sauder.com
Entertainment Credenza
Harvest Mill Collection | Model 403891
Need help? Visit Sauder.com to view video assembly tips or chat with a live rep.
Prefer the phone? Call 1-800-523-3987.
Share your journey!
Smart stand
for the idiot box.
NOTE: THIS INSTRUCTION
BOOKLET CONTAINS IMPORTANT
SAFETY INFORMATION.
PLEASE READ AND KEEP FOR
FUTURE REFERENCE.
English pg 1-22
Français pg 23-25
Lot # 346467
08/24/12
Purchased: __________________
Be sure to give us a ring before
making any returns. 1-800-523-3987
Advertisement
Related Manuals for Sauder Entertainment Credenza 403891
Summary of Contents for Sauder Entertainment Credenza 403891
- Page 1 Harvest Mill Collection | Model 403891 NOTE: THIS INSTRUCTION BOOKLET CONTAINS IMPORTANT SAFETY INFORMATION. Need help? Visit Sauder.com to view video assembly tips or chat with a live rep. PLEASE READ AND KEEP FOR FUTURE REFERENCE. Prefer the phone? Call 1-800-523-3987.
- Page 2 • Check the size and weight of your TV. Compare it to the diagram below – before you begin assembly! • This Sauder unit is designed for use with televisions weighing less than 95 pounds. Never use with a TV that weighs more.
- Page 3 RIGHT BACK (1) LEFT UPRIGHT (1) SMALL ADJUSTABLE SHELF (2) LEFT BACK (1) TOP (1) SIDE SKIRT (2) RIGHT SKIRT (1) BOTTOM (1) FRONT MOLDING (1) LEFT SKIRT (1) BACK (1) MOLDING (2) BRACE (1) END MOLDING (2) www.sauder.com/services 403891 Page 3...
- Page 4 -Refer to instruction book for complete safety information. Note: This is a permanent label. Do not try to remove. Surface will be damaged. 02/ 02 269227 (Refer to the last step for proper location and application) Page 4 403891 www.sauder.com/services...
- Page 5 BLACK 1-1/4" FLAT HEAD SCREW - 9 SILVER 1-1/4" PAN HEAD SCREW - 2 BLACK 1-1/8" MACHINE SCREW - 2 BLACK 9/16" LARGE HEAD SCREW - 18 CONNECTOR SCREW - 2 NAIL - 15 SILVER 5/8" FLAT HEAD SCREW - 8 www.sauder.com/services 403891 Page 5...
- Page 6 Look for this icon. It means a Step 1 video assembly tip is available at www.sauder.com/services/tips Assemble your unit on a carpeted fl oor or on the empty å carton to avoid scratching your unit or the fl oor. Insert a CONNECTOR SCREW (PP) into each å...
- Page 7 å Then, insert a CAM DOWEL (W2) into each HIDDEN CAM. Do not tighten the HIDDEN CAMS in this step. Arrow (4 used) Arrow Insert the metal end of the CAM DOWEL into the HIDDEN CAM. www.sauder.com/services 403891 Page 7...
- Page 8 Fasten the SIDE MOLDINGS (P) to the ENDS (A). Use four å BLACK 1-7/8" FLAT HEAD SCREWS (HH). BLACK 1-7/8" FLAT HEAD SCREW (4 used in this step) Unfi nished edge Notched edge These edges must be even. Unfi nished edge Notched edge Page 8 403891 www.sauder.com/services...
- Page 9 Step 5 Fasten the FRONT MOLDING (M) to the TOP (D). Use fi ve å BLACK 1-1/4" FLAT HEAD SCREWS (JJ). BLACK 1-1/4" FLAT HEAD SCREW (5 used in this step) Rounded edge www.sauder.com/services 403891 Page 9...
- Page 10 BACK fastened. The unit may collapse. r f a o l e w i t BLACK 1-1/4" FLAT HEAD SCREW (4 used in this step) Notched edge l e s r f a Notched edge w i t Rounded edge Page 10 403891 www.sauder.com/services...
- Page 11 Step 7 Slide the END MOLDINGS (O) onto the notched edges of å the ENDS (A). *U.S. Patent No. 5,499,886 å Notched edge Notched edge www.sauder.com/services 403891 Page 11...
- Page 12 Fasten the MOLDINGS (N) to the ENDS (A). Use four å BROWN 1-1/2" FLAT HEAD SCREWS (II). Holes are closer to this edge. BROWN 1-1/2" FLAT HEAD SCREW (4 used in this step) Holes are closer to this edge. Surface with more holes Page 12 403891 www.sauder.com/services...
- Page 13 Insert the METAL PINS (EE) in one edge of the BACKS (Q and R) å into the holes in the ENDS (A). (8 used) F i n i s h r f a F i n i s h r f a www.sauder.com/services 403891 Page 13...
