  • Page 1 USB Dongleserver dongleserver ProMAX Quick Installation Guide MHAB-QI-dsProMAX Version: 1.0 | 2019-12...
  • Page 3 Overview This 'Quick Installation Guide' describes the hardware installation and initial setup of the dongleserver ProMAX.  Table of contents Do you need assistance? Contact us! Monday to Thursday 8:00 a.m. to 4:45 p.m. and Friday 8:00 a.m. to 3:15 p.m. (CET) +49 (0)521 94226-44 support@seh.de...
  • Page 4: Table Of Contents

    Getting Started: SEH UTN Manager ........10...
  • Page 5: General Information

    TCP/IP network. For this purpose, the USB dongles will be connected to the USB ports of the dongleserver ProMAX. Then the UTN (UTN = USB to Network) functionality and the corresponding software tool 'SEH UTN Manager' establish a virtual USB connection between USB dongle and client.
  • Page 6: Accessories

    Accessories Value-adding accessories for your dongleserver ProMAX are optionally available from SEH. dongleserver ProMAX plus The ‘dongleserver ProMAX Service package' plus Service Package extends the manufacturer's guarantee of your dongleserver ProMAX from 36 to 60 months. In addition, you will receive quickly and easily an advance replacement device in case of a defect.
  • Page 7: Technical Data

    Technical Data network connector 1 network connector 2 (RJ-45) (RJ-45) (at the rear side) (at the rear side) connector for connector for power supply 1 power supply 2 (at the rear side) (at the rear side) USB ports 1-20 with LED for the USB port link LED (green) activity LED...
  • Page 8 Properties Values Dimensions Width: 422 mm Height: 44 mm Depth: 243 mm Weight: 2950 g (with housing cover) WARNING Do not operate all USB ports with maximum load! The USB ports are grouped: Group 1 = 1–5 Group 2 = 6–10 Group 3 = 11-15 Group 4 = 16-20 Group 1 can only be loaded with 3.3 A.
  • Page 9: Led Display

    The serial number contains the production date: nnn YYYY MM nnnnn. This information helps you e.g. during maintenance and is needed for support  requests as well as for the ’dongleserver ProMAX Serviceplus Package’ Quick Installation Guide [en]...
  • Page 10: Safety Regulations

     Safety Regulations UTN servers are network devices for use in office environments. The dongleserver ProMAX is designed for the integration of USB dongles into TCP/IP networks. Important: Before starting the installation and the initial setup procedure as well during the operation of the UTN server, note the following safety regulations.
  • Page 11: Hardware Installation

     Hardware Installation You can directly connect up to 20 USB dongles to the dongleserver ProMAX. clients with software tool 'SEH UTN Manager' dongleserver ProMAX with USB dongles network UTN connection 1. Connect the USB dongle to a USB port of the UTN server.
  • Page 12: Software Installation

    A detailed description can be found in the myUTN User Manual. The SEH UTN Manager has to be installed on all clients that are intended to access a USB dongle via the network. Different installation files are available, depending on the operating system.
  • Page 13: Getting Started: Seh Utn Manager

     Getting Started: SEH UTN Manager After the SEH UTN Manager is started, the network has to be scanned for connected UTN servers. The network range to be scanned is freely definable; the search can be effected via multicast and/or in definable IP ranges. The default setting is multicast search in the local network segment.
  • Page 14: Starting The Seh Utn Manager

    Starting the SEH UTN Manager You recognize the SEH UTN Manager by its icon: . The program is started with the usual methods of your operating system. Important: During the initial configuration, client and UTN server must be assigned to the same local network segment.
  • Page 15: Finding The Utn Server And Assigning An Ip Address

    Finding the UTN Server and Assigning an IP Address Once the UTN server is connected to the network, it checks if it gets an IP address dynamically via the boot protocols BOOTP or DHCP. If this is not the case, the UTN server assigns itself an IP address via Zeroconf from the address range reserved for Zeroconf (169.254.0.0/16).
  • Page 16: Adding The Utn Server To The Selection List

    You can extend the search for UTN servers to any network range. To do this, change the search parameters for the net- work scan. Windows: Via Program – Options. Mac: Via SEH UTN Manager – Preferences. [en] Quick Installation Guide...
  • Page 17: Connecting The Usb Dongle To The Client

    Connecting the USB Dongle to the Client To use a USB dongle, a point-to-point connection is established between the client and the USB port of the UTN server to which the USB dongle is connected. The USB dongle can then be used as if it were directly connected to the client. ...
  • Page 18: Configuring The Utn Server

