Switch Features Overview
For a list of supported modules, see the release notes on Cisco.com. For detailed instructions on
installing, removing, and connecting to SFP modules, see the documentation that came with the
SFP module.
Figure 1-1
for Dell does not have the StackWise Plus ports and Stack, Master, and Member LEDs.
Figure 1-1
2
1 Switch
2
StackWise Plus ports 1 and 2 (only the CBS3130G-S and
CBS3130X-S switches)
3 Gigabit Ethernet uplink ports 17 to 20 and port LEDs
4
LEDs for ports 21 and 22 or for 10-Gigabit Ethernet slot 1
5 Gigabit Ethernet ports 21 and 22 or 10-Gigabit Ethernet slot 1
6 LEDs for ports 23 and 24 or for 10-Gigabit Ethernet slot 2
7 10-Gigabit Ethernet slot 2
or Gigabit Ethernet ports 23 and 24
1. SYST, STCK, MSTR, MMBR.
2. 10-Gigabit Ethernet supported only on the CBS3130X-S.
Table 1-1
Table 1-1
Port
Ports 1 to 16
Ports 17 to 20
Ports 21 to 24
Cisco Catalyst Blade Switch 3130 for Dell and Cisco Catalyst Blade Switch 3032 for Dell Hardware Installation Guide
1-2
shows the Cisco Catalyst Blade Switch 3130 for Dell. The Cisco Catalyst Blade Switch 3032
CBS3130 Switch Front Panel
1
4
3
5
describes the switch ports.
Cisco Catalyst Blade Switch 3130 for Dell and 3032 for Dell
Port Descriptions
Description
Internal Gigabit Ethernet 1000BASE-X downlink ports that connect the switch
to the server chassis blades.
External 10/100/1000BASE-T copper Gigabit Ethernet uplink ports that support
auto-MDIX and autonegotiation.
10-Gigabit Ethernet module slots for use with the Cisco TwinGig Converter
Modules and Cisco X2 transceiver modules.
8
9
6
7
11
Chapter 1 Product Overview
10
12
13
8 Release latch
9
Cisco status LEDs
10 System Status/ID LED
11 Mode button
2
12 Console port
13 Power LED
1
