Liteobar 126
Colour changing RGB LED panel lighting effect
M
A
N
U
A
L
V
E
R
S
I
O
N
1
.
0
21 / 04 / 11
126 x 10mm RGB LEDs
42 x red, 42 x green, 42 x blue LEDs
Full DMX512 operation / 11 DMX channels
Auto mode / Sound-to-Light operation via built-in mic
Master/Slave modes / LED display
Tough metal chassis / adjustable metal hanging bracket
Twin safety chain loop / mains fused IEC in and out
Dimensions: 580 x 158 x 105mm (WxHxD)
Weight: 3.2Kg
For the latest instruction manual updates and information on the entire Kam range visit:
www.kam.co.uk
Kam products are manufactured by: Lamba plc, Unit 1, Southfields Road, Dunstable, Bedfordshire, United Kingdom LU6 3EJ
Telephone: (+44) (0)1582 690600 • Fax: (+44) (0)1582 690400 • Email: mail@lambaplc.com • Web: www.lambaplc.com
If this product is ever no longer functional please take it to a recycling plant for environmentally friendly disposal.
Due to continuous product development, specifications and appearance are subject to change.
© Copyright Lamba plc 2010. E&OE.
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for KAM Liteobar 126
Summary of Contents for KAM Liteobar 126
- Page 1 For the latest instruction manual updates and information on the entire Kam range visit: www.kam.co.uk Kam products are manufactured by: Lamba plc, Unit 1, Southfields Road, Dunstable, Bedfordshire, United Kingdom LU6 3EJ Telephone: (+44) (0)1582 690600 • Fax: (+44) (0)1582 690400 • Email: mail@lambaplc.com • Web: www.lambaplc.com If this product is ever no longer functional please take it to a recycling plant for environmentally friendly disposal.
- Page 2 Thank you for purchasing this KAM product, we are sure that it will serve you for many years to come. To optimise the performance of this product, please read these operating instructions carefully to familiarise yourself with the basic operations of this unit. After you have read the instructions, please retain them for future reference.
- Page 3 Rear view 1. Power link output 2. DMX Male Socket 3. DMX Female Socket 4. Audio Sensitivity 5. Mic 6. LCD display 7. Touch switch “MENU” 8. Touch switch “UP” 9. Touch switch “DOWN” 10. Power input Installation methods This unit can be fixed to a flat floor surface, wall or ceiling. If you choose to mount the unit please use the appropriate equipment to ensure the unit is completely secured to the wall/ceiling to avoid any problems.
- Page 4 Spd XX (01-10): when the display shows Spd XX you can set the speed of the program. There are 10 speeds to choose from. 01 is the fastest speed and 10 is the slowest speed. Use the up and down buttons to select the desired speed.
- Page 5 DMX control DMX function chart CH10 CH11 0 - 40 Black Out 41 - 80 Flash Red1 Green1 Blue1 Red2 Green2 Blue2 Red3 Green3 Blue3 Dimmer1 81 - 120 Flash Dimmer2 Green Blue 121 - 160 Flash Color Color Flash 161 - 200 Speed Color Change...
