ATTACH YOUR RECEIPT HERE AND REGISTER YOUR FAN AT FANIMATION.COM
READ AND SAVE THESE INSTRUCTIONS
Purchase Date
Questions, problems, missing parts? Before returning to your retailer, call our customer
service department at 1-888-567-2055, 8 a.m.-5 p.m., EST, Monday-Friday.
CEILING FAN
PALMA
™
MODEL #FP6258BNMW
Net Weight 24.69 lbs (11.2 kgs)
Español p. 18
.
Advertisement
Table of Contents
Related Manuals for Fanimation PALMA FP6258BNMW
Summary of Contents for Fanimation PALMA FP6258BNMW
- Page 1 PALMA ™ MODEL #FP6258BNMW Español p. 18 ATTACH YOUR RECEIPT HERE AND REGISTER YOUR FAN AT FANIMATION.COM READ AND SAVE THESE INSTRUCTIONS Purchase Date Net Weight 24.69 lbs (11.2 kgs) Questions, problems, missing parts? Before returning to your retailer, call our customer...
-
Page 2: Table Of Contents
Fanimation. 8. Fanimation reserves the right to modify or discontinue any product at any time and may substitute any part under this warranty. 9. Under no circumstances may a fan be returned without prior authorization from Fanimation. The receipt of purchase must ac- company authorized returns and must be sent freight prepaid to Fanimation. -
Page 3: Unpacking Instructions
– Phillips Screwdriver 4˝ Fanimation. Substitution of parts or accessories not • Housing Assembly – Wire Connectors designated for use with this product by Fanimation could • Light Screw Cover Assembly – Balance Kit result in personal injury or property damage. Contact •... -
Page 4: Energy Efficient Use Of Ceiling Fans
8 - 9 feet above the floor for optimal airflow. Consult your down into the occupied space.Remember to adjust your Fanimation Retailer for optional mounting accessories. thermostat when using your ceiling fan - additional energy and dollar savings could be realized with this simple step! Turn Off When Not in the Room Ceiling fans cool people, not rooms. - Page 5 Electrical and Structural Requirements (Continued) Deep box with brace (Figure 3) Paired with a deep box, this hanger is meant to span CEILING JOIST between two joists and takes the place of wooden blocking. WARNING To reduce the risk of fire, electric shock, or personal injury, mount to outlet box marked acceptable for fan support of 15.9 kg (35 lbs) or less and use mounting screws provided with the outlet box.
-
Page 6: How To Assemble Your Ceiling Fan
How to Assemble Your Ceiling Fan 1. Remove the hanger ball portion from the downrod/ hanger ball assembly by loosening the set screw in the hanger ball until the ball falls freely down the downrod. Downrod Remove the pin from the downrod, then remove the hanger ball. - Page 7 How to Assemble Your Ceiling Fan (continued) 5. Route wires through motor coupling cover, canopy screw cover and ceiling canopy. (Figure 5) Ceiling Canopy Motor Coupling Cover Canopy Screw Cover Figure 5 6. Reinstall the hanger ball on the downrod as follows. Route the black, white and blue wires and safety cable through the hanger ball.
-
Page 8: How To Hang Your Ceiling Fan
How to Hang Your Ceiling Fan WARNING To avoid possible electrical shock, be sure electricity is turned off at the main fuse box before hanging. (Figure 1) MAIN FUSE BOX NOTE: If you are not sure if the outlet box is grounded, contact a licensed electrician for advice, as it must be grounded for safe operation. -
Page 9: How To Wire Your Ceiling Fan
How to Wire Your Ceiling Fan NOTE: If fan or supply wires are different colors than indicated, ha WARNING To avoid possible electrical shock, be sure electricity is turned off at the main fuse box before wiring. MAIN FUSE BOX (Figure 1). -
Page 10: How To Install Your Canopy Housing
How to Install Your Canopy Housing NOTE: This step is applicable after the neccessary wiring is completed. 1. Remove one of the two shoulder screws in the hanger bracket. Loosen the second shoulder screw without fully removing it. Assemble canopy by rotating key slot in canopy over shoulder screw in hanger bracket. -
Page 11: How To Assemble Your Light Kit Assembly Or Cap
How to Assemble Your Light Kit Assembly or Cap 1. Remove one of the three screws in the adaptor plate at the bottom of the motor assembly. Slightly loosen the remaining two screws. (Figure 1) Motor Assembly Figure 1 2. Assemble the housing assembly to the adaptor plate of the motor assembly using the two key slots in the housing assembly. -
Page 12: How To Operate Your Ceiling Fan
How to Assemble Your Light Kit Assembly or Cap (continued) Securely attach the light screw cover assembly LED Assembly Steel Cap over the screws in the housing assembly utilizing the key slot twist-lock feature. (Figure 6) Light Screw Light Screw Housing Housing Assembly... -
Page 13: Maintenance
Maintenance n i l CAUTION maintenance that is needed. Do not use solvents when cleaning your ceiling fan. It When cleaning, use only a soft brush or lint free cloth could damage the motor or the blades and create the possibility of electrical shock. -
Page 14: Parts List
Parts List Model #FP6258BNMW Ref. # Description Part # AP255BL Hanger Bracket Assembly Hanger Ball/Downrod Assembly ADR1-6BN P625801BN Canopy AP260BN Canopy Screw Cover Assembly Motor Coupling Cover APPAC1412BN AMA6258BN Fan Motor Assembly Upper Housing Assembly AP625802MW Blade Holder Set AP625813BN Blade Set AP623603MW LED Assembly... -
Page 15: Exploded-View Illustration
PALMA ™ Model FP6258BNMW Exploded-View Illustration NOTE: u l l s t i... -
Page 16: Trouble Shooting
6. Fan blades out of balance. 6. Balance blades using balance kit provided in hardware bag. 1. If possible, consider using a longer 4.NOT ENOUGH AIR downrod (not included, you can buy MOVEMENT the longer downrod from fanimation.com). - Page 17 10983 Bennett Parkway Zionsville, IN 46077 Phone: 888-567-2055 Outside U.S.: 317-733-4113 2017/01 V.01 FAX: 866-482-5215 Copyright 2017 Fanimation FANIMATION.COM...