     Configuring the UTN Server The UTN server has a user interface, the dongleserver Control Center, which can be opened in an Internet browser (Internet Explorer or Safari). The UTN server can be configured, monitored, and maintained via the dongleserver Control Center. 1.
  • Page 19: Locking The Utn Server

     Locking the UTN Server The dongleserver ProMAX has a lockable lid. With it, you can protect the USB dongles. To lock it, insert the straps of the lid into the notches of the housing. The key for  the lock is delivered with the dongleserver ProMAX...
  • Page 20 Software-Installation ..........25 Erste Schritte mit dem SEH UTN Manager ......26 SEH UTN Manager starten....................27...
  • Page 21: Allgemeine Information

    Der USB-Dongleserver 'dongleserver ProMAX' stellt nicht-netzwerkfähige USB- Dongles via TCP/IP-Netzwerk bereit. Dazu werden die USB-Dongles an die USB-Ports des dongleserver ProMAX angeschlossen. Anschließend wird mithilfe der UTN-Funktionalität (UTN = USB to Network) und dem dafür entwickelten Software-Tool 'UTN Manager' eine virtuelle USB-Verbindung zwischen USB-Dongle und Client hergestellt.
  • Page 22: Optionales Zubehör

    Optionales Zubehör Als praktische Ergänzung zu Ihrem dongleserver ProMAX bietet SEH optional erhältliches Zubehör an. dongleserver ProMAX plus Das 'dongleserver ProMAX Service -Paket' plus Service -Paket verlängert die Herstellergarantie Ihres dongleserver ProMAX von 36 auf 60 Monate. Zudem erhalten Sie im Falle eines Defektes bequem und schnell ein Vorab-Austausch-Gerät.
  • Page 23: Technische Daten

    Technische Daten Netzwerkanschluss 1 Netzwerkanschluss 2 (RJ-45) (RJ-45) (auf der Rückseite) (auf der Rückseite) Anschluss für Stromversorgung 1 Anschluss für Stromversorgung 2 (auf der Rückseite) (auf der Rückseite) USB-Ports 1–20 mit LED für den USB-Port Link-LEDs (grün) SD-Kartenleser Activity-LED Restart-Taster Reset-Taster (gelb) Anzeigefeld...
  • Page 24 WARNUNG Betreiben Sie nicht alle USB-Ports mit maximaler Last! Die USB-Ports sind in Gruppen eingeteilt: Gruppe 1 = 1–5 Gruppe 2 = 6–10 Gruppe 3 = 11–15 Gruppe 4 = 16–20 Gruppe 1 kann nur mit 3,3 A belastet werden. Die Gruppen 2–4 können jeweils nur mit 2,2 A belastet werden.
  • Page 25: Led-Anzeige

    Informationen zur Hardware und zu Zertifizierungen sowie die Seriennummer. Die Seriennummer enthält das Produktionsdatum: nnn YYYY MM nnnnn. Diese Angaben helfen Ihnen z.B. bei der Wartung und Sie benötigen sie für Support-Anfragen sowie für das ’dongleserver ProMAX Serviceplus-Paket’  Quick Installation Guide...
  • Page 26: Sicherheitsvorschriften

     Sicherheitsvorschriften UTN-Server sind Netzwerkgeräte für den Gebrauch in Büroumgebungen. Der dongleserver ProMAX dient dem Einbinden von USB-Dongles in TCP/IP- Netzwerken. Wichtig: Beachten Sie vor Inbetriebnahme und beim Betrieb des UTN-Servers die folgenden Sicherheitsvorschriften, um sich und andere vor Personenschäden zu schützen sowie Beschädigungen am Gerät zu vermeiden.
  • Page 27: Hardware-Installation

     Hardware-Installation Am dongleserver ProMAX können bis zu 20 USB-Dongles direkt angeschlossen werden. Clients mit Software-Tool 'SEH UTN Manager' dongleserver ProMAX USB-Dongles Netzwerk UTN-Verbindung 1. Stecken Sie den USB-Dongle an einen USB-Port des UTN-Servers. 2. Wiederholen Sie Schritt 1 je nach Anzahl der anzuschließenden USB- Dongles.
  • Page 28: Software-Installation

