- Page 1 Dell Latitude 5310 2-in-1 Setup and specifications guide Regulatory Model: P96G Regulatory Type: P96G003...
- Page 2 Notes, cautions, and warnings NOTE: A NOTE indicates important information that helps you make better use of your product. CAUTION: A CAUTION indicates either potential damage to hardware or loss of data and tells you how to avoid the problem. WARNING: A WARNING indicates a potential for property damage, personal injury, or death.
-
Page 3: Table Of Contents
3 Chassis overview..........................8 Display view.................................... 8 Left view....................................9 Right view....................................9 Palmrest view..................................10 Bottom view..................................11 4 Keyboard shortcuts........................12 5 Specifications of Latitude 5310 2-in-1................... 13 Dimensions and weight................................13 Processors.....................................13 Chipset....................................13 Operating system................................. 14 Memory....................................14 Ports and connectors................................14 Communications...................................15... - Page 4 System configuration..............................25 Video screen options..............................27 Security................................... 27 Secure Boot..................................29 Intel Software Guard Extensions options........................29 Performance...................................30 Power management..............................30 Post behavior.................................. 31 Manageability................................. 32 Virtualization support..............................33 Wireless options................................33 Maintenance...................................33 System logs..................................34 Updating the BIOS in Windows ............................34 Updating BIOS on systems with BitLocker enabled....................
-
Page 5: Set Up Your Computer
Set up your computer 1. Connect the power adapter and press the power button. NOTE: To conserve battery power, the battery might enter power saving mode. 2. Finish Windows system setup. Follow the on-screen instructions to complete the setup. When setting up, Dell recommends that you: •... - Page 6 Dell apps Details Dell Update Updates your computer with critical fixes and important device drivers as they become available. Dell Digital Delivery Download software applications including software that is purchased but not preinstalled on your computer. 4. Create recovery drive for Windows. NOTE: It is recommended to create a recovery drive to troubleshoot and fix problems that may occur with Windows.
-
Page 7: Create A Usb Recovery Drive For Windows
Create a USB recovery drive for Windows Create a recovery drive to troubleshoot and fix problems that may occur with Windows. An empty USB flash drive with a minimum capacity of 16 GB is required to create the recovery drive. NOTE: This process may take up to an hour to complete. -
Page 8: Chassis Overview
Chassis overview Topics: • Display view • Left view • Right view • Palmrest view • Bottom view Display view 1. Array microphone 2. Camera IR LED 3. Camera 4. Camera shutter 5. Camera status LED 6. Array microphone 7. LCD panel 8. -
Page 9: Left View
Left view 1. Power connector port 2. USB 3.2 Gen 2 (USB Type-C) port with DisplayPort/ Power Delivery/Thunderbolt (optional) 3. HDMI port 4. USB 3.2 Gen 1 port 5. Smart card reader (optional) Right view 1. Universal Audio Jack 2. microSD card reader 3. -
Page 10: Palmrest View
Palmrest view 1. Power button with optional fingerprint reader (FPR) 2. Keyboard 3. NFC/Contactless smartcard reader (optional) 4. Touchpad Chassis overview... -
Page 11: Bottom View
Bottom view 1. Thermal vent 2. Service tag label 3. Speakers Chassis overview... -
Page 12: Keyboard Shortcuts
Keyboard shortcuts NOTE: Keyboard characters may differ depending on the keyboard language configuration. Keys that are used for shortcuts remain the same across all language configurations. Table 2. List of keyboard shortcuts Keys Primary Behavior Secondary Behavior (Fn + Key) Fn + Esc Escape Toggle Fn-key lock... -
Page 13: Specifications Of Latitude 5310 2-In-1
