Hughes & Kettner TubeMeister 18 Series Service Documents

Hide thumbs

page of 32

/ 32
Bookmarks

Quick Links

Download this manual

Service Documents

Confidential, for authorized service technicians only!

Do not disclose this information to or share these documents

Vertraulich! Nur für autorisierte Servicetechniker!

HU0910

Nicht zur Weitergabe an Dritte freigegeben!

TM 18

Note!

The components used in this product - particularly parts

affecting safety as well as speakers and transformers -

were developed and manufactured to certain specifications.

Please use original spare parts only to ensure the product

remains fully functional and safe.

TECHNICAL SERVICE:

Stamer Musikanlagen GmbH • Magdeburger Str. 8 • 66606 St.Wendel • Germany

Music & Sales P.E. GmbH • Leipziger Str. 3 • 66606 St.Wendel • Germany

with third parties.

Head

Achtung!

Die in diesem Produkt verwendeten Komponenten, insbeson-

dere sicherheitsrelevante Teile, Lautsprecher und Transforma-

toren wurden nach spezifischen Vorgaben entwickelt und ge-

fertigt. Bitte benutzen Sie ausschließlich Original-Ersatzteile –

nur so ist die volle Funktionalität und Sicherheit gewährleistet.

Need help?

Do you have a question about the TubeMeister 18 Series and is the answer not in the manual?

