YOSEMITE DESK
ASSEMBLY INSTRUCTIONS
A. TOP 1PC
B. DRAWER BOTTOM 2PCS
C. LEG RIGHT 1PC
D. LEG LEFT 1PC
E. CROSS BAR 1PC
1
2
08
ALLEN BOLT
PCS
M8 x 40 MM
6
7
SPANNER
01
PC
N13
TOOL REQUIRED
PHILLIPS HEAD SCREW
DRIVER NOT PROVIDED
3
02
ALLEN BOLT
WASHER
PCS
M8 x 60 MM
M9/22
8
SCREW
24
HANDLE
PC
M4 x 15 MM
DESK ASSEMBLED
4
08
08
SPRING WASHER
PCS
PCS
M9/11
9
ALLEN BOLT
4
08
M4 x 35 MM
PCS
PCS
5
HALF MOON
02
WASHER
PCS
Advertisement
Table of Contents
Related Manuals for Modus Furniture Yosemite 7YC996D
Summary of Contents for Modus Furniture Yosemite 7YC996D
- Page 1 YOSEMITE DESK ASSEMBLY INSTRUCTIONS A. TOP 1PC DESK ASSEMBLED B. DRAWER BOTTOM 2PCS C. LEG RIGHT 1PC D. LEG LEFT 1PC E. CROSS BAR 1PC HALF MOON ALLEN BOLT ALLEN BOLT WASHER SPRING WASHER WASHER M8 x 40 MM M8 x 60 MM M9/22 M9/11 ALLEN BOLT...
- Page 2 ON A FLAT, LEVEL AREA LAY DOWN A CLEAN BLANKET OR A TOWEL TO PLACE THE TOP (A) UPSIDE DOWN ON. OPEN BOTH SETS OF DRAWERS TO FULL EXTENSION. ATTACH THE LEG RIGHT (C) TO THE TOP (A) USING FOUR M8X40 ALLEN BOLTS (1), SPRING WASHERS (4) AND FLAT WASHERS (3).
- Page 3 ATTACH THE LEG LEFT (D) TO THE TOP (A) USING FOUR M8X40 ALLEN BOLTS (1), SPRING WASHERS (4) AND FLAT WASHERS (3). FASTEN THE CROSS BAR (E) TO THE LEG LEFT (D) USING ONE HALF MOON WASHER (5) AND M8X60 ALLEN BOLT (2).
- Page 4 STEP 5: STEP 6: ASSEMBLY COMPLETE.