Specifications of Latitude 5310 2-in-1 Dimensions and weight Table 3. Dimensions and weight Description Values Height: Front 17.53 mm (0.69 in.) Rear 19.71 mm (0.78 in.) Width 305.70 mm (12.04 in.) Depth 207.50 mm (8.17 in.) Weight 2.92 lb (1.32 kg) -
Page 14: Operating System
One DisplayPort1.2 over USB Type-C Media card reader uSD slot (push-push type) SIM card uSIM card with tray (optional) Smart card Smart card reader slot (optional) Docking port Supports Type-C Docks Power adapter port • One 7.4 mm barrel Specifications of Latitude 5310 2-in-1... -
Page 15: Communications
Up to 450 Mbps DL/50 Mbps UL (Cat 9) Operating Frequency bands supported (1,2,3,4,5,7,8,11,12,13,17,18,19,20,21,26,28,29,30,38,39,40,41,66), HSPA+ (1, 2, 4,5, Power supply DC 3.135 V to 4.4 V, Typical 3.3 V Temperature Normal operating temperature: -10°C to + 55°C Specifications of Latitude 5310 2-in-1... -
Page 16: Audio
128 GB, 256 GB, 512 GB One M.2 2280 PCle Solid-State Drive Class 40 PCIe Gen 3 x 4 256 GB, 512 GB, 1 TB Media-card reader Table 13. Media-card reader specifications Description Values Type One microSD card slot Specifications of Latitude 5310 2-in-1... -
Page 17: Keyboard
1280 x 720 megapixel Video 1280 x 720 (VGA/HD) at 30 fps Infrared camera Still image 0.23 megapixel Video 640 x 360 (VGA/HD) at 30 fps Diagonal viewing angle Camera 78.6 degrees Infrared camera 87 degrees Specifications of Latitude 5310 2-in-1... -
Page 18: Touchpad
0 °C to 40 °C (32 °F to 104 °F) °F) °F) Storage -40 °C to 70 °C (-40 °F 158 -40 °C to 70 °C (-40 °F 158 -40 °C to 70 °C (-40 °F 158 °F) °F) °F) Specifications of Latitude 5310 2-in-1... -
Page 19: Battery
Coin-cell battery CR-2032 CR-2032 CR-2032 ExpressCharge Supported Supported Not Supported Display Table 19. Display specifications Description Values Type Full High Definition (FHD) Panel technology Wide Viewing Angle (WVA) Luminance (typical) 300 Nits Dimensions (active area): Specifications of Latitude 5310 2-in-1... -
Page 20: Fingerprint Reader
Airborne contaminant level: G1 as defined by ISA-S71.04-1985 Table 22. Computer environment Description Operating Storage Temperature range 0 °C to 35 °C (32 °F to 95 °F) -40 °C to 65 °C (-40 °F to 149 °F) Specifications of Latitude 5310 2-in-1... - Page 21 -15.2 m to 10668 m (4.64 ft to 19234.4 ft) * Measured using a random vibration spectrum that simulates user environment. † Measured using a 2 ms half-sine pulse when the hard drive is in use. Specifications of Latitude 5310 2-in-1...
-
Page 22: Software
Software This chapter details the supported operating systems along with instructions on how to install the drivers. Topics: • Downloading Windows drivers Downloading Windows drivers 1. Turn on the laptop. 2. Go to Dell.com/support. 3. Click Product Support, enter the Service Tag, and then click Submit. NOTE: If you do not have the Service Tag, use the auto detect feature or manually browse for your laptop model. -
Page 23: System Setup
System setup CAUTION: Unless you are an expert computer user, do not change the settings in the BIOS Setup program. Certain changes can make your computer work incorrectly. NOTE: Before you change BIOS Setup program, it is recommended that you write down the BIOS Setup program screen information for future reference. -
Page 24: Boot Sequence
Keys Navigation Moves to the previous page until you view the main screen. Pressing Esc in the main screen displays a message that prompts you to save any unsaved changes and restarts the system. Boot Sequence Boot sequence enables you to bypass the System Setup–defined boot device order and boot directly to a specific device (for example: optical drive or hard drive). -
Page 25: System Configuration
Option Description Date/Time Allows you to set the date and time. The change to the system date and time takes effect immediately. System configuration Table 24. System Configuration Option Description SATA Operation Allows you to configure the operating mode of the integrated SATA hard-drive controller. - Page 26 Option Description • Auto Switch : The BIOS will automatically switch between BIOS Assist and Native Thunderbolt PC device enumeration modes to get all benefits of the installed OS • Native Enumeration: The BIOS will program the Thunderbolt controller to Native mode ( Auto Switching is disabled) •...
