* Microphone (Pink) * This motherboard supports RS232/422/485 on COM3 port. Please refer to below table for the pin definition.
- Page 19 IMB-1210-L R2: COM Port (COM3) (RS232/422/485)* USB 3.0 Ports (USB3_3_4) (Only +5VSB) DisplayPort (DP1) USB 3.0 Ports (USB3_1_2) LAN RJ-45 Port** D-Sub Port (VGA1) LAN RJ-45 Port** DisplayPort (DP2) Line out (Lime) COM Port (COM4) (RS232)* Microphone (Pink) * This motherboard supports RS232/422/485 on COM3 port. Please refer to below table for the pin definition.
-
Page 20: Installation
Chapter 2: Installation This is a Mini-ITX form factor (6.7” x 6.7”, 17.0 x 17.0 cm) motherboard. Before you install the motherboard, study the configuration of your chassis to ensure that the motherboard fits into it. Make sure to unplug the power cord before installing or removing the motherboard. -
Page 21: Installation Of Memory Modules (So-Dimm)
2.3 Installation of Memory Modules (SO-DIMM) This motherboard provides two 260-pin DDR4 (Double Data Rate 4) SO-DIMM slots. 1. The SO-DIMM only fits in one correct orientation. It will cause permanent damage to the motherboard and the SO-DIMM if you force the SO-DIMM into the slot at incorrect orientation. -
Page 23: Expansion Slots
2.4 Expansion Slots There is 1 mini-PCIe slot, 2 M.2 sockets and 1 PCI Express slot on this mother- board. mini-PCIe slot: MINI_PCIE1 (mini-PCIe slot; half/full size) is used for PCI Express mini cards. M.2 sockets: 1 x M.2 (M2_2) (Key E, 2230) with PCIe x1, CNVI and USB2.0 for Wireless. - Page 24 M.2 Key-E Socket (M2_1): M.2 Key-M Socket (M2_2): * IMB-1211-D R2: Switch between SATA and PCIe mode. IMB-1210-L R2: SATA mode only. * M2_2 and SATA3_1 share lanes. If either one of them is in use, the other one will be disabled.
-
Page 25: Jumpers Setup
2.5 Jumpers Setup The illustration shows how jumpers are setup. When the jumper cap is placed on pins, the jumper is “Short”. If no jumper cap is placed on pins, the jumper is “Open”. The illus- tration shows a 3-pin jumper whose pin1 and pin2 are “Short”... - Page 26 1-2 : +5V 2-3 : +12V (3-pin PWR_COM1 (For COM Port1), PWR_COM2 (For COM Port2), PWR_COM5 (For COM Port5) (PWR_COM5 is for IMB-1211-D R2 / IMB-1211-L R2 only)) (see p.14, No. 19) BL1, BL2 Open : Protect LCD_BLT_VCC (2-pin BL1) Short : No Protect LCD_BLT_VCC (see p.14 No.
- Page 27 M.2 Select (For IMB-1210-D R2 / IMB-1210-L R2 only) Open : For SATA3_1 Close : For M.2 (2-pin M2_SEL1) (see p.14, No. 25) * M2_2 and SATA3_1 share lanes. If either one of them is in use, the other one will be disabled.
-
Page 28: Onboard Headers And Connectors
2.6 Onboard Headers and Connectors Onboard headers and connectors are NOT jumpers. Do NOT place jumper caps over these headers and connectors. Placing jumper caps over the headers and connectors will cause permanent damage of the motherboard! CPU Fan Connector Please connect the CPU fan cable to the connector and (4-pin CPU_FAN1) - Page 29 COM1, 2, 5 Headers (10-pin COM1, 2, 5: see p.14, No. 10) (COM5 is for IMB-1211-D R2 / IMB-1211-L R2 only) (COM1, COM2, COM5 support RS232 only) Signal Signal...
- Page 30 SATA3 Connectors These four Serial ATA3 (SATA3) SATA3_4 SATA3_1 connectors support SATA data (SATA3_1~4: see p.14, No. 28) cables for internal storage devices. The current SATA3 SATA3_2 SATA3_3 interface allows up to 6.0 Gb/s data transfer rate. * M2_2 and SATA3_1 share lanes. If either one of them is in use, the other one will be disabled.
- Page 31 (40-pin LVDS1) (see p.14 No. 5) * PD (Panel Detection): Connect this pin to LVDS Panel’s Ground pin to detect Panel detection. eDP Connector (For IMB-1210-D R2 / IMB-1211-D R2 only) (on the Backside of PCB) EDP1 (40-pin EDP1) Buzzer (2-pin BUZZ2) (see p.14 No.
- Page 32 Chassis Intrusion Headers This motherboard supports CASE OPEN detection feature (2-pin CI1, CI2: see p.14, No. 20) Signal that detects if the chassis cover has been removed. This feature requires a chassis with chassis intrusion detection design. CI1 : Close : Active Case Open Open : Normal CI2 : Close : Normal...