- Page 14 Tighten Risk of damage or Arrow injury. HIDDEN CAMS must be completely Arrow Maximum tightened. HIDDEN 210 degrees CAMS that are not completely tightened may loosen, and parts may separate. To Minimum completely tighten: 190 degrees Page 14 403891 www.sauder.com/services...
- Page 15 SIDE SKIRTS (K). Use nine BLACK 9/16" LARGE HEAD SCREWS (MM). NOTE: Be sure the METAL BRACKETS are even with the å edges of the BRACE and SIDE SKIRTS. BLACK 9/16" LARGE HEAD SCREW (9 used in this step) (9 used) www.sauder.com/services 403891 Page 15...
- Page 16 METAL BRACKETS and into the BOTTOM. Fasten the BRACE (G) to the SIDE SKIRTS (K). Use two å Edge with BLACK 9/16" LARGE HEAD SCREWS (MM) through the HIDDEN METAL BRACKETS and into the SIDE SKIRTS. CONNECTOR Edge with HIDDEN CONNECTOR Page 16 403891 www.sauder.com/services...
- Page 17 To fasten two parts together using the HIDDEN CONNECTORS, insert your screwdriver, at an angle, into the slot in the HIDDEN CONNECTOR. While pushing the screw into the hole of the adjoining part, turn the screwdriver clockwise to tighten. www.sauder.com/services 403891 Page 17...
- Page 18 NOTE: Do not tap NAILS along the top edge of the back. å NOTE: Perforations have been provided for access å through the BACK. Carefully cut out the holes needed. NAIL (15 used in this step) Do not tap NAILS along the top edge of the BACK. Page 18 403891 www.sauder.com/services...
- Page 19 Step 15 Fasten four HINGES (Y) and four HINGE SPACERS (AA) to the å DOORS (H). Use eight SILVER 5/8" FLAT HEAD SCREWS (QQ). SILVER 5/8" FLAT HEAD SCREW (8 used in this step) www.sauder.com/services 403891 Page 19...
- Page 20 Fasten a BACKPLATE (DD) and KNOB (CC) to the DOOR (H). Use a BLACK 1-1/8" å MACHINE SCREW (LL). Mounting screw Repeat this step for the other door. å (2 used) BLACK 1-1/8" MACHINE SCREW (2 used in this step) Page 20 403891 www.sauder.com/services...
- Page 21 To adjust the DOORS in or out (depth), loosen the mounting screw one turn and move the DOORS in or å out, as needed. Tighten the mounting screw after making adjustments. Mounting screw (depth) Adjusting screw (horizontal) (vertical adjustment) www.sauder.com/services 403891 Page 21...
- Page 22 -Refer to instruction book for complete safety information. Note: This is a permanent label. Do not try to remove. Surface will be damaged. 02/ 02 269227 95 lbs. 15 lbs. 25 lbs. 25 lbs. 15 lbs. 50 lbs. total (16 used) Page 22 403891 www.sauder.com/services...
- Page 23 élément et conserver le livret pour future référence. EXTRÉMITÉ ................2 CONNECTEUR ESCAMOTABLE ......2 Pour contacter Sauder MONTANT DROIT ............. 1 EXCENTRIQUE ESCAMOTABLE ......4 en ce qui concerne cet MONTANT GAUCHE ............1 CHEVILLE D'EXCENTRIQUE ........4 élément, faire référence...
- Page 24 MARRON TÊTE PLATE 38 mm (II). Fixer les PLINTHES (S et T) aux PLINTHES LATÉRALES (K). Serrer deux CONNECTEURS ESCAMOTABLES. Fixer les PLINTHES (S et T) au DESSOUS (E). Utiliser deux VIS ARGENTÉES TÊTE GOUTTE DE SUIF 32 mm (KK). Page 24 403891 www.sauder.com/services...
- Page 25 MONTANT (C). meubles ou d’un chiff on humide. Essuyer. Fixer une FERRURE (DD) et un BOUTON (CC) à la PORTE (H). Utiliser une VIS À MÉTAUX 28 mm NOIRE (LL). Répéter cette étape pour l'autre porte. www.sauder.com/services 403891 Page 25...
- Page 26 TOUJOURS décharger les tablettes et les tiroirs, en commençant par les surface supérieures, avant de déplacer le meuble. NE JAMAIS pousser ou tirer un meuble sur de la moquette. Demander à une autre personne de le soulever correctement pour le déplacer et/ou le repositionner. Page 26 403891 www.sauder.com/services...
- Page 27 à compter de la date d'achat la première fois et qui sont signalés à Sauder dans les limites de couverture de la contre tout défaut de matériaux ou de fabrication des composantes de mobilier Sauder.
- Page 28 Dear Valued Customer: So, how did it go? Thanks so much for choosing Sauder® furniture. I hope the Set a world record for speed? purchase and assembly process was a positive experience Feeling good about yourself? and you feel good about the furniture you just built. If you Nice.
