- Page 1 MAINS OPERATED CORDED LAWNMOWER ASSEMBLY AND OWNER'S MANUAL WARNING! Read this manual before operating your product. Register your Murray product... Take advantage of all benefits! www.MURRAY.com/Register...
- Page 2 IMPORTANT INFORMATION Details Thank you for purchasing your Murray Electric Mower. Murray prides itself in the quality and performance of all its products. This instruction manual will aid in the assembly, safe operation and maintenance of your product. Please read the following warnings to ensure safety and the long life of your product.
-
Page 3: Table Of Contents
Table of Contents Features & Definitions Features & Supplied Items Safety & Handling General Safety Electrical Safety Product Disposal Assembly Procedures Unpacking Unfolding & Adjusting Handles Fixing the Cable Installing the Grass Catcher Installing & Removing the Mulch Plug Operating Instructions Starting &... -
Page 4: Features & Supplied Items
FEATURES DEFINITIONS Features & Supplied Items Switch Box Bail Upper Handle Lower Handle Quicky Release Clamp (Upper Handle)* Full Grass Indicator Grass Bag Deck Cable Clip Clamp Assembly (Lower Handle)* Height Adjustment (position may vary on different models) Rear Wheel Hardwired Cable Front Wheel Mid Handle... -
Page 5: General Safety
General Safety • Carefully read all instructions on the machine and in the manual before attempting to assemble and operate the machine. Keep this manual in a safe place for future reference, and consult it regularly. Ensure other users read this manual and are aware of the product safety risks •... -
Page 6: Electrical Safety
Electrical Safety • This product has a rated power of 1600W (37cm Model) or 1200W (32cm Model) and input operating voltage of 220-240V, 50Hz. Do not use this product on the supply voltage other than listed, as it may result in shock. •... -
Page 7: Unfolding & Adjusting Handles
ASSEMBLY PROCEDURES Unfolding & Adjusting the Handles For 37cm Model, Refer to Figure 1, 2 & 3. • Lead the lower handle through the hole in the cable retain hang and hook on it. • Slide the two fixing blocks to the end of lower handle. •... -
Page 8: Installing The Grass Catcher
ASSEMBLY PROCEDURES Installing the Grass Catcher NOTE: Refer to Figure 8. • Lift the grass catcher by its handle and place under the rear flap so that the hooks on the grass catcher frame are seated into the slots in the handle bracket. •... -
Page 9: Starting & Stopping
OPERATING INSTRUCTIONS Starting & Stopping For Your Safety • Never use the mower unless the grass catcher or the guards supplied by the manufacturer are in position. • Before starting the mower check blades and bolt for damage or wear. •... -
Page 10: Cutting Height Adjustment
OPERATING INSTRUCTIONS Cutting Height Adjustment NOTE: Refer to figure 11. The location and appearance of the height adjustment lever may vary between NOTE: different models. Before using the mower for the first time, raise the cutting position to the height best suited for your lawn. -
Page 11: Quick Setup Guide
OPERATING INSTRUCTIONS Quick Setup Guide 1 - READY • Remove plug from the main power supply • Check if the grass is tall or thick • Check catcher & deck are empty of grass Don't adjust the mower without switching off and unplugging the device. -
Page 12: Mowing Tips
OPERATING INSTRUCTIONS Mowing Tips NOTE: Refer to Figure 12. A sharp blade will greatly enhance the performance of the mower, especially when cutting high grass. Be sure to check the blade and to replace it at least once per year, as described in the Maintenance section. -
Page 13: Emptying The Grass Catcher
Emptying the Grass Catcher NOTE: Refer to Figure 13. • Stop mower, allow blades to completely stop, and remove the plug from the mains. • Lift the rear flap. • Lift the grass catcher by its handle to remove from mower. •... -
Page 14: Bar Blade Replacement
Contact with the blade could result in serious personal injury. NOTE: Use only genuine replacement parts made and guaranteed by Murray. Insist on them from your parts and service dealer. -
Page 15: Cleaning
Blade Bar Replacement Cont'd NOTE: Check all fasteners often, always be sure mower is in safe operating condition. Only use Murray genuine replacement blades. Replace worn or damaged blades and bolts in sets to preserve balance. 1. Stop the mower and allow the blade to come to a complete stop. -
Page 16: Storing
Storing The following steps should be taken in order to prepare the machine for storage. • Clean the machine as described in the previous section. • Inspect the blade, and replace it or sharpen it, if required (refer to the Maintenance section). -
Page 17: Maintenance Chart
Service Cont'd • Never tamper with safety devices. Check them regularly for proper operation. NOTE: Refer to warranty card supplied with this product for service contact details. WARNING Do not at any time let brake fluids, gasoline, petroleum based products, penetrating oils, etc, to come in contact with plastic parts. -
Page 18: Troubleshooting
TROUBLESHOOTING Troubleshooting Problem Possible Cause Correction Does not start. The mower is not connected to Connect to the power supply. power supply. Grass is too long, wrapped around Start on short grass or increase the the blade. cutting height. Mower housing clogged with grass Check under the deck for clogged and debris. -
Page 19: Technical Specifications
TECHNICAL SPECIFICATIONS Technical Specifications Product Specifications Description Murray Corded Lawn Mower Model No. 2691585 2691584 Deck Type Plastic Plastic Cut Width 32cm 37cm Motor Type Brushed Brushed Motor Specification 1200 Watts 1600 Watts Motor Shaft Diameter 8.5mm 10mm Max Motor Speed (RPM) - Page 20 ©2019 Briggs & Stratton Corporation. All rights reserved. No part of this booklet may be reproduced by any means without prior written permission. All information herein is subject to change without notice. Murray is a registered trademark of Briggs & Stratton Corporation. WWW.MURRAY.COM 2245 TECHNICAL SPECIFICATIONS UPDATED 26.02.19...
