  • Page 1 Operating instructions Induction multi slider Glas ceramic hob...
  • Page 2 These operating instructions apply to: Type Product family GK37TIMPS/C/F/F spec. 31038 GK46TIABS/C/F/U/.1F 028, 31017 GK47TIMPS/C/F 31036 GK47TIMAS/C/F 31037 GK36TIPS/C/F/F spec. GK46TIPS/C/F/F spec. GK46TIAS/C/F/U/.1F 974, 31019 Variations depending on the model are noted in the text. © V-ZUG Ltd, CH-6301 Zug, 2015...

  • Page 3: Table Of Contents

    Contents 1 Safety precautions  5 Symbols used.................... 5 General safety precautions............... 6 Appliance-specific safety precautions ............ 7 Instructions for use.................. 8 2 Disposal  10 3 Using for the first time  11 4 Your appliance  12 Appliance overview.................. 12 Operating and display elements ............ 14 How induction hobs function .............. 15 Pan detection .................... 16 Cookware.................... 16 Flexible cooking .................. 17...
  • Page 4 Product fiche ..................... 40 10 Index  42 11 Notes  44 12 Service & Support  47...

  • Page 5: Safety Precautions

    Safety precautions Symbols used Denotes important safety precautions. Failure to observe said precautions can result in injury or in damage to the appliance or fittings! Information and precautions that should be observed. Information on disposal Information about the operating instructions ►...

  • Page 6: General Safety Precautions

    1 Safety precautions General safety precautions • Read the operating instructions before using the appliance for the first time! • This appliance can be used by children aged 8 and above and by persons with reduced physical, sensory or mental cap- abilities, or lack of experience and/or knowledge, provided they are supervised or have been instructed on the safe use of the appliance and have understood the hazards involved.

  • Page 7: Appliance-Specific Safety Precautions

    1 Safety precautions Appliance-specific safety precautions • WARNING: If the surface is cracked or there is damage to the material thickness, the appliance must be switched off and disconnected from the electricity supply in order to avoid a possible electric shock. •...

  • Page 8: Instructions For Use

    1 Safety precautions Instructions for use Before using for the first time • The appliance must be installed and connected to the electricity supply in accordance with the separate installation instructions. Have a qualified fitter/ electrician carry out the necessary work. Correct use •...
  • Page 9 1 Safety precautions Caution: Risk to life! • Packaging materials, e.g. plastic film and polystyrene, can be dangerous for children. Danger of suffocation! Keep packaging material away from chil- dren. How to avoid damaging the appliance • In the case of thermal failure, switch the solid plate off and allow to cool down completely.

  • Page 10: Disposal

    Disposal Packaging • All packaging materials (cardboard, plastic film (PE) and polystyrene (EPS)) are marked and should, if possible, be collected for recycling and disposed of in an environmentally friendly way. Disconnection • Disconnect the appliance from the mains. With a fixed appliance, this is to be carried out by a qualified electrician! Safety •...

  • Page 11: Using For The First Time

    Using for the first time The appliance must be installed and connected to the electricity sup- ply in accordance with the separate installation instructions. Have a qualified fitter/electrician carry out the necessary work. Unpleasant odours can develop during the initial operating hours of a cooking zone.

  • Page 12: Your Appliance

    Your appliance Appliance overview GK37TIMPS, GK37TIMPSC, GK37TIMPSF, GK37TIMPSF spec. • 3 cooking zones Ø 210 mm GK46TIABS, GK46TIABSC, GK46TIABSF, GK46TIABSU, GK46TIABS.1F • 1 frying zone Ø 180/280 mm • 1 cooking zone Ø 210 mm • 1 cooking zone Ø 180 mm • 1 cooking zone Ø 145 mm GK47TIMPS, GK47TIMPSC, GK47TIMPSF •...
  • Page 13 4 Your appliance GK47TIMAS, GK47TIMASC, GK47TIMASF • 2 cooking zones Ø 210 mm (back) • 2 cooking zones Ø 180 mm (front) GK36TIPS, GK36TIPSC, GK36TIPSF, GK36TIPSF spec. • 1 dual ring cooking zone Ø 180/260 mm • 1 cooking zone Ø 210 mm • 1 cooking zone Ø 145 mm GK46TIPS, GK46TIPSC, GK46TIPSF, GK46TIPSF spec.

  • Page 14: Operating And Display Elements

    4 Your appliance Operating and display elements GK36TI… / GK37TI … GK46TI … / GK47TI … Buttons Device ON/OFF Slider (to set the power level) PowerPlus Pause cooking ON/OFF and restore function Operating time/timer Wipe protection ON/OFF...

