Higham Bed With Drawer

Assembly lnstructions - Please keep for future reference

Dimensions (4'6)

Width - 146cm

Depth - 226cm

Height - 95cm

Important - Please read these instructions fully before starting assembly

If you need help or have damaged or missing parts, call the Customer Helpline: 0345 6400 800

Dimensions (5')

Width - 161cm

Depth - 236cm

Height - 95cm

248/9320

258/9127

Issue 1- 22/12/14

Need help?

Do you have a question about the Higham 248/9320 and is the answer not in the manual?

Questions and answers

Summary of Contents for Heart of House Higham 248/9320

Page 1 Higham Bed With Drawer Assembly lnstructions - Please keep for future reference 248/9320 258/9127 Dimensions (4'6) Dimensions (5') Width - 146cm Width - 161cm Depth - 226cm Depth - 236cm Height - 95cm Height - 95cm Important - Please read these instructions fully before starting assembly If you need help or have damaged or missing parts, call the Customer Helpline: 0345 6400 800 Issue 1- 22/12/14...
Page 2 Safety and Care Advice Important To reduce or put weight on the product, components and tools listed on the likelihood of the following pages. this could cause damage. damaging your product please ttings from the Assemble the item as close ensure that your plastic bags and separate them to its nal position (in the same...
Page 3: Components - Parts
lf you have damaged or missing components, call the Components - Parts Customer Helpline: Argos = 0345 6400 800 FRONT INSIDE Headboard Footboard (4'6 -146 x90 cm) (4'6 -146 x 50 cm) (5' -161 x 90 cm) (5' -161 x 50 cm) INSIDE Side rail Centre support...
Page 4 lf you have damaged or missing components, call the Components - Parts Customer Helpline: Argos = 0345 6400 800 Drawer side panel x 4 Short support leg X 4 (60 x 16 x 1.2 cm) Underside Drawer base panel x 2 Drawer front panel x 2 (106.5 x 60 x 1.2 cm) (109 x 20 x 3 cm)
Page 5 Components - Fittings lf you have damaged or missing components.call the Customer Helpline: 0345 6400 800 Height adjustable foot x 6 3 x 35mm Wood screw x 28 8 x 35mm Wood screw x 20 25mm 1/4'' Metal dowel x 8 10 x 10 mm Locking Nut x 8 3.5 x 14mm Wood Screw x 8 Spanner x 1...
Page 6 Assembly Instructions Attaching feet With help, attach feet the underside of headboard using screws Repeat for footboard Note: The exact position should be outlined.
Page 7 Assembly Instructions Attaching side rails Lay headboard footboard flat onto the floor with the fixing holes facing upwards. Loosely fit bolts into headboard footboard as shown. With help, raise the headboard into the standing position. Hang the metal brackets on the end of side rails , over the bolts in the headboard Note: Do not fully tighten...
Page 8 Assembly Instructions Preparing drawer guides Attach short support legs to the underside of the drawer guide rail using screws Screw height adjustable feet into support legs shown. Repeat for both drawer guide rails. Assembling drawer guides Assemble drawer guide rails in between side rails using screws at both...
Page 9 Assembly Instructions Preparing central support Assemble long support legs to the underside of central support using screws as shown. Screw height adjustable feet into support legs shown. Locating central support Carefully locate central support in between the headboard and footboard by locating the metal plates on each end of the central support , into the brackets...
Page 10 Assembly Instructions Assembling corner brackets Assemble corner brackets in each corner of the bed frame using screws The positions should be outlined. After checking the bed frame is correctly aligned, proceed to fully tighten all fixings from previous steps. Assembling slats Assemble single plastic slat caps onto one end of...
Page 11 Assembly Instructions Preparing drawer panels Place drawer front panel face down onto a clean flat surface. Screw metal dowels into the holes in the back of drawer front panel shown. Note: Screw metal dowels as far as shown. Do not overtighten. Locate drawer side panels onto front panel shown.
Page 12 Assembly Instructions Completing drawers Locate drawer back panel in between drawer side panels Secure drawer back panel using wood screws Holes to face up Carefully turn the drawer body upside down. Locate drawer base panel into position. Note: Ensure the fixing holes for the castors are facing up.
Page 13 Assembly Instructions Assembling castors Screw castors into drawer base panel Tighten using spanner Repeat steps 9 to 11 to assemble both drawers. Locating drawers Carefully turn the drawers over. Push the drawers under the bed, ensuring they locate in between the drawer guides. Assembly is complete.

This manual is also suitable for:

Higham 258/9127