    • Minimal-Variante: reine Kommandozeilen-Version Detaillierte Beschreibungen finden Sie in der myUTN-Benutzerdokumentation. Der SEH UTN Manager muss auf allen Clients installiert werden, die auf einen im Netzwerk bereitgestellten USB-Dongle zugreifen sollen. Je nach Betriebssystem sind verschiedene Installationsdateien verfügbar. Laden Sie zuerst die Installationsdatei für den SEH UTN Manager von der SEH Computertechnik GmbH-Homepage: http://www.seh-technology.com/de/service/...
  • Page 29: Erste Schritte Mit Dem Seh Utn Manager

     Erste Schritte mit dem SEH UTN Manager Nach dem Start des SEH UTN Managers muss zunächst im Netzwerk nach angeschlossenen UTN-Servern gesucht werden. scannende Netzwerkbereich ist frei definierbar; es kann über Multicast und/oder in freidefinierbaren IP-Bereichen gesucht werden. Voreingestellt ist die Multicastsuche in dem lokalen Netzwerksegment.
  • Page 30: Seh Utn Manager Starten

    SEH UTN Manager starten Sie erkennen den SEH UTN Manager an seinem Icon: . Er wird wie auf Ihrem Betriebssystem üblich gestartet. Wichtig: Während der Erstkonfiguration müssen Client und UTN- Server demselben lokalen Netzwerksegment zugeordnet sein. [de] Quick Installation Guide...
  • Page 31: Utn-Server Finden Und Eine Ip-Adresse Zuweisen

    UTN-Server finden und eine IP-Adresse zuweisen Nachdem der UTN-Server an das Netzwerk angeschlossen ist, überprüft der UTN-Server, ob er eine IP-Adresse dynamisch über die Bootprotokolle BOOTP oder DHCP erhält. Ist das nicht der Fall, gibt sich der UTN-Server über Zeroconf selbst eine IP-Adresse aus dem für Zeroconf reservierten Adressbereich (169.254.0.0/16).
  • Page 32: Utn-Server Der Auswahlliste Hinzufügen

    Die Suche nach UTN-Servern kann auf beliebige Netzwerkbe- reiche erweitert werden. Ändern Sie hierzu die Suchparameter für den Netzwerkscan. Windows: Im Menü Programm über den Dialog Optionen. Mac: Im Menü SEH UTN Manager über den Dialog Einstellun- gen. [de] Quick Installation Guide...
  • Page 33: Usb-Dongle Mit Client Verbinden

    USB-Dongle mit Client verbinden Um einen USB-Dongle zu nutzen, wird eine Punkt-zu-Punkt-Verbindung hergestellt zwischen dem Client und dem USB-Port des UTN-Servers, an den der USB-Dongle angeschlossen ist. Der USB-Dongle kann dann so genutzt werden, als ob er direkt am Client angeschlossen wäre. ...
  • Page 34: Utn-Server Konfigurieren

     UTN-Server konfigurieren Der UTN-Server verfügt über eine Benutzeroberfläche, das dongleserver Control Center, welches Sie in einem Internet-Browser (z.B. Microsoft Edge oder Safari) aufrufen. Über das dongleserver Control Center kann der UTN-Server konfiguriert, überwacht und gewartet werden. 1. Öffnen Sie Ihren Browser. 2.
  • Page 35: Utn-Server Abschließen

     UTN-Server abschließen Der dongleserver ProMAX hat einen abschließbaren Gehäusedeckel. Damit können Sie die USB-Dongles schützen. Zum Schließen führen Sie die Laschen des Gehäusedeckels in die Nuten des Gehäuses ein. Der Schlüssel für das Schloss liegt dem Lieferumfang des ...
  • Page 36: Regulatory Compliance Information

     Regulatory Compliance Information Important: The latest version of the EC declaration of conformity can be downloaded from the website of SEH Computertechnik GmbH: http://www.seh-technology.com/services/ ce-notifications.html Quick Installation Guide...
  • Page 37 Quick Installation Guide...
  • Page 38 Quick Installation Guide...
  • Page 39: Open Source Software License Disclaimer And License Texts

     Open Source Software License Disclaimer and License Texts This product was developed by SEH Computertechnik GmbH and contains and uses software which is licensed under the terms of various Open Source software licenses. All information including disclaimer and licenses can be found in the device's web-based user interface, the dongleserver Control Center, on the page 'Open Source Software' (http://<IP address>...
  • Page 40 Downloads: http://www.seh-technology.com/services/downloads.html © 2019 SEH Computertechnik GmbH All trademarks, registered trademarks, logos and product names are property of their respective owners. The contents of this document are subject to change without notification. This product uses 'Open Source Software' . For further information, go to http:// www.seh-technology.com/services/licenses.html.
