- Page 1 IM3013 07/2019 REV05 ® COOL ARC OPERATOR’S MANUAL ENGLISH Lincoln Electric Bester Sp. z o.o. ul. Jana III Sobieskiego 19A, 58-263 Bielawa, Poland www.lincolnelectric.eu...
-
Page 2: Table Of Contents
12/05 THANKS! For having chosen the QUALITY of the Lincoln Electric products. Please Examine Package and Equipment in case of Damage. Claims for material damaged in shipment must be notified immediately to the dealer. For future reference record in the table below your equipment identification information. Model Name, Code &... -
Page 3: Technical Specifications
Technical Specifications NAME INDEX COOL ARC ® K14037-1 INPUT Input Voltage U Rated current Frequency 230 10% single phase 0,95A 50 Hz RATED OUTPUT AT 40°C Flow range 0,5 to 3,3 l/min with torch 4,5m: 1,7 1,8 l/min with torch 3,8m: 1,3 ... -
Page 4: Electromagnetic Compatibility (Emc)
If any electromagnetic disturbances are detected the operator must put in place corrective actions to eliminate these disturbances with, if necessary, assistance from Lincoln Electric. Before installing the machine, the operator must check the work area for any devices that may malfunction because of electromagnetic disturbances. -
Page 5: Safety
Failure to follow the instructions in this manual could cause serious personal injury, loss of life, or damage to this equipment. Read and understand the following explanations of the warning symbols. Lincoln Electric is not responsible for damages caused by improper installation, improper care or abnormal operation. -
Page 6: Installation And Operator Instructions
CYLINDER MAY EXPLODE IF DAMAGED: Use only compressed gas cylinders containing the correct shielding gas for the process used and properly operating regulators designed for the gas and pressure used. Always keep cylinders in an upright position securely chained to a fixed support. Do not move or transport gas cylinders with the protection cap removed. - Page 7 Installation WARNING UNPLUG THE COOLER BEFORE FILLING THE RESERVOIR. Filling: Tilt the unit backward and pour 8,5 liters of coolant into the reservoir fill hole through a funnel. If 2,5 liter antifreeze fill bottle or fill bottle is available, tilt the unit forward until the bottle mates with the reservoir fill hole.
- Page 8 reservoir. Mounting Before water hoses installing to the cooler, you should check if the tread of the connector water hose nut matches the quick water connectors placed in the connector block on the back of the unit. All Lincoln products have water hoses which are equipped with 5/8"-18 left hand nuts so hose connectors must be matched the quick water fittings on the back of the cooler, in the following way:...
- Page 9 Vertical Installation COOL ARC ® 25 on a Power Source with a Cylinder Undercarriage For the COOL ARC ® 25 vertically mounted on a power source with a cylinder undercarriage, you should use the main mounting bracket. For proper installation, you should see Figure 3A and Figure 3B.
- Page 10 Maintenance WARNING For any repair operations, modifications or maintenance, it is recommended to contact the nearest Technical Service Center or Lincoln Electric. Repairs and modifications ® Figure 7 Circulation of COOL ARC performed by unauthorized service or personnel will cause the manufacturer’s warranty to become null and 1.
- Page 11 Lincoln Electric is not in a position to warrant or coolant system. Add new coolant when cleaning is guarantee such advice, and assumes no liability, with finished.
- Page 12 WARNING If for any reason you do not understand the test procedures or are unable to perform the tests/repairs safely, contact the nearest authorized Technical Service Center or Lincoln Electric for technical troubleshooting assistance before you proceed. LOCATE PROBLEM RECOMMENDED COURSE OF POSSIBLE CAUSE (SYMPTOM).
-
Page 13: Weee
12/05 Part List reading instructions Do not use this part list for a machine if its code number is not listed. Contact the Lincoln Electric Service Department for any code number not listed. Use the illustration of assembly page and the table below to determine where the part is located for your particular code machine. -
Page 14: Accessories
Accessories W000010167 FREEZCOOL (coolant) English English...