  • Page 15: How Induction Hobs Function

    4 Your appliance Displays Power level of the cooking zone Operating time activated Pause activated/restoration of saved settings possible Cooking zone indicator light for the operating time Operating time/timer Wipe protection activated How induction hobs function Induction hobs function considerably differently to conventional hobs or solid plates.

  • Page 16: Pan Detection

    4 Your appliance Pan detection Every cooking zone is equipped with pan detection. This recognises cookware with a magnetisable base that is suitable for use with induction hobs. • If the cookware is removed during operation or unsuitable cookware is used, –...

  • Page 17: Flexible Cooking

    4 Your appliance Coated cookware • Coated cookware when empty may never be heated at a higher power level than – The coating may otherwise become overheated and damaged. • For frying, do not use a higher power level than Never use PowerPlus with coated frying pans.

  • Page 18: Operating The Appliance

    Operating the appliance Switching the appliance on and off Operation is roughly the same for all appliances. ► Switching on the appliance: Hold button down for 1 second. – If there is no further input, the appliance switches off after 10 seconds for safety reasons.

  • Page 19: Overview Of Power Levels

    5 Operating the appliance Overview of power levels Power level Cooking method Keeping warm Sauces, keeps food ready for serving at around 65 °C Melting, gentle Butter, chocolate, gelatine, sauces warming Swelling Rice Continued cooking, Vegetables, potatoes, sauces, fruit, reducing, stewing fish Continued cooking, Pasta, soup, braised meat...

  • Page 20: Powerplus

    5 Operating the appliance PowerPlus All the cooking zones are equipped with the PowerPlus booster. When PowerPlus is switched on, the cooking zone selected works at extra high power for 10 minutes. PowerPlus can be used, for instance, to heat a large quantity of water quickly.
  • Page 21 5 Operating the appliance Power management GK37TIMPS, GK37TIMPSC, GK37TIMPSF, GK37TIMPSF spec. PowerPlus cannot be used on all cooking zones at the same time. If Power- Plus is active, the other cooking zones run on less power. PowerPlus in Maximum available power level in cooking zone cooking zone Level 9 in cooking Maximum available power level in cooking zone...
  • Page 22 5 Operating the appliance GK46TIABS, GK46TIABSC, GK46TIABSF, GK46TIABSU, GK46TIABS.1F PowerPlus cannot be used for both cooking zones of a group (A or B) at the same time. If PowerPlus is activated for both cooking zones of a group, the power of the cooking zone that was initially set reduces. PowerPlus in cooking zone Group A* PowerPlus in cooking zone...
  • Page 23 5 Operating the appliance GK47TIMPS, GK47TIMPSC, GK47TIMPSF PowerPlus cannot be used for both cooking zones of a group (A or B) at the same time. If PowerPlus is activated for both cooking zones of a group, the power of the cooking zone that was initially set reduces. PowerPlus in cooking zone Group A* PowerPlus in cooking zone...
  • Page 24 5 Operating the appliance GK47TIMAS, GK47TIMASC, GK47TIMASF PowerPlus cannot be used for both cooking zones of a group (A or B) at the same time. If PowerPlus is activated for both cooking zones of a group, the power of the cooking zone that was initially set reduces. PowerPlus in cooking zone Group A* PowerPlus in cooking zone...
  • Page 25 5 Operating the appliance GK36TIPS, GK36TIPSC, GK36TIPSF, GK36TIPSF spec. PowerPlus cannot be used on all cooking zones at the same time. If Power- Plus is active, the other cooking zones run on less power. PowerPlus in Maximum available power level in cooking zone cooking zone 3A + B –...
  • Page 26 5 Operating the appliance GK46TIPS, GK46TIPSC, GK46TIPSF, GK46TIPSF spec. GK46TIAS, GK46TIASC, GK46TIASF, GK46TIASU, GK46TIAS.1F PowerPlus cannot be used for both cooking zones of a group (A or B) at the same time. If PowerPlus is activated for both cooking zones of a group, the power of the cooking zone that was initially set reduces.

  • Page 27: Automatic Boost

    5 Operating the appliance Automatic boost Do not leave the hob unattended when using the automatic boost. Risk of boiling over, burning on and igniting! All the cooking zones are equipped with a selectable automatic boost. With this function, a cooking zone works at power level for a certain length of time (see table).

  • Page 28: Operating Time

    5 Operating the appliance Operating time Do not leave the hob unattended during use. Risk of boiling over, burning on and igniting! With the operating time function, a Cooking zone switches off automatically after a set time 1–99 min.. Setting the operating time ►...
  • Page 29 5 Operating the appliance Switching the operating time off before time ► Press the button. ► On the slider of the required cooking zone, touch – flashes on the operating time/timer display. – The cooking zone remains in operation. End of the operating time When the operating time is up –...

