Sierra Designs FLASHLIGHT 2 Pitching Instructions

FLASHLIGHT 2
PITCHING INSTRUCTIONS
Congratulations on the purchase of you new Sierra Designs tent! In order to familiarize yourself with
your new tent, we recommend you "test pitch" it before embarking on your wilderness adventure.
PACKAGE INCLUDES: Tent body with attached Rain Fly, 1 NR Joint Rear Pole, 2 Vertical Poles, Guy Cords, Stakes, 1 Pole/Stake Bag and Tent Stuff Sack.
STEP 1:
Find an even piece of ground; be sure area
is clear of debris. Layout your tent as shown. Stake
the 4 corners (circled).
STEP 3: Assemble vertical poles. Insert the rounded
into the sleeve
end of the pole
awning at the peak of the tent. Insert the bottom of
the pole into the grommet.
STEP 5: Stake out the rear vent on tent (circled) and
your tent should be completely set up.
(STANDARD, UL & FL MODELS)
located under the
STEP 2:
Assemble rear pole and insert in grommets.
Attach the two H-Clips on the tent to NR Joint on pole.
Attach ultralight clip to pole.
NR Joint with H-Clip
must face down.
STEP 4: Now that the vertical pole is installed, stake
out the gear closet. It works best if the gear closet
wall is attached to the tent body as shown. Repeat
steps 3 & 4 on the other side of the tent.
NOTE: If you're carrying trekking poles and want to
drop 6oz of weight, leave the vertical poles at home.
Simply insert the handle end of the pole into the
awning peak and put the trekking pole tip into the
grommet.