-
Page 27: Video Screen Options
Option Description Touchscreen This option controls whether the touchscreen is enabled or disabled. This option is enabled by default. Unobtrusive Mode When enabled, pressing Fn+F7 will turn off all light and sound emissions in the system. Press Fn+F7 to resume normal operation. Default is Disabled. - Page 28 Option Description NOTE: For the first time login, "Enter the old password:" field is marked to "Not set". Set the password for the first time and later you can change or delete the password. Strong Password Allows you to enforce the option to always set the strong password. •...
-
Page 29: Secure Boot
Option Description Master Password Lockout Allows you to disable master password support. • Enable Master Password Lockout This option is not set by default. NOTE: Hard Disk password should be cleared before the settings can be changed. SMM Security Mitigation Allows you to enable or disable additional UEFI SMM Security Mitigation protection. -
Page 30: Performance
Option Description • 32 MB • 64 MB • 128 MB—Default Performance Table 29. Performance Option Description Multi Core Support This field specifies whether the processor has one or all cores enabled. The performance of some applications improves with the additional cores. -
Page 31: Post Behavior
Option Description • Disabled—Default • Every Day • Weekdays • Select Days This option is not set by default. USB Wake Support Allows you to enable USB devices to wake the system from standby. • Enable USB Wake Support • Wake on Dell USB-C Dock This option is not set by default. -
Page 32: Manageability
Option Description • Enable Numlock—Default Fn Lock Options Allows you to let hot key combinations Fn + Esc toggle the primary behavior of F1–F12, between their standard and secondary functions. If you disable this option, you cannot dynamically toggle the primary behavior of these keys. -
Page 33: Virtualization Support
Virtualization support Table 33. Virtualization Support Option Description Virtualization This option specifies whether a Virtual Machine Monitor (VMM) can utilize the additional hardware capabilities provided by the Intel Virtualization technology. • Enable Intel Virtualization Technology This option is set by default. VT for Direct I/O Enables or disables the Virtual Machine Monitor (VMM) from utilizing the additional hardware capabilities provided by the Intel Virtualization technology for direct I/O. -
Page 34: System Logs
Option Description BIOS Downgrade Allows you to flash previous revisions of the system firmware. • Allow BIOS Downgrade This option is set by default. Data Wipe Allows you to securely erase data from all internal storage devices. • Wipe on Next Boot This option is not set by default. -
Page 35: Updating Bios On Systems With Bitlocker Enabled
Follow the instructions on the screen. Updating BIOS on systems with BitLocker enabled CAUTION: If BitLocker is not suspended before updating the BIOS, the next time you reboot the system it will not recognize the BitLocker key. You will then be prompted to enter the recovery key to progress and the system will ask for this on each reboot. -
Page 36: Assigning A System Setup Password
You can create a system password and a setup password to secure your computer. CAUTION: The password features provide a basic level of security for the data on your computer. CAUTION: Anyone can access the data stored on your computer if it is not locked and left unattended. NOTE: System and setup password feature is disabled. -
Page 37: Getting Help And Contacting Dell
Getting help and contacting Dell Self-help resources You can get information and help on Dell products and services using these self-help resources: Table 38. Self-help resources Self-help resources Resource location Information about Dell products and services www.dell.com Dell Help and Support app Accessing help In Windows search, type Help and Support, and press Enter.
