Troubleshooting Guide

DANGER
ELECTROCUTION HAZARD
Never attempt to repair or perform maintenance on
the unit until the main electrical power has been
disconnected.
Troubleshooting - What to check when problems occur:
PROBLEM
Unit not cold enough
Water is leaking out the back of the
unit.
Ice cubes sticking together
Noise during operation
No ice
Not enough ice
Water leaks into ice bucket.
Fresh food section on Combo units
too cold
Unit too cold
POSSIBLE CAUSE
Door gasket not sealing properly
Item(s) interfering with door
Dirty condenser coils
Airflow to front grille blocked
Temperature not set cold enough
Water supply connection leaking
Door gasket not sealing properly
Infrequent use of cubes
Copper water supply tubing
contacting internal components
Certain sounds are normal.
Bin arm locked in upright position
No water to unit
Ice cube size too large
Dirty condenser coils
Water level set too high
Ice bucket not fully inserted
Freezer door not closed correctly
Temperature control set too cold
CO29FF
REMEDY
Adjust door (See MAINTENANCE; DOOR ALIGN, ADJUST,
REVERSE).
Reposition or remove item(s).
Clean condenser (See MAINTENANCE; CONDENSER
CLEANING).
Airflow must not be obstructed to front grille (See
OPERATION).
Set control knob to cooler setting (See OPERATION).
Allow 24 hours for temperature to stabilize.
Tighten fitting as required.
Adjust door (See MAINTENANCE; DOOR ALIGN, ADJUST,
REVERSE).
Break apart cubes.
Carefully bend tubing away from cabinet and
components.
Soft sounds from the fan and water/dropping sounds
from the ice maker will be heard.
Lower bin arm.
Turn on water or contact plumber.
Set cube size smaller (See MAINTENANCE; ICE MAKER;
ICE CUBE THICKNESS ADJUST).
Clean condenser (See MAINTENANCE; CONDENSER
CLEANING).
Set cube size smaller (See MAINTENANCE; ICE MAKER;
ICE CUBE THICKNESS ADJUST).
Push ice bucket into place.
Be sure freezer door is closed correctly.
Set control to warmer setting (See OPERATION).
15
