Chapter 2 Switch Installation
Follow these steps to install the switch into the server chassis:
Obtain and make note of this information from your network administrator before you begin the switch
Step 1
installation:
Switch IP address
•
Subnet mask (IP netmask)
•
Default gateway (router)
•
Enable secret password (encrypted)
•
• Enable password (not encrypted)
• Telnet password
• SNMP community strings (optional)
Select a chassis I/O module bay in which to install the switch. Follow the prerequisites listed in the
Step 2
Modular Server Chassis Architecture" section on page
Remove the IOM blank from the selected bay, and store it for future use.
Step 3
Step 4 If you have not already done so, touch the static-protective package that contains the switch to an
unpainted metal part of the server chassis for at least 2 seconds.
Step 5 Remove the switch from its static-protective package.
Cisco Catalyst Blade Switch 3130 for Dell and Cisco Catalyst Blade Switch 3032 for Dell Hardware Installation Guide
OL-13269-01
Installing the Switch in the Server Chassis
2-3.
"Dell
2-5
