Dynojet Power Commander V Installation Instructions Manual page 4

FIG.D
PCV connector
Stk connector
FIG.E
Unplug
FIG.F
14-001 www.powercommander.com
6 Plug the YELLOW colored wires from the PCV in-line of the rear injector and
stock wiring harness (Fig. D).
PCV connector
7 Unplug the stock wiring harness from the front injector (Fig. E).
This injector is located on the right hand side of the bike.
8 Plug the ORANGE colored wires from the PCV in-line of the front injector and
stock wiring harness (Fig. F).
09-11 Ducati M696 PCV - 4
