- Page 1 Instructions Manual 13-24 pages VIGILO 2250 - VIGILO 2251 VIGILO 2263 VIGILO 2280 - VIGILO 2281 Ø 200 EN 13241 EN 12453 EN 12445 the gate opener - 13 -...
- Page 2 The oil-hydraulic bollards VIGILO 2250 (500 mm height), VIGILO 2251 (500 mm height, with LEDs), VIGILO 2263 (600 mm height, with or without LEDs), VIGILO 2280 (800 mm height) and VIGILO 2281 (800 mm height, with LEDs) are fitted with posts made of rust-treated steel, 200 mm diameter.
-
Page 3: Preliminary Operations
- The manufacturer reserves the right to make changes to this manual without giving notice. - Meccanica Fadini declines all responsibility for improper use not specifically indicated in this manual and any malfunction deriving from the use of materials or accessories other than those indicated by the manufacturer. - Page 4 PRELIMINARY OPENING OF ALL FUNCTIONAL COMPONENTS Start by removing the cover plate to reveal the operator and separate the individual components, with the aid of a hoist. Pic.2: this makes it easy to extract the internal piston and hydraulic main unit container unit. IMPORTANT: TAKE CARE NOT TO TEAR OR CUT WIRES.
- Page 5 ELECTRICAL LAYOUT OF THE INSTALLATION 4x1 mm² 230 V - 50 Hz 2x1 mm² 4x1 mm² 3x1 mm² 2x1 mm² 4x1 mm² 1 - MIRI 4-Led flashing light with built-in aerial 2 - Wall-mounted ASTRO 43 MQB radio receiver 3 - Elpro S40 electronic programmer 4 - Differential circuit breaker switch (sensitivity 30 mA, protection 6-10 A) 5 - Junction box, electric wires 6 - FIT 55 photocell receiver...
- Page 6 ARRANGING THE HOUSING Ø275 pic. 4 IMPORTANT: once the housing has been positioned and installation completed, it is important for the top edge to be level with the ground. Piping Ø 50 mm Concrete for passage of cast Spirit level electric wires 12 cm cover with...
- Page 7 PLACING THE TRAFFIC CONTROL POST INSIDE THE HOUSING Before performing this operation, wait for the housing to be secured firmly in place. Do not commence until the concrete has set and the electric wire pipe has been secured and covered with soil. - Use a hoisting hook to lift the piston unit with the post and main unit (using the eyebolt) and place on top of the housing.
- Page 8 MAGNETIC LOOP PREPARATIONS IMPORTANT: make sure that no other electro-magnetic sources are located on or under the ground near the installation to prevent interference or any affecting action with the magnetic loops of the vehicle detecting device if installed or with any other electronic equipment included in the system for commanding and controlling operations.
- Page 9 ELECTRIC CONNECTIONS WITH THE PROGRAMMER Vigilo with LED lights 20 µF ELPRO S40 Closing limit switch M1 (post up) Opening limit switch M1 (post down) 16 17 18 22 23 11 12 13 52 53 52 53 STABILIZER VIGILO bollard Standard Vigilo Vigilo with Standard Vigilo...
- Page 10 VERSION OF CORAL WITH SOLENOID VALVE In the version of VIGILO with solenoid valve no manual overriding action is needed, and in case of power failure the post descends automatically flush with pavement level. To enable the solenoid valve to operate properly, the electric wires labelled “ELECTROVALVE”...
-
Page 11: Declaration Of Conformity
200 and stroke 500 mm: version with LEDs is conforming to machinery directive 2006/42/CE VIGILO 2250 and VIGILO 2251 (version with LEDs) are sold for installation as an automated system, with original accessories and components indicated by the Manufacturer. -
Page 12: Technical Data
Service mode Oil-hydraulic piston Plunger diameter 30 mm Rod diameter 16 mm Net rod stroke 500 mm (Vigilo 2250 and 2251) 600 mm (Vigilo 2263) 800 mm (Vigilo 2280 and 2281) Post Features Material Fe 360 Steel Diameter Ø 200 mm...