  • Page 30: Timer

    5 Operating the appliance 5.10 Timer The timer functions like an egg timer (1–99 min.). It can be used at any time and independently of all other functions. Setting the timer ► Switch on the appliance. ► Press the button 2×. –...

  • Page 31: Childproof Lock

    5 Operating the appliance 5.11 Childproof lock The childproof lock is to prevent the appliance from being accidentally switched on. Switching the childproof lock on ► Switch on the appliance. No cooking zone must be in operation. ► Touch the buttons at the same time.

  • Page 32: Restore Function

    5 Operating the appliance Switching the childproof lock off ► Switch on the appliance. No cooking zone must be in operation. ► Touch the buttons at the same time. – An acoustic signal is emitted. ► Press the button again. –...

  • Page 33: Pause Cooking

    5 Operating the appliance 5.13 Pause cooking With this function, the power level of all cooking zones that are switched on can be temporarily reduced to for up to 10 minutes. Operation can be resumed with the previous settings after a cooking pause. ►...

  • Page 34: User Settings

    User settings The following user settings can be individually set and saved: User setting Default setting Factory setting Acoustic signal No acoustic signal volume 1-8 Adjustable gradually (1 = quiet, 8 = loud) Acoustic signal No acoustic signal at the end of Off automatically after 10 s the operating Off automatically after 1 min...

  • Page 35: Changing User Settings

    6 User settings Changing user settings ► When the hob is switched off, hold down the button and touch the 3 slider areas from left to right within 1 second. – Each touch is confirmed with an acoustic signal. A double acoustic signal is emitted for an incorrect entry. –...

  • Page 36: Care And Maintenance

    Care and maintenance Preferably, do not clean the appliance until it is cold. Burns hazard! Clean the hob after every use in order to prevent food residues from burning on. Cleaning dried-on and burnt-on dirt requires more effort. If the appliance is not cleaned correctly, the appearance and surface could be damaged.

  • Page 37: Trouble-Shooting

    Trouble-shooting What to do if ..the appliance does not function and all displays are dark? Possible cause Solution • The fuse or automatic cir- ► Change the fuse. cuit breaker of the flat or ► Reset the circuit breaker. house wiring system is de- fective.
  • Page 38 8 Trouble-shooting ... A continuous acoustic signal is emitted, flashes in a display and the appli- ance switches off? Possible cause Solution • A button or a slider was ► Remove object or food that has boiled over. touched for longer than ►...
  • Page 39 8 Trouble-shooting flashes in the display? Possible cause Solution • An interruption in the ► Press any button to quit the error message. mains power supply. ► Put the appliance into operation as usual. … are illuminated in the display? Possible cause Solution •...

  • Page 40: Technical Data

    Technical data Product fiche In accordance with EU Regulation No. 66/2014 Model number GK 31038 Type designation GK GK37TIMPS/C/F/F spez. Number of cooking zones Heating technology Radiant cooking zone Diameter of round cooking zones Energy consumption per Wh/kg 198.2 193.3 200.6 cooking zone Energy consumption for...
  • Page 41 9 Technical data Modellnummer GK 31036 Typenbezeichnung GK GK47TIMPS/C/F Anzahl Kochzonen Heiztechnologie Radiant cooking zone Durchmesser der runden Kochzonen Energieverbrauch pro Wh/kg 181.3 171.3 196.1 193.4 Kochzone Energieverbrauch des Wh/kg 185.5 gesamten Kochfeldes EC Model number GK 31037 Type designation GK GK47TIMAS/C/F Number of cooking zones Heating technology...
  • Page 42 Index Operating time .......... 28 Cancelling before time...... 29 Appliance Changing .......... 28 Switching on and off...... 18 End of the operating time.... 29 Appliance-specific safety precautions ..7 Setting .......... 28 Automatic boost........27 Several operating times.... 29 Switching on ........ 27 Overview of power levels ......19 Care and maintenance ......
  • Page 43 10 Index Cancelling before time...... 35 Using for the first time ......11 Validity............2 Where is the identification plate? ............... 11 Wipe protection......... 33...
  • Page 44 Notes...
  • Page 47 The identification plate and connection plate are located on the underside of the hob. Requesting repairs You can contact your nearest V-ZUG service centre directly and free of charge on our ser- vice hotline – 0800 850 850. When requesting repairs over the phone, we will agree on an appointment for us to visit your site at your earliest convenience.
  • Page 48 Switching the cooking zone off ► Touch on the slider. Switching the appliance off Press the button. J973013-R06 V-ZUG Ltd, Industriestrasse 66, CH-6301 Zug Tel. +41 58 767 67 67, Fax +41 58 767 61 61 info@vzug.com, www.vzug.com Service Centre: Tel. 0800 850 850...
