HERRINGBONE FULL/QUEEN PLATFORM BED
ASSEMBLY INSTRUCTIONS
BOX #1
BOX #1
A. HEADBOARD 1PC
BOX #3
C. LEFT SIDE RAIL 1 PC
D. RIGHT SIDE RAIL 1 PC
E. CENTER SLAT SUPPORT 1 PC
F. SLAT SUPPORT LEG 2 PCS
C
D
ASSEMBLY COMPLETE
TOOL REQUIRED PHILLIPS HEAD SCREW DRIVER
A
F
E
(NOT PROVIDED)
BOX #2
B. PANEL FOOTBOARD 1 PC
G. SLAT ROLL 1 SET
HARDWARE PACKED IN BOX #2
1
ALLEN BOLT (M8X50)
2
ALLEN BOLT (M8X60)
3
ALLEN BOLT (M6X60)
4
SPRING WASHER (M8)
5
FLAT WASHER (M8)
6
WOOD DOWEL (M8X30)
7
WOOD SCREW (M4X30)
ALLEN KEY
8
9
BRACKET
10
WOOD SCREW (M4X15)
MODUS
F U R N I T U R E
B
G
4 PCS
4 PCS
2 PCS
8 PCS
8 PCS
4 PCS
6 PCS
1 PC
1 PC
6 PCS
