Installing A Switch - Huawei OceanStor CloudStor CSE Quick Installation Manual

2
Removing Filler Panels
3
Installing Back-End Storage Devices
Install the back-end storage device by referring to the accompanying documents.
4
Installing a KVM
Install the KVM balancing pole to the
1
rear of the cabinet.
5

Installing a Switch

5
2
Slide the KVM along the guide rails.
1
Fix the mounting ears on each side of the
switch by using M4 panel screws.
2 Slide the switch along the guide
rails.
Fix the mounting ears on the square hole bar
3
of the cabinet by using M6 panel screws.
5
Remove only filler panels that cover the planned
installation positions.
Fix the mounting ears on the square
3
hole bars of the cabinet by using M6
panel screws.