Questions and answers

Summary of Contents for Hughes & Kettner TubeMeister 18 Series

Page 1 Service Documents Confidential, for authorized service technicians only! Do not disclose this information to or share these documents with third parties. Vertraulich! Nur für autorisierte Servicetechniker! HU0910 Nicht zur Weitergabe an Dritte freigegeben! TM 18 Head Note! Achtung! The components used in this product - particularly parts Die in diesem Produkt verwendeten Komponenten, insbeson- affecting safety as well as speakers and transformers - dere sicherheitsrelevante Teile, Lautsprecher und Transforma-...
Page 2 Directory features page: 3 - 9 drawing-numbers-example page: standard for single wire confection page: HU0910 - Tubemeister 18 Head page: exploded drawings: complete Rev.: page: 13 - 15 spare parts list mainboard Rev.: page: 16 - 18 rearboard Rev.: page: 19 - 20 LED-board Rev.: page: 21 - 22...
Page 3 Table of contents Connections & Control Features Standard Setup/Cable Connections Tube Safety Control (TSC) Technical Specifications Things to Do Before Operating the Amp • Please read these instructions carefully, particularly the notes on safety, before operating the amp. • The manufacturer disclaims any liability or responsibility whatsoever for any damage or defect to this and other devices resulting from misuse.
Page 4 Connections and Control Features TubeMeister 18 Head Front Panel TubeMeister 18 Combo Front Panel TubeMeister 18 Head Rear Panel TubeMeister 18 Combo Rear Panel The TubeMeister 18 features independent GAIN POWER SOAK on the back of the amp. and MASTER controls for the CLEAN and LEAD The best way to discover the amp’s sonic possibilities channels.
Page 5 To avoid very loud and unwelcome surprises, make MASTER a habit of backing the VOLUME knob of the guitar This knob adjusts the CLEAN channel’s volume connected to the TubeMeister all the way down without affecting the LEAD channel’s volume. before switching on the amp.
Page 6 BOOST is active. Connecting a footswitch disables TIP: This port gives you another hip remote-control the front panel button. You can then switch BOOST option: If you wish to control the TubeMeister 18 via footswitch only, and the button merely serves to via MIDI, connect a MIDI switcher or looper to this indicate the function’s status.
Page 7 tightly focused response, set the POWER SOAK to SPEAKER jack if you wish. To do so, simply unplug full power and turn the MASTER knob down. If the built-in speaker. you want classic rock sounds replete with spongier power tube saturation, drop the POWER SOAK MAINS IN down to a lower setting and crank the MASTER Connect the factory-included power cord (MAINS...
Page 8 Tube Safety Control (TSC) TSC adjusts bias to improve the amp’s tonal and One LED flashes constantly. technical stability and extend power tubes’ life. It The tube assigned to this flashing LED is generating does this automatically and continuously, so there is over-voltage.
Page 9 Technical Specifications TubeMeister 18 Head & Combo Preamp tubes: 2 x 12AX7 / ECC83 Power tubes: 2 x EL84 Power output: 18 watts Max. power consumption: 101 watts Mains voltage tolerance range: +/-10% Ambient operating temperature range: 0° to +35° C Mains fuse, 100 volts: 250 V / T 1.25 A L Mains fuse, 120 volts:...
Page 10 *8'=/4-4;3(+89 +>'362+ -0*=7& 5(9,6,21 9(56,21 6(5,$/ 180%(5 '(3$570(17 5 5 ' &+$5$&7(5 %/ 6+((7 0(7$/ %/(&+ (; (;3/2'(' '5$:,1* (;3/26,216=(,&+181* += &$%,1(7 +2/=*(+86( .8 3/$67,& .8167672)) /3 3&% /(,7(53/$77(1 62 0,6&(//$1(286 62167,*(6 63 6&+(0$7,& 6&+$/73/1( 75 75$16)250(5 75$16)250$725 *.
