Travis Industries GreenSmart 2 Setup Instructions

Hide thumbs Also See for GreenSmart 2:
Table of Contents

Advertisement

Quick Links

Table of Contents

Table of Contents .................................................................................................................................................................... 1
Warnings ................................................................................................................................................................................. 1
Compatibility ........................................................................................................................................................................... 1
Packing List ............................................................................................................................................................................. 1
Installation ............................................................................................................................................................................... 1
Wall Mount and Hand Held Remote ........................................................................................................................................ 2
Remote Setup ......................................................................................................................................................................... 2
Intermittent/Continuous Pilot ................................................................................................................................................... 3
Direct Operation ...................................................................................................................................................................... 4
Remote Operation ................................................................................................................................................................... 4
Battery Replacement ............................................................................................................................................................... 7
Display Fahrenheit or Celsius ................................................................................................................................................. 8
Power Outages ....................................................................................................................................................................... 8
Low Battery Indicator .............................................................................................................................................................. 8
Child-Proof Feature ................................................................................................................................................................. 8
Remote Programming ............................................................................................................................................................. 9

Warnings

The transmitter and receiver are radio frequency devices. Placing the transmitter in or near metal may
severely reduce the signal range.
Turn off power to the heater (unplug or turn off at the breaker).
Turn off the main gas supply to the appliance during appliance installation or maintenance.
REMOTE CONTROL / PILOT WARNING: Installing batteries in the battery holder or connecting the
appliance to power may automatically initiate the CPI pilot mode, resulting in a lit pilot flame. Do not
place combustibles inside the firebox.

Compatibility

The GreenSmart™ 2 remote is compatible with all Travis Industries GS2 products.

Packing List

Transmitter
Battery Box
Remote Wall Mount w Screws & Anchors
Stepper Motor
Torx Wrench
Remote Control DVD
GSR2 IFC

Installation

HINT: If using a blower, make sure to have it on hand while installing the remote.
Refer to the installation instructions included with your appliance.
Page 1 of 10
GreenSmart
(SKU 99300688, 99300690, 99300692, 99300693)
The remote control system requires the batteries and battery cover to remain in place at all times. Once the
batteries or cover are removed, the system may restart in standing pilot mode. If this occurs when the heater
is in Remote Mode, you will not be able to turn off the heater manually from the battery box.
If you need to replace dead batteries, make sure to turn the appliance off before removing the batteries.
NOTE:
If the batteries go dead, the system will operate normally as long as household power (120v AC)
is present.
17601740.docx - 11/3/16
TM
2 Remote Setup Instructions
KEEP BATTERIES AND COVER
INSTALLED AT ALL TIMES
Split-flow Harness (attached to IFC)
System Jumper (attached to IFC)
Battery Box Harness (attached to IFC)
Fan/Light Harness (attached to IFC)
(2) Jumper Wires
Power Lead (Eden, Northfield, Tree of Life, Berkshire only)
(2) 4" Cable Ties
© Travis Industries, Inc.

















Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the GreenSmart 2 and is the answer not in the manual?

Questions and answers

Related Manuals for Travis Industries GreenSmart 2

Summary of Contents for Travis Industries GreenSmart 2

  • Page 1: Table Of Contents

    CPI pilot mode, resulting in a lit pilot flame. Do not place combustibles inside the firebox. Compatibility The GreenSmart™ 2 remote is compatible with all Travis Industries GS2 products. Packing List  ...

  • Page 2: Wall Mount And Hand Held Remote

    The system will return to its original configuration: a remote will need to be synchronized; and, the system will operate under continuous pilot mode. Page 2 of 10 17601740.docx — 11/3/16 © Travis Industries, Inc.

  • Page 3: Intermittent/Continuous Pilot

    IPI/CPI. NOTE: This icon appears when the appliance is in CPI mode. Press the "UP" button Press the "DOWN" button to activate CPI mode. to activate IPI mode. Page 3 of 10 17601740.docx — 11/3/16 © Travis Industries, Inc.

  • Page 4: Direct Operation

    NOTE: When the batteries start to get low, the IFC will beep intermittently. When the batteries are nearly depleted, the IFC will no longer beep. See “IFC Batteries” on page 8). Page 4 of 10 17601740.docx — 11/3/16 © Travis Industries, Inc.
  • Page 5 NOTE: If the transmitter batteries go dead while in thermostat setting (standard or smart), the appliance will shut off after approximately 24 hours. Page 5 of 10 17601740.docx — 11/3/16 © Travis Industries, Inc.
  • Page 6 When in Manual Mode the blower will remain on, even if the burner is turned off and the heater cools. Either manually turn the blower off, or turn off the heater by pressing the On/Off button. Page 6 of 10 17601740.docx — 11/3/16 © Travis Industries, Inc.

  • Page 7: Battery Replacement

    Install four AA batteries into the battery holder (see below). These batteries act as a power backup in case the household (AC) current goes out. Transmitter Battery Installation Install the three included AAA batteries into the remote (see below). Page 7 of 10 17601740.docx — 11/3/16 © Travis Industries, Inc.

  • Page 8: Display Fahrenheit Or Celsius

     Press both the MODE and UP buttons simultaneously to turn this feature on and off (see below). HINT: This feature is especially useful while using the thermostat setting. Child Proof Indicator Page 8 of 10 17601740.docx — 11/3/16 © Travis Industries, Inc.

  • Page 9: Remote Programming

    Repeat this process to toggle the thermostat function to the desired setting. When "SET" appears, the thermostat function is enabled. When "CLR" appears, the thermostat function is disabled. Page 9 of 10 17601740.docx — 11/3/16 © Travis Industries, Inc.
  • Page 10 Press the "up" button to activate ("SET") the mode selected. Press the "down" button to clear ("CLR") the mode selected. Release the on/off button to complete programming. Page 10 of 10 17601740.docx — 11/3/16 © Travis Industries, Inc.