-
Page 33: Uefi Setup Utility
Chapter 3: UEFI SETUP UTILITY 3.1 Introduction This section explains how to use the UEFI SETUP UTILITY to configure your system. The UEFI chip on the motherboard stores the UEFI SETUP UTILITY. You may run the UEFI SETUP UTILITY when you start up the computer. Please press <F2>... -
Page 34: Navigation Keys
3.1.2 Navigation Keys Please check the following table for the function description of each navigation key. Navigation Key(s) Function Description Moves cursor left or right to select Screens Moves cursor up or down to select items + / - To change option for the selected items <Enter>... -
Page 35: Advanced Screen
3.3 Advanced Screen In this section, you may set the configurations for the following items: CPU Configu- ration, Chipset Configuration, Storage Configuration, Super IO Configuration, AMT Configuration(Q370 only), ACPI Configuration, USB Configuration and Trusted Computing. Setting wrong values in this section may cause the system to malfunction. -
Page 36: Cpu Configuration
3.3.1 CPU Configuration Intel Hyper Threading Technology Intel Hyper Threading Technology allows multiple threads to run on each core, so that the overall performance on threaded software is improved. Active Processor Cores Select the number of cores to enable in each processor package. CPU C States Support Enable CPU C States Support for power saving. - Page 37 Intel Turbo Boost Technology Use this item to enable or disable Intel Turbo Boost Mode Technology. Turbo Boost Mode allows processor cores to run faster than marked fre- quency in specific conditions. The default value is [Enabled]. CPU Thermal Throttling You may select [Enabled] to enable CPU internal thermal control mechanism to keep the CPU from overheating.
-
Page 38: Chipset Configuration
3.3.2 Chipset Configuration Primary Graphics Adapter This allows you to select [Onboard] or [PCI Express] as the boot graphic adapter priority. The default value is [PCI Express]. Above 4G Decoding Enable or disable 64bit capable Devices to be decoded in Above 4G Ad- dress Space (only if the system supports 64 bit PCI decoding). - Page 39 Panel Type Selection (IMB-1210-L R2 and IMB-1211-L R2 only) Use this to select panel type. This item appears when you enable Active LVDS. The default values of Active LVDS and Panel Type Selec- tion will be changed only when the users manually adjust them.
-
Page 40: Storage Configuration
3.3.3 Storage Configuration SATA Controller(s) Use this item to enable or disable the SATA Controller feature. SATA Mode Selection Use this to select SATA mode. The default value is [AHCI Mode]. AHCI (Advanced Host Controller Interface) supports NCQ and other new features that will improve SATA disk perfor- mance. -
Page 41: Super Io Configuration
3.3.4 Super IO Configuration COM1 Configuration Use this to set parameters of COM1. COM2 Configuration Use this to set parameters of COM2. COM3 Configuration Use this to set parameters of COM3. Select COM3 port type: [RS232], [RS422] or [RS485]. COM4 Configuration Use this to set parameters of COM4. -
Page 42: Amt Configuration
3.3.5 AMT Technology (Q370 only) AMT BIOS Features Use this to enable or disable Intel(R) Active Management Technology BIOS Extension. The default is [Enabled]. ASF support Use this to enable or disable Alert Specification Format. The default is [En- abled]. USB Provisioning of AMT Use this to enable or disable AMT USB Provisioning. - Page 43 WatchDog Use this to enable or disable AMT WatchDog Timer. The default is [Dis- abled]. Activate Remote Assistance Process Trigger CIRA boot. The default is [Disabled]. PET Progress User can enable or disable PET Events progress to receive PET events or not.
-
Page 44: Acpi Configuration
3.3.6 ACPI Configuration Suspend to RAM Use this item to select whether to auto-detect or disable the Suspend-to- RAM feature. Select [Auto] will enable this feature if the OS supports it. PCIE Devices Power On Use this item to enable or disable PCIE devices to turn on the system from the power-soft-off mode. -
Page 45: Usb Configuration
3.3.7 USB Configuration Legacy USB Support Use this option to select legacy support for USB devices. There are two configuration options: [Enabled] and [UEFI Setup Only]. The default value is [Enabled]. Please refer to below descriptions for the details of these four options: [Enabled] - Enables support for legacy USB. -
Page 46: Trusted Computing
3.3.8 Trusted Computing Security Device Support Enable or disable BIOS support for security device. Onboard TPM (Q370 only) Use this to enable or disable onboard TPM. The default is [Enabled]. -
Page 47: Hardware Health Event Monitoring Screen
3.4 Hardware Health Event Monitoring Screen In this section, it allows you to monitor the status of the hardware on your system, including the parameters of the CPU temperature, motherboard temperature, CPU fan speed, chassis fan speed, and the critical voltage. CPU_FAN1 Setting This allows you to set CPU fan 1’s speed. -
Page 48: Security Screen
3.5 Security Screen In this section, you may set, change or clear the supervisor/user password for the system. Supervisor Password Set or change the password for the administrator account. Only the ad- ministrator has authority to change the settings in the UEFI Setup Utility. Leave it blank and press enter to remove the password. -
Page 49: Boot Screen
3.6 Boot Screen In this section, it will display the available devices on your system for you to config- ure the boot settings and the boot priority. Boot From Onboard LAN Use this item to enable or disable the Boot From Onboard LAN feature. Setup Prompt Timeout This shows the number of seconds to wait for setup activation key. - Page 50 CSM (Compatibility Support Module) Use this to enable or disable Compatibility Support Module. The default value is [Disabled]. Launch PXE OpROM Policy Select UEFI only to run those that support UEFI option ROM only. Select Legacy only to run those that support legacy option ROM only. Select Do not launch to not execute both legacy and UEFI option ROM.
-
Page 51: Exit Screen
3.7 Exit Screen Save Changes and Exit When you select this option, it will pop-out the following message, “Save configuration changes and exit setup?” Select [OK] to save the changes and exit the UEFI SETUP UTILITY. Discard Changes and Exit When you select this option, it will pop-out the following message, “Discard changes and exit setup?”... -
Page 52: Software Support
Chapter 4: Software Support 4.1 Install Operating System ® ® This motherboard supports various Microsoft Windows operating systems: 10 64- bit. Because motherboard settings and hardware options vary, use the setup proce- dures in this chapter for general reference only. Refer your OS documentation for more information.