Page 11 Stand 17. Jun 04 Standard for single wire confection. 485 W 1015 style 1015 according UL specifications I = completely insulated with black shrinktube or appropriate sleeve IT = partly insulated; only crimp connection insulated. no marking = without insulation Z = with additional junction no marking = without additional junction W = angled faston...
Page 12 Service Documents HU0910 Tubemeister TM 18 Head Confidential, for authorized service technicians only! Do not disclose this information to or share these documents with third parties. TECHNICAL SERVICE: Stamer Musikanlagen GmbH • Magdeburger Str. 8 • 66606 St.Wendel • Germany Music &...
Page 15 9.91* 8Y <JSIJQ ,JWRFS^ )7&<.3,34 ;*78.43 7*;.8.43 )7&<3 '> )&9* 5&,* .3)*= (-&3,*8 )&9* 7*85 (-*(0*) '> 5&,*8 2&9*7.&1 +.3.8- +.1*3&2*...
Page 16 TITLE: SPARE PART LIST TUBEMEISTER 18 HEAD HU0910 MAINBOARD DRAWING-NO VERSION REVISION DRAWN BY: DATE PAGE C. SCHMIDT 16.7.14 CHECKED BY DATE PAGES FILENAME HU0910-SPARES-MAINBOARD...
Page 17 TITLE: SPARE PART LIST TUBEMEISTER 18 HEAD HU0910 MAINBOARD DRAWING-NO VERSION REVISION DRAWN BY: DATE PAGE C. SCHMIDT 16.7.14 CHECKED BY DATE PAGES FILENAME HU0910-SPARES-MAINBOARD...
Page 18 TITLE: SPARE PART LIST TUBEMEISTER 18 HEAD HU0910 MAINBOARD DRAWING-NO VERSION REVISION DRAWN BY: DATE PAGE C. SCHMIDT 16.7.14 CHECKED BY DATE PAGES FILENAME HU0910-SPARES-MAINBOARD...
Page 19 9.91* 85&7* 5&79 1.89 9:'*2*.89*7 -*&) -: 7*&7'4&7) )7&<.3,34 ;*78.43 7*;.8.43 & )7&<3 '> )&9* 5&,* ( 8(-2.)9 (-*(0*) '> )&9* 5&,*8 +.1*3&2* -:85&7*87*&7'4&7)
Page 20 9.91* 85&7* 5&79 1.89 9:'*2*.89*7 -*&) -: 7*&7'4&7) )7&<.3,34 ;*78.43 7*;.8.43 & )7&<3 '> )&9* 5&,* ( 8(-2.)9 (-*(0*) '> )&9* 5&,*8 +.1*3&2* -:85&7*87*&7'4&7)
Page 21 9.91* 85&7* 5&79 1.89 9:'*2*.89*7 -*&) -: 1*)'4&7) )7&<.3,34 ;*78.43 7*;.8.43 & )7&<3 '> )&9* 5&,* ( 8(-2.)9 (-*(0*) '> )&9* 5&,*8 +.1*3&2* -:85&7*81*)'4&7)
Page 22 9.91* 85&7* 5&79 1.89 9:'*2*.89*7 -*&) -: 1*)'4&7) )7&<.3,34 ;*78.43 7*;.8.43 & )7&<3 '> )&9* 5&,* ( 8(-2.)9 (-*(0*) '> )&9* 5&,*8 +.1*3&2* -:85&7*81*)'4&7)
Page 23 ;*78.43 ; ; ;*78.43 ; ; 9 9 9 9 5T\JW 8YFSIG^ $//( 1,&+7 72/(5,(57(1 0$66( 1$&+ ',1 ,62 P &5574;*) '> )&9* 9.91* 70 +HDG .DEHOSODQ :LULQJ 'LDJUDP 6W :HQGHO *HUPDQ\ )7&<.3,34 ;*78.43 7*;.8.43 +8*.5$...
Page 24 REL2B +350V TP-THT30 +350V TP-THT30 +15V Clean Gain 470p/500V-K 100K/1W 10n/63V TP-THT30 MC33078P(MOT) INPUT 10n/63V 100K/1W 220K 100p/100V-K +350V 1MEG 220p/500V-K 22n/400V FRT5-1-12V ECC83S-CZ-N-PCB 1n/63V +15V -15V Treble 3n9/400V 1MEG -15V BZX55V_3V9 RM122-02 330p/100V-K 47p/100V-K 470K 270K 470K Treble 470K -22V 220K 22n/400V...
Page 25 18 Watt SPEAKER+ Audiotransformer Powersoak Switch FASTON-4.8-LG 39R/5W Full Full 5Watt 5Watt 1Watt 1Watt Zero Zero 15R/5W 1000UH-LBC SPEAKER- SW1A SR1102F-0404-TH SR1102F-0404-TH SW1C FASTON-4.8-LG Speaker Out 820R 33R/5W Full Full 8 to 16 Ohms 5Watt 5Watt 1Watt 1Watt Zero Zero MC33079P(MOT) 1000UH-LBC RM122-02...
Page 26 TP-SMD10 ZM2CB45S-BLUE ZM2CB45S-BLUE ZM2CB45S-BLUE ZM2CB45S-BLUE TP-SMD10 NDK-R0-B15 NDK-R0-B15 NA = not assembled part ----- EX = exclusive part, no alternative allowed HT = high temperature part, assemble with distance from PCB Title: PortaValve18 LED Board 66606 St. Wendel / Germany Number: HU0210-SP-R03 Version:...
Page 27 +3,3V TP-SMD10 10K* 100n-K+ 220R* PMLL4148 PMLL4148 39K* 10uF/4V-TA 150R* 22K* +15V 10K* MC33079 PMLL4148 PMLL4148 15K* 100K* 10n-K+ 4n7-K+ 10K* RESET PMLL4148 PMLL4148 IN + 47n-K+ MC33079 10K* IN + OUT + 10K* 10K* 10K* 4K7* MC33079 220R* IN - OUT + TP-SMD10 IN -...
Page 28 LM2594M-5.0 OPA2348AID 10K* OPA2348AID 150UH-BC PRLL5819 22,0uF/50V-S6 100uF/10V-S6 PMLL4148 10K* 10K* 10K* PMLL4148 100n-K* 220R* 22K* 4K7* TP-SMD-2X3-R2.54-B 1n5-K* T2-MISO T1-MOSI 4K7* 10K* 47K* RESET 470n-K- BC807-25 100K* 1K0* 22n-K* BC817-25 100n-K* 10R* 47K* 22K* 3K3* 100K* 1K0* PB0 (CLKO/ICP1) 100n-K* PWM-Tube2 PB1 (OC1A)
