Product Features; Origins Ice Maker/Refrigerator Model Co29Ff; Operation; Initial Startup - U-Line Combo CO29FF Use And Care Manual

4 Product Features

Origins Ice Maker/Refrigerator
Model CO29FF
The CO29FF Ice Maker/Refrigerator with adjustable
temperature control provides 2.1 cubic feet (59 L) of
refrigeration in one compact unit.
• The ice maker produces up to 8 lbs (3.6 kg) of ice per
day, and will store 13 lbs (5.9 kg). It conserves on water,
using only 2-3/4 gallons (12.5 L) to produce
approximately 22 lbs (10 kg) of ice.
• Frost Free technology
• Two tempered glass shelves provide a generous
amount of shelving space. The shelves are easy to
clean.
• Two in-door shelves feature clear bottle retainers, and
an additional half shelf is provided to maximize
storage capacity.
• The door features an integrated handle, and can
accommodate a custom 1/4" (0.64 cm) flat or raised
panel to match surrounding cabinets.
• The door is field-reversible.
• The unit features a vinyl clad steel cabinet that
provides a rich textured look, and resists scratching,
peeling, and flaking.
Features and specifications are subject to change without
notice.
6

5 Operation

Proper air flow (Figure 2) is required for your unit to
operate at its highest efficiently. A grille, located in
the base of the unit, must not be blocked at any
time, or your unit will not perform as expected.

Initial Startup

All U-Line units are shipped with controls that are preset.
No initial adjustments are required.
• U-Line recommends the unit be allowed to run
overnight prior to loading the refrigerator and/or
freezer with product.
• On ice maker equipped units, it is possible that
dirt or scale will dislodge in the water line.
Always throw away all ice cubes made during the
first two to three hours of operation.
To turn the unit on or off, press the rocker switch (Figure
3) located below the temperature control dial in the
center of the grille.
CO29FF
ULIN_0130_A
Figure 2
IMPORTANT IMPORTANT
IMPORTANT IMPORTANT
ULIN_0129_A
Figure 3
