- Page 1 Operator’s Manual Riding Mower Model MT60 Model No. Description 2690997 Parklander, 14.5HP w/38" Mower Deck 2690998 Parklander, 15.5HP w/38" Mower Deck 2690999 Parklander, 15.5HP w/42" Mower Deck Part No. 1752618 Revision ‘-’...
-
Page 2: Model Number
You never have to look far to find support and service for your mower. There are many authorized service dealers who provide quality service. You can also contact Customer Service by phone at 02 9584 7700, or on the Internet at www.murray.com or www.parklands.net. - Page 3 (#4) (#8) (#3) (#9) (#5) (#6) (#7) (#2) (#1)
- Page 4 www.parklands.net...
- Page 5 7101935...
- Page 6 3,4,5,6 3,4,5,6 www.murray.com www.parklands.net...
- Page 8 10° max ±150N max ±90N (#4) (#2) (#1) (#3) (#10) (#6) (#9) (#5) (#8) (#7) www.murray.com www.parklands.net...
-
Page 9: Table Of Contents
Table of Contents Operator Safety ........10 Assembly . -
Page 10: Operator Safety
N - DANGER: Sulfuric Acid Can Cause Blindness Or Severe could result in serious injury or death to the Burns. operator or bystanders. O - DANGER: Flush Eyes With Water. Get Medical Help Fast. The responsibility of the owner is to follow the instructions below. www.murray.com www.parklands.net... -
Page 11: Operating Safety
Operator Safety Operating Safety Power equipment is only as safe as the operator. If it is misused, or not properly maintained, it can be dangerous! Remember, you are responsible for your safety and that of those around you. Use common sense, and think through what you are doing. If you are not sure that the task you are about to perform can be safely done with the equipment you have chosen, ask a professional: contact your local authorized dealer. -
Page 12: Slope Operation
Spilled fuel needs to be cleaned up immediately. Proper maintenance is critical to the safety and performance of your unit. Be sure to perform the maintenance procedures listed in this manual, especially pe- riodically testing the safety system. www.murray.com www.parklands.net... -
Page 13: Safe Operation Practices
Operator Safety Safe Operation Practices Preparation While mowing, always wear substantial footwear and For Ride-On (Riding) Rotary Mower Machines long trousers. Do not operate the equipment when Training barefoot or wearing open sandals. Read the instructions carefully. Be familiar with the Thoroughly inspect the area where the equipment is to controls and the proper use of the equipment. - Page 14 17. Before and when backing, look behind and down for on this engine. small children. 18. Use extra care when approaching blind corners, shrubs, trees or other objects that may obscure vision. www.murray.com www.parklands.net...
-
Page 15: Assembly
Assembly Steering Wheel All fasteners are in the parts bag. Do not discard any parts or material until the unit is assembled. How To Assemble The Steering Wheel (Figure 3) WARNING: Before doing any as sembly or Make sure the front wheels point forward. maintenance to the mower, remove the wire from Slide the cover (C) over the steering post (B). -
Page 16: Important! Before You Start Mowing
Make sure the level of cut is still correct. After you mow a short distance, look at the area that was cut. If the mower housing does not cut level, see the instructions on “How To Level The Mower Housing” in the Maintenance section of this instruction book. www.murray.com www.parklands.net... -
Page 17: Features And Controls
Features and Controls location of Controls - Gear Drive Models location of Controls - Hydro-Drive Models (Figure 5) (Figure 6, 19) Blade Rotation Control (A) — Use the blade rota tion control Blade Rotation Control (A) — Use the blade rota tion control to start and stop the rotation of the blade. -
Page 18: Operation
If low, add oil slowly into the engine oil fill (C). Do not overfill. After adding oil, wait one minute and then • If fuel spills, wait until it evaporates before starting engine. recheck the oil level. Replace and tighten the dipstick. www.murray.com www.parklands.net... -
Page 19: Operation - Gear Drive Models
Operation Raise the tractor hood. How To Use The Shift lever (Figure 5) Clean the fuel cap area of dirt and debris. Remove the CAUTION: Before you move the shift lever, completely fuel cap. push the clutch/brake pedal for ward to stop the unit. If the Fill the fuel tank (A) with fuel. -
Page 20: Starting The Engine
Slowly move the throttle control to the FAST position. If the mower housing does not cut level, see the To stop the engine, turn the ignition key to the OFF instructions on “How To Level The Mower Housing” in position. Remove the key. the Maintenance section. www.murray.com www.parklands.net... -
Page 21: Operation - Hydro-Drive Models
Operation Mowing and Bagging Tips Operation - Hydro-Drive Models For a lawn to look better, check the cutting level of the mower housing. See “How To Level The Mower Using Controls Housing” in the Maintenance section. For the mower housing to cut level, make sure the tires How To Use The Throttle Control (Figure 6) have the correct amount of air pressure. - Page 22 Completely push the brake pedal (B) for ward. Lift and hold the parking brake lever (F). Remove your foot from the brake pedal (B) and then let go of the parking brake lever (F). Make sure the parking brake will hold the unit. www.murray.com www.parklands.net...
