bromfield extendable table
Assembly Instructions
228/5548
- Please keep for future reference
Dimensions
Width - 190cm
Depth - 90cm
Height - 75cm
Important
– Please read these instructions fully before starting assembly
If you need help or have damaged or missing parts, call the Customer Helpline:
Argos = 0845 6400800
Issue 3- 20/5/14
Advertisement
Related Manuals for Heart of House 228/5548
Summary of Contents for Heart of House 228/5548
- Page 1 Assembly Instructions 228/5548 - Please keep for future reference Dimensions Width - 190cm Depth - 90cm Height - 75cm Important – Please read these instructions fully before starting assembly If you need help or have damaged or missing parts, call the Customer Helpline:...
- Page 2 Safety and Care Advice Important – Please read these instructions fully before starting assembly ‡ &KHFN \RX KDYH DOO WKH ‡ 'XULQJ DVVHPEO\ GR QRW VWDQG ‡ To reduce WKH OLNHOLKRRG RI components and tools listed on RU SXW ZHLJKW RQ WKH SURGXFW the following pages.
- Page 3 If you have damaged or missing components, call the Components - Panels Customer Helpline: Argos = 0845 6400800 Please check you have all the panels listed below (190 x 90cm) (6.5 x 72. cm)
- Page 4 Components - Fittings Note: may be supplied than are required. 80mm Bolt x 8 Washer x 8 Spring washer x 8 Hex key x 1 Felt x 2 Tools required Ruler/tape Phillips screwdriver (medium & large) Ruler - Use this ruler to help correctly identify the screws 95 100 110 115 120 125 130 135 140 145 150 155 160 165 170 The screws length is measured from the head to the point (30mm screw shown).
- Page 5 Assembly Instructions Step 1 Attaching legs Attach four legs using washer spring washer bolt . Tighten the bolts with hand. Step 2 Attaching legs Tighten the bolts with the hex key...
- Page 6 Assembly Instructions Step 3 Extension panel Open the lock. Step 4 Extension panel Pull the top apart.
- Page 7 Assembly Instructions Step 5 Extension panel Attach the felt on the L metal by hand. Step 6 Extension panel Fold up the extension.
- Page 8 Assembly Instructions Step 7 Extension panel Pull the table tops together and close the lock. Step 8 Extension panel Open the lock and pull the table tops apart.
- Page 9 Assembly Instructions Step 9 Extension panel Fold down the extension. Step 10 Extension panel Pull the table together and close the lock. Assembly is complete. If you need help or have damaged or missing parts, call the Customer Helpline: Argos = 0845 6400800...