- Page 23 Operation Mowing How To Start Operation On A Hill Start the engine. How To Operate With The Mower Housing Move the blade rotation control attachment clutch to the ENGAGED position. IMPORTANT: When you operate with the mower housing, Move the throttle control to the FAST posi tion. always operate with the throttle control in the FAST position.
-
Page 24: Mowing And Bagging Tips
FAST position and the speed control pedal pushed 1/3 to 1/2 for ward. 12. After each use, clean the bottom and top of the mower housing for better performance. Also, a clean mower housing will help pre vent a fire. www.murray.com www.parklands.net... -
Page 25: Maintenance
Maintenance Maintenance Chart TRACTOR AND MOWER ENGINE Every 8 Hours or Daily First 5 Hours Check safety interlock system Change engine oil Clean debris off tractor and mower deck Every 8 Hours or Daily Clean debris from engine compartment Check engine oil level Every 25 Hours or Annually * Every 25 Hours or Annually * Check tire pressure... -
Page 26: General Recommendations
When you mow, make sure the throttle con trol is in the blade or replace the old blade with an original equipment FAST position. part. (Figure 10) Move the blade rotation control to the DISENGAGE position (A). Stop the engine. Disconnect the wire from the spark plug. www.murray.com www.parklands.net... - Page 27 Maintenance Check the blade(s). Keep a sharp edge on the blade(s). How To Check And Adjust The Drive Brake - Hydro-Drive A blade that is not sharp will cause the tips of the grass Models (Figure 13, 19) to become brown. (Figure 19) Set the parking brake.
-
Page 28: Mower Housing
Also, make sure the lift links are loose and can easily move up or down. Push down on the lift links (B) and tighten the left and right adjuster knobs (A). Make sure the adjuster knobs www.murray.com www.parklands.net... -
Page 29: Maintenance - Engine
Maintenance lubrication How To Remove The Mower Housing (Figure 20) Move the blade rotation control (A) to the DISENGAGE Where To lubricate (Gear Drive Models - Figure 16, Hydro- position. Drive Models - Figure 17) If equipped, remove the gauge wheels. Models with grease fittings: Lubricate with Move the lift lever (B) to the level adjust ment position. - Page 30 • See the Specifications section for oil capacity. (Figure 7) Remove the dipstick (A) and wipe with a clean cloth. Pour the oil slowly into the engine oil fill (C). Do not overfill. After adding oil, wait one minute and then check the oil level. www.murray.com www.parklands.net...
-
Page 31: Storage (Over 30 Days)
Warranty service is available only through Autho rized Service Clean the entire unit. Dealers. Locate your nearest dealer in our locator map at Charge the battery. www.murray.com. * Fuel System Replacement parts for the engine, transaxle, or transmission, are available from the manufac turer’s authorized service Fuel can become stale when stored over 30 days. -
Page 32: Troubleshooting
3. Replace the fuel filter. 1. Replace the blade. 2. Check for loose engine bolts. Excessive vibration. 3. Decrease the air pressure in the tires. 4. Check for a damaged belt or damaged pulley. Replace the damaged parts. www.murray.com www.parklands.net... - Page 33 Troubleshooting Troubleshooting Chart Continued Problem Correction 1. Stop the engine. Clean the mower housing. 2. Raise the height of cut. 3. Replace or sharpen the blade(s). The grass does not discharge 4 Use a slower ground speed. correctly. 5. Move the throttle control to the FAST position. 6.
-
Page 34: Warranties
This warranty is effective for the time periods and subject to the conditions stated below. For warranty service, find the nearest Authorized Service Dealer using our dealer locator at www.BriggsandStratton.com or www. Murray.com. There is no other express warranty. Implied warranties, including those of merchantability and fitness for a particular purpose, are limited to one year from purchase or to the extent permitted by law. - Page 35 Warranties...
-
Page 36: Specifications
(air cleaner, exhaust, charging, cooling, carburetor, fuel pump, etc.), application limitations, ambient operating conditions (temperature, humidity, altitude), and engine-to-engine variability. Due to manufacturing and capacity limitations, Briggs & Stratton may substitute an engine of higher rated power for this Series engine. www.murray.com www.parklands.net...
